Overhaul/Repair your snowmobile now - Download this PDF at repairloader.com: Polaris Industries inc (2007-2008 models) manual.
Specs:
Production/model years: 2007, 2008.
This manual applies to the following models:
2007 600 HO IQ
2007 600 HO SWITCHBACK
2007 600 HO RMK
2007 600 HO IQ CFI
2007 600 HO SWITCHBACK CFI
2007 600 HO IQ LX CFI
2007 600 HO IQ TOURING CFI
2007 700 HO IQ DRAGON
2007 700 HO RMK DRAGON
2008 IQ SHIFT
2008 600 RMK 144 / 600 RMK SHIFT
2008 600 DRAGON IQ
2008 600 SWITCHBACK / 600 DRAGON SWITCHBACK
2008 600 IQ LX
2008 600 IQ TOURING
2008 600 RMK 155
2008 700 IQ / 700 DRAGON IQ
2008 700 SWITCHBACK / 700 DRAGON SWITCHBACK
2008 700 RMK 155 / 700 DRAGON RMK
2008 800 DRAGON RMK
Manual Language: English
Manual format: PDF / e-book (zip)
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
#
³
2007 600 HO IQ:
• Engine: Liberty liquid-cooled, 2-stroke, 2-cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI
• Suspension: IQ front suspension, RydeFX MPV shocks, IQ rear suspension
• Track dimensions: 15 x 121 x .91 in.
• Fuel Capacity: 11.5 gal.
• Dry Weight: 471 lbs.
2007 600 HO SWITCHBACK:
• Engine: Liberty liquid-cooled, 2-stroke, 2-cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI
• Suspension: EDGE front suspension, RydeFX MPV shocks, EDGE rear suspension
• Track dimensions: 15 x 136 x 1.25 in.
• Fuel Capacity: 11.5 gal.
• Dry Weight: 496 lbs.
2007 600 HO RMK:
• Engine: Liberty liquid-cooled, 2-stroke, 2-cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI
• Suspension: RMK Coil-Over front suspension, RydeFX MPV shocks, RMK rear suspension
• Track dimensions: 15 x 144 x 2 in.
• Fuel Capacity: 11.5 gal.
• Dry Weight: 472 lbs.
2007 600 HO IQ CFI:
• Engine: Liberty liquid-cooled, 2-stroke, 2-cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI
• Suspension: IQ front suspension, RydeFX MPV shocks, IQ rear suspension
• Track dimensions: 15 x 121 x .91 in.
• Fuel Capacity: 11.5 gal.
• Dry Weight: 471 lbs.
2007 600 HO SWITCHBACK CFI:
• Engine: Liberty liquid-cooled, 2-stroke, 2-cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI
• Suspension: EDGE front suspension, RydeFX MPV shocks, EDGE rear suspension
• Track dimensions: 15 x 136 x 1.25 in.
• Fuel Capacity: 11.5 gal.
• Dry Weight: 496 lbs.
2007 600 HO IQ LX CFI:
• Engine Type: Liberty Liquid Cooled Twin Cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 mm x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI w/TPS, WTS & DET
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Length: 121 in
• Ski Stance: 42.5 in
• Fuel Capacity: 11.5 gal
2007 600 HO IQ TOURING CFI:
• Engine Type: Liberty Liquid Cooled Twin Cylinder
• Displacement: 599 cc
• Bore x Stroke: 77.25 mm x 64 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI w/TPS, WTS & DET
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Length: 136 in
• Ski Stance: 42.5 in
• Fuel Capacity: 11.5 gal
2007 700 HO IQ DRAGON:
• Engine Type: Liberty Liquid Cooled Twin Cylinder
• Displacement: 755 cc
• Bore x Stroke: 77.25 mm x 66.4 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI w/TPS, WTS & DET
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Length: 136 in
• Ski Stance: 42.5 in
• Fuel Capacity: 11.5 gal
2007 700 HO RMK DRAGON:
• Engine Type: Liberty Liquid Cooled Twin Cylinder
• Displacement: 755 cc
• Bore x Stroke: 77.25 mm x 66.4 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI w/TPS, WTS & DET
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Length: 155 in
• Ski Stance: 39 - 41 in
• Fuel Capacity: 11.5 gal
2008 IQ SHIFT:
• Engine Type: Liberty Liquid Cooled Twin Cylinder
• Displacement: 544 cc
• Bore x Stroke: 73 mm x 66 mm
• Carburetion: Cleanfire Injection
• Ignition: Digital CDI w/TPS, WTS & DET
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Length: 121 in
• Ski Stance: 42.5 in
• Fuel Capacity: 11.5 gal
2008 600 RMK 144 / 600 RMK SHIFT:
• Engine Type: Liberty, liquid-cooled, twin-cylinder, 2-stroke
• Displacement: 599cc
• Bore x Stroke: 77.25 x 64mm
• Ignition: Digital CDI w/ TPS, WTS, DET
• Carburetion: 2x TM 40
• Fuel Capacity: 11.5 gal.
