Repair your dual-purpose on/off road motorcycle: Buy this Yamaha Motor Corp., Ltd XT660R, XT660X factory manual / repair guide.
2004-2012 Yamaha XT660R, XT 660X, XT 660 repair manual
off-road bike: Use this Yamaha Motor Corporation, Ltd XT660R, XT 660X, XT 660 manual (PDF).
Production year(s): 2004, 2005, 2006, 2007, 2008, 2009,
Production/model years: 2004, 2005, 2006, 2007, 2008, 2009.
Models / manfuacturer: XT660R, XT660X / Yamaha
Engine: 660 cc liquid-cooled, 4-stroke, SOHC, single-cylinder, 4-valve, fuel injected
Manual Language: English
Manual format: PDF / e-book (zip)
Delivery: Download link will appear on the checkout page after your payment is complete.
Looking for a comprehensive manual to repair your 2004-2009 Yamaha XT660R or XT660X? Look no further than the instant download available at repairloader.com. This DIY handbook has everything you need to keep your bike in top condition.
The manual includes information on how to repair various components of the bike, including the engine, carburetor, and wiring. It also includes a detailed parts list and helpful troubleshooting advice to make your repairs as smooth as possible.
Here are 10 tech specs to give you an idea of what to expect from your XT660R or XT660X:
- The engine is a liquid-cooled, 4-stroke, single-cylinder, SOHC, 4-valve engine with a displacement of 659 cc.
- The engine produces a maximum power of 35 kW (47 hp) at 6,000 rpm and a maximum torque of 58 Nm (43 lb-ft) at 5,500 rpm.
- The bike has a 5-speed manual transmission.
- The carburetor is a Mikuni BSR42.
- The bike has an electric starter system and a maintenance-free battery.
- The front suspension is a telescopic fork with a diameter of 43 mm, while the rear suspension is a link-type Monocross.
- The bike has front and rear disc brakes.
- The fuel tank has a capacity of 15 liters (3.96 US gallons).
- The bike has a seat height of 865 mm (34.1 inches).
Service intervals for the bike include oil changes every 10,000 km (6,200 miles) and valve clearance checks every 40,000 km (24,800 miles).
Whether you're a seasoned mechanic or just starting out, the 2004-2009 Yamaha XT660R/XT660X manual is a valuable resource for maintaining and repairing your bike. Don't let a breakdown keep you off the road - download your copy with the convenience of PayPal.
