Repair your used Snowmobile with the help of this professional electronic PDF download version of the detailed and specific Yamaha Exciter servcie manual / repair guide.
Manual details, specs and technical data:
Production/model years: 1987, 1988, 1989, 1990, 87, 88 ,89, 90
Model specification / type:
Exciter EX570
Exciter EX570E Deluxe w/ Electric Start
Venture XL 500
Manual Language: English
Manual format: PDF / e-book (zip)
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
*/#
³
If you own a 1987-1990 Yamaha Exciter 570, Exciter EX570, Exciter EX570E Deluxe, or Venture XL 500 snowmobile, then you know how important it is to keep your machine in top condition. That's why the 1987-1990 Yamaha Exciter 570, Exciter EX570, Exciter EX570E Deluxe, Venture XL 500 snowmobile service manual is a must-have for any owner. With this manual, you can perform repairs and maintenance on your snowmobile with confidence, knowing you have access to all the information you need.
Here are 15 tech specs and features about the 1987-1990 Yamaha Exciter 570, Exciter EX570, Exciter EX570E Deluxe, Venture XL 500:
• Engine Type: 2-stroke, liquid-cooled
• Displacement: 570cc
• Carburetion: 1x Mikuni VM34
• Ignition System: CDI
• Drive Clutch: Yamaha primary
• Driven Clutch: Yamaha secondary
• Suspension: Independent Double Wishbone front suspension, ProAction Plus rear suspension
• Track Size: 121 x 15 x 0.79
• Brake Type: Hydraulic disc brake
• Fuel Capacity: 10.8 US gal
• Length: 105.5 inches
• Width: 43.9 inches
• Height: 39.6 inches
• Dry Weight: 474 lbs
• Oil Capacity: 3.17 US qt
The service manual includes detailed instructions for maintenance, troubleshooting, and repair of your snowmobile. It includes everything from basic oil changes to more complex engine repairs, and even has wiring diagrams and exploded parts diagrams to help you understand your snowmobile's inner workings.
The manual also provides a comprehensive parts list, making it easy to find the replacement parts you need for your snowmobile. Whether you need a new drive belt, spark plug, or fuel filter, the parts list will guide you to the right part for your specific snowmobile model.
In addition to helping you perform repairs, the service manual can also help you save money. Instead of taking your snowmobile to a mechanic for routine maintenance, you can do it yourself with the help of the manual. This can save you hundreds of dollars in labor costs over the life of your snowmobile.
So, if you want to keep your 1987-1990 Yamaha Exciter 570, Exciter EX570, Exciter EX570E Deluxe, or Venture XL 500 snowmobile in top condition, don't hesitate to download the service manual from repairloader.com. With all the information you'll be able to tackle any repair or maintenance task with confidence.