• Suspension: RMK with Walker Evans Piggyback Needle Shocks
• Track Dimensions: 15 x 144 x 2.0 in.
• Dry Weight: 455 lbs.
2008 600 DRAGON IQ:
• Engine Type: Liberty, liquid-cooled, twin-cylinder, 2-stroke
• Displacement: 599cc
• Bore x Stroke: 77.25 x 64mm
• Ignition: Digital CDI w/ TPS, WTS, DET
• Carburetion: Cleanfire Injection
• Fuel Capacity: 11.5 gal.
• Suspension: IQ with Walker Evans Piggyback Needle Shocks
• Track Dimensions: 15 x 136 x 1.25 in.
• Dry Weight: 480 lbs.
2008 600 SWITCHBACK / 600 DRAGON SWITCHBACK:
• Engine Type: Liberty, liquid-cooled, twin-cylinder, 2-stroke
• Displacement: 599cc
• Bore x Stroke: 77.25 x 64mm
• Ignition: Digital CDI w/ TPS, WTS, DET
• Carburetion: Cleanfire Injection
• Fuel Capacity: 11.5 gal.
• Suspension: IQ with Walker Evans Piggyback Needle Shocks
• Track Dimensions: 15 x 136 x 1.25 in.
• Dry Weight: 470-480 lbs.
2008 600 IQ LX:
• Engine Type: Liberty, liquid-cooled, twin-cylinder, 2-stroke
• Displacement: 599cc
• Bore x Stroke: 77.25 x 64mm
• Ignition: Digital CDI w/ TPS, WTS, DET
• Carburetion: Cleanfire Injection
• Fuel Capacity: 11.5 gal.
• Suspension: IQ with RydeFX MPV Shocks
• Track Dimensions: 15 x 121 x 1.0 in.
• Dry Weight: 470 lbs.
2008 600 IQ TOURING:
• Engine Type: Liberty, liquid-cooled, twin-cylinder, 2-stroke
• Displacement: 599cc
• Bore x Stroke: 77.25 x 64mm
• Ignition: Digital CDI w/ TPS, WTS, DET
• Carburetion: Cleanfire Injection
• Fuel Capacity: 11.5 gal.
• Suspension: IQ with RydeFX MPV Shocks
• Track Dimensions: 15 x 136 x 1.0 in.
• Dry Weight: 565 lbs.
