TT-R125 / Yamaha Motor Co., Ltd
- TT-R125(P)
- TT-R125LW(P)
- TT-R125: Standard model with 125cc engine
- TT-R125L: Larger wheel version
- TT-R125LE: Larger wheel version with electric start
Production year(s): 2001
2001 Yamaha TT-R125 owner's + service manual
Models covered in this manual:
File specifications
File type: PDF
Language: English, French, German
Number of pages: 501
Printable: Yes
Estimated download time: 0.3 Minutes
$18.99
Pay with Bitcoin
Product Information
Table of Contents:
GENERAL INFORMATION
- Description
- Machine Identification
- Important Information
- Checking of Connection
- Special Tools
- Control Functions
- Fuel
- Starting and Break-In
- Torque-Check Points
- Cleaning and Storage
SPECIFICATIONS
- General Specifications
- TT-R125
- TT-R125LW
- Maintenance Specifications
- Engine
- Chassis
- Electrical
- General Torque Specifications
- Definition of Units
- Cable Routing Diagram
REGULAR INSPECTION AND ADJUSTMENT
- Maintenance Intervals
- Pre-Operation Inspection and Maintenance
- Engine
- Chassis
- Electrical
ENGINE
- Seat, Fuel Tank, and Side Covers
- Muffler
- Carburetor
- Cylinder Head
- Camshaft and Rocker Arms
- Valves and Valve Springs
- Cylinder and Piston
- Clutch and Primary Driven Gear
- Oil Pump
- Kick Axle and Shift Shaft
- CDI Magneto
- Engine Removal
- Crankcase, Crankshaft, and Balancer
- Transmission, Shift Cam, and Shift Fork
CHASSIS
- Front Wheel and Front Brake (TT-R125)
- Front Wheel (TT-R125LW)
- Front Brake (TT-R125LW)
- Rear Wheel and Rear Brake
- Front Fork
- Handlebar
- Steering
- Swingarm
- Rear Shock Absorber Assembly
ELECTRICAL
- Electrical Components and Wiring Diagram
- Ignition System
How to Download Your Manual - Delivery Policy
Within a minute after completing the payment process, you will receive two emails from us. One for the completed payment and another with the download link. The download link is valid for 3 days.
Lifetime Guarantee
