New Holland TN75S Supersteer Tractor Parts List (1998+) Parts Catalog

Shop manual for the New Holland TN75S Supersteer Tractor, covering various components and part numbers for efficient maintenance and repair. Part numbers are crucial for ordering.

4.7starstarstarstarstar_half(3)
New Holland Tractor manual preview - New Holland TN75S Supersteer Tractor Parts List (1998+) Parts Catalog
$17.85 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

New Holland Models Covered & Key Technical Specifications

Models: New Holland TN75S Supersteer Tractor
Sub-models / Variants: 8x8 30 km/h, 16x16 30 km/h, 32x16 30 km/h, Hi-Lo, Power Shuttle, Synchro Shuttle, Terraglide Front Axle, Supersteer Front Axle
Build Years: 1998 onwards
Technical Data:

  • Engine: Diesel
  • Transmission options: 8x8, 16x16, 28x16, 32x16, 44x16
  • Front Axle options: Standard 4WD, Supersteer, Terraglide
  • PTO: 540 RPM, 540/540E, 540/540E/1000 RPM
  • Hydraulic Pump capacity: 16.9 GPM (64L)
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
27605 / Donna Parker
File Size:
38.43 MB
File Type:
PDF
Language:
English
Pages:
2874
Printable:
Yes
Category:
Tractor
Last updated / verified
Jul 1, 2025

New Holland Manual Features & Content Preview

New Holland TN75S Parts Documentation

  • Covers the 1998 onwards New Holland TN75S Supersteer Tractor with diesel engine variants including Hi-Lo, Power Shuttle, and Terraglide configurations
  • Original OEM publication, catalog number 6031441200, first edition September 1998
  • Features 2,874 pages of exploded-view diagrams and assembly breakdowns for every tractor system
  • No shipping wait — the PDF is available immediately after purchase
  • Full-text search finds any part number in seconds
  • Suitable for printing individual sections for shop-floor use
  • This 1998 first edition serves as the foundational parts reference for the TN75S build, documenting all factory-installed options and mid-mount hydraulic attachments

Assembly and System Breakdown

This publication provides an exhaustive visual index of the New Holland TN75S tractor. The document systematically catalogs assemblies ranging from the diesel engine block, crankshaft, and cylinder head to the complex transmission gear sets and steering controls. Each section provides exploded diagrams with associated part numbers, ensuring accurate identification for all 5 documented model variations including the Supersteer and Terraglide axle configurations.

Technical Component Overview

Engine coverage details include piston and connecting rod specifications, cooling system lines, and injection pump variations. The parts documentation for New Holland tractors includes detailed hydraulic system diagrams, featuring remote control valves, lift cylinders, and pump specifications. The electrical section documents cable harnesses, relay locations, and instrument cluster connections. Reference data includes:

  • Front axle assembly 1.40.1 specifies configurations for Supersteer and Terraglide versions.
  • Hydraulic pump capacity for the electronic lift system is documented at 16.9 GPM (64L).
  • Engine gasket kits for the TN75S are indexed by engine number variation.

This is an official 2,874-page New Holland parts catalog covering the 1998 onwards TN75S Supersteer tractor, providing complete exploded-view diagrams for all mechanical, electrical, and hydraulic sub-assemblies for the specified build.

Manual FAQ, Purchase & Download Details

Does this parts catalog provide comprehensive exploded views for the TN75S Supersteer tractor systems? keyboard_arrow_down

Manual includes detailed figure lists and exploded view references for components ranging from the engine and transmission to the electrical and hydraulic systems.

What kind of reference data can be found in the parts list for the various tractor variations? keyboard_arrow_down

Document lists component part numbers and identifiers for multiple documented variations, including different transmissions, axles, and cab configurations. It utilizes figure search indexes to help locate specific assembly breakdowns for parts like the hydraulic pump, cooling lines, and front axle components.

Which publication identifier is shown for the TN75S Supersteer parts list? keyboard_arrow_down

Document is labeled for the TN75S Supersteer Tractor with an effective start date of November 1998.

Can I use this parts list to see the breakdown of the transmission or front axle assemblies? keyboard_arrow_down

Catalog contains extensive sections covering transmission cases, gear sets, and front axle assemblies, including specialized versions like the Terraglide axle. These sections provide visual parts lists that identify the structure and components of these major systems.

Is the information in this parts catalog specific to the New Holland TN75S series? keyboard_arrow_down

Manual is dedicated to the New Holland TN75S Supersteer Tractor and covers parts for a wide range of model variations including diesel engine types and various transmission setups. It serves as a comprehensive reference for identifying part numbers across the entire tractor build. The file is provided in PDF format for use on compatible electronic devices.

Customer Reviews

Read what our customers say about this New Holland Tractor manual and share your own experience.