2008 600 RMK 155:
• Engine: 599cc liquid-cooled, 2-stroke engine
• Bore x Stroke: 77.25 mm x 64 mm
• Carburetion: Cleanfire Injection
• Front Suspension: RMK Coil-Over
• Rear Suspension: RMK Coil-Over
• Track Dimensions: 15 x 155 x 2.25 in
• Dry Weight: 467 lb
• Fuel Capacity: 11.5 gal
• Electric Start: Optional
2008 700 IQ / 700 DRAGON IQ:
• Engine: 795cc liquid-cooled, 2-stroke engine
• Bore x Stroke: 85 mm x 70 mm
• Carburetion: Cleanfire Injection
• Front Suspension: IQ
• Rear Suspension: IQ
• Track Dimensions: 15 x 121 x 1 in
• Dry Weight: 491 lb
• Fuel Capacity: 11.5 gal
• Electric Start: Optional
2008 700 SWITCHBACK / 700 DRAGON SWITCHBACK:
• Engine: 795cc liquid-cooled, 2-stroke engine
• Bore x Stroke: 85 mm x 70 mm
• Carburetion: Cleanfire Injection
• Front Suspension: IQ
• Rear Suspension: PRO-RIDE
• Track Dimensions: 15 x 136 x 1.25 in
• Dry Weight: 489 lb
• Fuel Capacity: 11.5 gal
• Electric Start: Optional
2008 700 RMK 155 / 700 DRAGON RMK:
• Engine: 795cc liquid-cooled, 2-stroke engine
• Bore x Stroke: 85 mm x 70 mm
• Carburetion: Cleanfire Injection
• Front Suspension: RMK
• Rear Suspension: RMK
• Track Dimensions: 15 x 155 x 2.25 in
• Dry Weight: 478 lb
• Fuel Capacity: 11.5 gal
• Electric Start: Optional
2008 800 DRAGON RMK:
• Engine: 795cc liquid-cooled, 2-stroke engine
• Bore x Stroke: 85 mm x 70 mm
• Carburetion: Cleanfire Injection
• Front Suspension: RMK
• Rear Suspension: RMK
• Track Dimensions: 15 x 155 x 2.25 in
• Dry Weight: 478 lb
• Fuel Capacity: 11.5 gal
• Electric Start: Optional
The Polaris snowmobile repair manual from www.repairloader.com provides an extensive guide on how to fix any issues that may arise with your snowmobile. The manual covers the most common problems on a Polaris snowmobile and offers the best solution to encounter these issues. This manual includes over forty pages of troubleshooting information and suggestions for maintenance and care, with photos and detailed instructions. You can use the manual as a guide and reference during your Polaris snowmobile repair.
The 2007-2008 Polaris IQ RMK 155 Snowmobile service repair workshop manual covers each part of the fix, such as general specifications, maintenance, fuel delivery, engine, clutching, final drive, brake system, steering, front and rear suspension, chassis/hood, electrical system, and wiring diagrams. With this manual, you can learn how to repair your snowmobile correctly, avoid expensive and unnecessary repairs, and save money.
The manual is 100% complete and immaculate, providing step-by-step instructions that guide the reader through every service and repair procedure. You can download the Polaris IQ RMK 155 snowmobile service repair workshop manual instantly at www.repairloader.com. The manual is suitable for DIYers and experienced mechanics alike. It provides detailed instructions for the complete disassembly and reassembly of your snowmobile.
Additionally, the manual includes specifications, such as the weight, length, width, height, track length, and lug height, as well as the fuel capacity, engine type, and horsepower for each snowmobile model. For example, the 2007 600 HO IQ has a weight of 465 lbs, length of 110 in, width of 47.5 in, height of 48 in, track length of 121 in, and lug height of 1.25 in. It also has a fuel capacity of 11.5 gallons, a liquid-cooled 2-stroke engine, and 120 horsepower.
The manual provides specific information on each model, such as the 2008 600 Switchback, which has a dry weight of 485 lbs, a length of 116 in, a width of 48 in, a height of 48 in, and a track length of 136 in. It also has a fuel capacity of 11.5 gallons, a liquid-cooled 2-stroke engine, and 120 horsepower. The manual includes information on the 2008 700 IQ, 700 DRAGON IQ, 700 SWITCHBACK, 700 DRAGON SWITCHBACK, 700 RMK 155, and 700 DRAGON RMK.
You can buy the Polaris snowmobile repair manual for your specific model at www.repairloader.com using PayPal. Click on the green button to start the instant download, and we will email you with all download information one minute after payment. This manual is your go-to guide for proper maintenance, repair, and service of your Polaris snowmobile. It provides you with the knowledge and skills to keep your snowmobile in top condition, ensuring you have an unforgettable snowmobiling experience.
Price: 17.99 USD
