Yamaha Blaster 200 YFS200 1988–2008 ATV Service Manual Set (P/N LIT-11616-06-41)
347 Pages • ZIP Download: 3 Printable PDFs (English)
Yamaha Models Covered & Key Technical Specifications
Models: Blaster 200 — YFS200U, YFS200A, YFS200P, YFS200R
Models & Model Codes:
YFS200U — 2XJ
YFS200A — USA (3JM2), non-USA (3JM3)
YFS200P — USA (5KJ7)
YFS200R — Oceania (5VM1), Canada/Europe (5VM2)
Engine prefixes: YFS200U: 2XJ; YFS200A: 3JM
Model Years: 1988–2008 (1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008)
Starting Serial Numbers — YFS200U: USA/Canada VIN: JY42XJW0 * JC000101; frame outside USA/Canada: 2XJ-000101; engine: 2XJ-000101.
Starting Serial Numbers — YFS200A: USA VIN: JY43JMA0 LC046101; Canada/Australia VIN: JY43JMW0 LC075101; frame outside USA/Canada/Australia: 3JM-075101; USA engine: 3JM-046101; non-USA engine: 3JM-075101.
-
Engine type: 2-stroke, air-cooled
-
Ignition system: C.D.I.
-
Transmission: YFS200U: constant-mesh 6-speed
-
Spark plug: YFS200P/YFS200R: BR8ES/NGK; YFS200U USA/Oceania: B8ES/NGK or W24ES/NIPPON DENSO; YFS200U Canada/South Africa: BP8ES/NGK; YFS200A USA/Oceania: B8ES/NGK or W24ES/NIPPON DENSO; YFS200A Canada/Great Britain/France/Switzerland/South Africa: BR8ES/NGK
-
Spark plug gap: 0.7–0.8 mm (YFS200P: 0.028–0.031 in; YFS200U/YFS200A/YFS200R: 0.028–0.032 in)
-
Engine idling speed: 1,450–1,550 r/min
-
Front tire: AT21x7-10
-
Rear tire: AT21x10-8
-
Brake fluid: YFS200R hydraulic brakes: DOT 4
Yamaha Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| YFS200U Service Manual — P/N LIT-11616-06-41; model code 2XJ | 234 |
| YFS200A Supplementary Service Manual — P/N LIT-11616-07-20 / 3JM-28197-10; model codes 3JM2 (USA), 3JM3 (non-USA) | 14 |
| YFS200P Supplementary Service Manual — P/N LIT-11616-15-05 / 3JM-28197-11; model code 5KJ7 (USA) | 24 |
| YFS200R Supplementary Service Manual — P/N 2XJ-AE3; model codes 5VM1 (Oceania), 5VM2 (Canada/Europe) | 75 |
The YFS200U book supplies the full repair foundation. The A supplement updates that material, and the P supplement expressly calls for both earlier publications. Use each supplement with the base procedures for its named configuration.
R supplement references: Its foreword specifies international manuals 2XJ-ME1, 2XJ-AE1 and 2XJ-AE2. This set supplies U/A/P material under US-market identifiers, rather than those exact international editions.
PDF Search, Bookmarks and Diagram Detail
Finding procedures and reading diagrams: The combined U/A file has no PDF text search; the P and R files have searchable text. U/A chapter bookmarks include an incorrect lighting-fault link. Most R section bookmarks open the contents; its wiring-diagram bookmark opens the diagram. The P file has no bookmarks. Small wiring and connector labels on the checked P/R diagrams require zooming; the checked U circuit diagram is readable when enlarged.
The ZIP contains three printable English PDFs totaling 347 pages: the combined U/A file has 248 pages, followed by separate P and R files. The table’s A count includes the combined front cover; introductory and closing pages, one U section-divider page and two R blank pages are already included.
Engine Overhaul, Chassis Repair and Electrical Testing
The following is a selection of covered work, rather than a full contents list. Other topics include headlight aiming and bulb replacement.
