2003-2009 Yamaha Wolverine 350 ATV repair manual

Price: 18.99 USD
Lifetime Guarantee
File specifications File size: 53.97 MB File ending in: pdf
To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. Ensure the upkeep and repair of your ATV by instantly accessing the genuine Yamaha Motor Corp., Ltd Wolverine 350 OEM manual in PDF format. Specs: Production/model years: 2009, 2008, 2007, 2006 2005, 2004, 2004 This manual applies to the following models: Wolverine 350 / Yamaha Motor Company YFM35FXGR (2003) YFM35FXGS (2004) YFM35FXT (2005) YFM35FXY (2006) YFM35FGY (2007) YFM35FGZ (2008) YFM35FGH (2009) Serial numbers: Range from JY43GNW03C000001 to JY43GNW09C014981. Engine: 348 cc / 21.2 ci, 4-stroke, single-cylinder, air cooled, oil cooled, SOHC, 83 / 3.27 x 64.5 / 2.54, 9.2:1 Manual Language: English Printable: Yes Delivery: Download link will appear on the checkout page after your payment is complete. # ³ "Download Yamaha Wolverine 350 Repair Manual in PDF Format for Instant Maintenance Help" Are you a proud owner of a Yamaha Wolverine 350 ATV? Whether you are looking for maintenance intervals, general maintenance tips, technical specs, or solutions for common issues, we have got you covered. This article provides a comprehensive guide to the 2003-2009 Yamaha Wolverine 350 ATV, including engine specs, maintenance tips, tuning suggestions, accessories, and more. Technical Specs: • The 2003-2009 Yamaha Wolverine 350 ATV is powered by a 348cc four-stroke engine. • It has a bore and stroke of 83mm x 64.5mm. • The engine has a compression ratio of 9.2:1. • The ATV features a five-speed manual transmission with reverse gear. • The front suspension has independent double wishbone with 5.9 inches of travel. • The rear suspension is swingarm with 6.3 inches of travel. • The front brakes are dual hydraulic discs, while the rear brake is a sealed drum. • The ATV has a fuel capacity of 3.8 gallons. • The overall length of the vehicle is 80.1 inches. • The width is 42.5 inches, and the height is 45.7 inches. • The ground clearance is 10.8 inches. • The ATV weighs 489 pounds. • It has a maximum towing capacity of 1102 pounds. • The front tires are AT 25 x 8-12, while the rear tires are AT 25 x 10-12. • The ignition system is a CDI. • The ATV has a shaft drive system. • The battery voltage is 12V, and the capacity is 14Ah. • The ATV has a wheelbase of 49.2 inches. • The maximum load capacity is 242 pounds. • The seat height is 33.1 inches. • The turning radius is 118.1 inches. • The engine oil capacity is 2.11 US quarts. • The spark plug gap is 0.6-0.7mm. • The air filter should be cleaned or replaced every 3000 miles or six months. • The valve clearance should be checked every 4000 miles. Interesting Facts and Details: - The Yamaha Wolverine 350 ATV was introduced in 2003 and discontinued in 2009. - It is designed for off-road use and is not legal for highway use. - The ATV features a compact body design that allows it to maneuver easily in tight spaces. - The Wolverine 350 ATV is known for its durability and reliability. - The ATV is popular among hunters, farmers, and outdoor enthusiasts. Maintenance Tips: - Change the oil and oil filter every 1000 miles or six months. - Check the tire pressure before every ride. - Clean the air filter regularly. - Lubricate the drive chain every 300 miles. - Check the brake pads and replace them if necessary. Tuning Tips: - Install an aftermarket exhaust system for improved performance. - Upgrade the air filter to a high-performance filter. - Install a jet kit for better fuel delivery. - Install a high-performance CDI for improved ignition timing. - Upgrade the suspension for better handling. Accessories and Aftermarket Options: - Winches - Cargo racks - Snowplows - Skid plates - Handguards - LED lights - Gun racks - GPS systems - Rearview mirrors Owner Reviews: Many owners of the Yamaha Wolverine 350 ATV have praised its durability, reliability, and versatility. It is known for its ability to handle rough terrain with ease and its smooth ride. However, some owners have reported issues with the brakes, electrical system, and transmission. Overall, the Yamaha Wolverine 350 ATV is highly regarded by many owners as a great all-around ATV. To buy the genuine Yamaha Wolverine 350 OEM manual in PDF format and make secure payment using PayPal, simply visit www.repairloader.com and click on the green button to start the instant download process. As soon as your payment is processed securely, you will receive an email with all the download information you need, and the original Yamaha Wolverine manual/parts list download link will appear on the checkout page. §
Price: 18.99 USD
Lifetime Guarantee
