To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years.
The manual is valid for the following models: GX70, GX75, GX85, SX85, GX95, SRX75, SRX95 / John Deere
John Deere GX70 (1991-1996)
John Deere GX75 (1991-1996)
John Deere GX85 (1997-2003)
John Deere SX85 (1997-2003)
John Deere GX95 (1995-2003)
John Deere SRX75 (1991-1996)
John Deere SRX95 (1995-2003)
Engine GX70: Kawasaki FC290V, gasoline, 1-cylinder, air-cooled, vertical-shaft, 290 cc, 17.7 ci, 3.07x2.36 inches, 78 x 60 mm, 9 hp, 6.7 kW.
Engine GX75: ..., see above, 8.4:1.
Engine GX85: Briggs & Stratton 28M707, gasoline, 1-cylinder, air-cooled, vertical-shaft, 465 cc, 28.4 ci, 3.44x3.06 inches, 87 mm x 78 mm, 13 hp, 9.7 kW.
Engine SX85: see above.
Engine GX95: Kawasaki FB460V, gasoline, 1-cylinder, air-cooled, vertical-shaft, 460 cc, 28.1 ci, 3.5x2.91 inches, 89 mm x 74 mm, 12.5 hp, 9.3 kW, 6.4:1.
Engine SRX75: Kawasaki FC290V, ..., see above...
Engine SRX95: Kawasaki FB460V, see above...
Production year(s): 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003.
Publication Number: TM1491
Pages: 457
Manual Language: English
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
#