-
Engine overhaul: Removal, disassembly, inspection, repair, reassembly and installation of the cylinder head, cylinder, piston, rings, crankshaft, crankcase and Autolube pump.
-
Clutch and transmission: Wet-clutch service, primary-drive and balancer-gear work, transmission inspection, shifter repair, kick-start mechanism service and assembly checks.
-
Carburetor and reed valve: Removal, teardown, inspection, assembly, installation, float-height and fuel-level adjustment, reed-petal checks and carburetor-setting changes.
-
Chassis repair: Front wheel and drum brake, rear wheel and axle, rear disc brake, steering, front arms and shocks, rear shock, swingarm, chain and sprockets.
-
R hydraulic brakes: Step-by-step instructions for pad replacement, caliper and master-cylinder overhaul, hose inspection, parking-brake adjustment, filling, bleeding and operating checks.
-
Electrical diagnosis: Ignition and lighting fault isolation, switch-continuity checks, coil tests, and troubleshooting charts for starting, shifting, clutch, brake and handling complaints.
Yamaha produced these manuals primarily for dealers and qualified mechanics, assuming an existing understanding of mechanical concepts and machine-repair procedures.
Engine Inspection and Fuel-System Adjustments
The base manual supports internal inspection with component-specific tightening data, exploded views, cylinder-head resurfacing guidance, cylinder measurements and oversize-piston information. It also identifies engine components that can be serviced with the engine still installed.
Periodic service covers Autolube-pump bleeding, ignition-timing checks, transmission-oil replacement, drive-chain adjustment, brake inspection, steering checks and chassis lubrication.
The A supplement provides revised transmission-oil procedures, parking-brake adjustment and a cold-weather carburetor setting chart. Its jetting changes are model-specific; the base book’s setting chart should not be treated as interchangeable.
Brake Configurations and Suspension Work
The U book’s front drum brakes and mechanically operated rear disc brake differ from the R supplement’s dual-front and single-rear hydraulic discs. Matching the brake arrangement before selecting a procedure helps avoid applying cable-operated brake instructions to hydraulic components.
R brake coverage includes seal replacement, front and rear assembly differences, hose positioning and post-assembly checks. Suspension work includes spring-preload adjustment, shock-assembly replacement and swingarm side-clearance shimming; the pressurized rear shock cylinder is not intended to be opened.
Wiring Diagrams and Fault Isolation
Diagram coverage includes the YFS200U circuit diagram, separate YFS200P and YFS200R wiring diagrams, and ignition-, lighting- and signal-system circuit diagrams. Model-specific cable-routing plates show cable, hose and harness placement.
The P supplement adds rear brake-light switch adjustment and signal-system diagnosis. The R ignition section explains the parking-brake engine-speed limit, helping distinguish its resulting misfire from an ignition fault. Additional charts address kick-start faults, poor running at different throttle ranges, lighting failure and overheating.
Service Tools and Workshop Cautions
Reference material includes torque tables, lubricant and capacity data, wear limits, clearances, carburetor settings, maintenance intervals and electrical test specifications.
Listed Yamaha tools include crankcase separator YU-01135 / 90890-01135, crankshaft installer YU-90050 with 90890-01274 and 90890-01275, rotor puller YM-01189 / 90890-01189, and pocket tester YU-03112 / 90890-03112.
Spinning bearings dry with compressed air can damage their surfaces and cause breakage. Incorrect or mixed hydraulic brake fluid can deteriorate seals, cause leakage and reduce braking performance.
Brake, steering, and suspension repairs directly affect machine control; follow the Yamaha warnings and final inspection checks before returning the ATV to service.
Preview of Ignition Test Specifications
For the YFS200R, the pickup-coil resistance specification is 16–24 Ω at 20 °C, measured across the White/Red and Black leads.
Its ignition-coil checks specify primary resistance of 0.18–0.28 Ω and secondary resistance of 6.32–9.48 kΩ, both at 20 °C. These values accompany diagnostic flowcharts and tester-connection illustrations.
