Yamaha TT-R125LW(M) 2011 Owner's Service Manual (P/N 5HP-28199-81)

466 Pages • 1 Printable PDF (EN, FR, DE) • Download

4.5starstarstarstarstar_half(2)
$17.59 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Yamaha Models Covered & Key Technical Specifications

Model: TT-R125LW(M)

Sub-models / Variants: TT-R125LWM (5HP4: USA except California, Australia, New Zealand; 5HP5: Canada), TT-R125LWMC (5HP4: California), TT-R125LW (5HP4: Europe)

Trade Names: TT-R125LW, TT-R125LWM, TT-R125LWMC

Model Year: 2011


  • Engine displacement: 123.7 cm³

  • Engine type: Air-cooled 4-stroke, SOHC

  • Bore × stroke: 54.0 × 54.0 mm

  • Compression ratio: 10.0:1

  • Transmission: 5-speed constant-mesh

  • Starter: Kickstarter

  • Front brake: Single disc

  • Rear brake: Drum

Yamaha Manual Features & Selected Content Preview

This Yamaha Owner's Service Manual (P/N 5HP-28199-81) covers operation, inspection, maintenance, and repair for the kick-start TT-R125LW(M), including the TT-R125LWM, TT-R125LWMC, and TT-R125LW. For the listed 2011 model year, check your machine against the regional model codes above before ordering.

PDF Navigation, Languages, and Page Count

Text search and wiring detail. The main text is searchable. Bookmarks open the contents pages, where linked entries jump to the service sections. Zoom in to read the small wire-color and connector labels in the wiring diagram.

The download is one printable 466-page PDF in English, French, and German. The total includes the front and back covers, 24 introductory, index, and contents pages, and five memo pages.


Engine, Chassis, and Ignition Service

This selection of service topics covers the main workshop jobs. The manual also explains drive-chain slack adjustment and spark arrester cleaning for U.S. models.

  • Engine repair. Engine removal, cylinder head and valve train service, cylinder and piston inspection, crankcase separation, and crankshaft and balancer installation.
  • Clutch and transmission. Clutch and primary-drive inspection, kick axle and shift shaft service, and assembly of the transmission, shift cam, and shift forks.
  • Carburetor and lubrication. Mikuni VM20SS disassembly, fuel-level adjustment, coasting-enricher inspection, oil pump service, and an oil pressure check.
  • Brakes and wheels. Front caliper and master cylinder service, hydraulic bleeding, rear drum brake service, and inspection of front and rear wheel bearings.
  • Suspension and steering. Front fork overhaul, steering-head bearing service, swingarm linkage inspection, and rear shock removal and spring preload adjustment.
  • Ignition diagnosis. No-spark troubleshooting, engine stop switch and ignition coil tests, and CDI magneto inspection, with wiring and cable routing diagrams.

Owners can use the operating instructions, pre-ride checks, and maintenance schedules. The workshop procedures are suited to mechanics with the specified measuring equipment and special tools.

Model Identification and Parts Matching

The identification section shows where to find the VIN, engine number, and model label. When ordering a replacement piston, use the cylinder marking and the A–E matching chart to identify the corresponding piston size group and color code.

Engine Assembly and Carburetor Service

Tightening-torque tables and wear limits cover the cylinder head, camshaft, valve train, clutch, and transmission. The engine chapter also covers rocker-arm measurements, valve guide replacement, and valve seat lapping.

Exploded views and job instruction charts show the removal sequence for the clutch and primary driven gear and for the oil pump. Sectional views show circlip orientation. The tool list identifies the crankcase separator as YU-01135-A / 90890-01135. The camshaft installation notes flag a risk of damage or incorrect valve timing if the crankshaft moves during installation.

The carburetor section covers the float, needle valve, jets, starter plunger, and coasting-enricher diaphragm. The pilot air screw has a machine-specific factory setting. The turn counts shown are examples. Yamaha lists 620-1423A-71-A0 as a high-altitude main jet option.

Brake, Fork, and Rear Suspension Work

The brake section covers caliper piston seals, master cylinder cups, rear brake shoes, and brake camshaft positioning. Wheel inspection covers rim runout, axle straightness, and bearing condition.

The fork disassembly view shows the damper rod and oil seal. Yamaha recommends dealer service for the fork and warns that dropping the damper rod into the tube can damage it.

Rear suspension service covers the swingarm and linkage bushings. For the nitrogen-charged rear shock, Yamaha describes inspection and external bushing replacement, specifies assembly replacement for leaks or damage, and warns against opening the damper.

CDI Ignition Tests and Wiring

The wiring diagram identifies wire colors and components, and the cable routing diagrams show where the harness runs. The no-spark chart helps isolate a fault by checking the stop switch, ignition coil, and magneto pickup and charging coils before replacing the CDI unit.

Examples of Valve Clearances, Wear Limits, and Fluid Capacities

For the cold valve clearance check, Yamaha specifies 0.08–0.12 mm at the intake and 0.10–0.14 mm at the exhaust. The cylinder head inspection gives a warpage limit of 0.03 mm, and the crankshaft inspection gives a runout limit of 0.03 mm.

The fork assembly section specifies 156 cm³ of oil per leg. The fuel section lists a total tank capacity of 6.6 L, including a 1.9 L reserve.
