1990-1998 Yamaha Phazer snowmobile service manual Preview image 1
1990-1998 Yamaha Phazer snowmobile service manual Preview image 2
1990-1998 Yamaha Phazer snowmobile service manual Preview image 3
1990-1998 Yamaha Phazer snowmobile service manual Preview image 4
1990-1998 Yamaha Phazer snowmobile service manual Preview image 5
1990-1998 Yamaha Phazer snowmobile service manual Preview image 6

1990-1998 Yamaha Phazer snowmobile service manual

Models covered in this manual:

Yamaha Motor Company

PZ480-EST

  • Yamaha Phazer (1990-1998)
    • Engine: 485cc, fan-cooled, fuel-injected liquid-cooled four-stroke
    • PZ480EST
    • PZ480W
    • PZ480EW
    • PZ480STW
    • PZ480T
    • PZ480ET
    • PZ480STT
    • PZ480R
    • PZ480ER
    • PZ480STR
    • PZ480P
    • PZ480EP

Production/model years: 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998

File specifications

File size: 73.01 MB
File type: PDF
Language: English
878 pages

Printable: Yes
Estimated download time: 1.5 Minutes
$17.99 Instant Download

Pay with Bitcoin

Product Information

Table of Contents

GENERAL INFORMATION

  1. Machine Identification
  2. Features and Specifications
  3. General Specifications
  4. Location of Labels

PERIODIC INSPECTION AND ADJUSTMENT

  1. Periodic Maintenance Chart
  2. Engine Oil and Filter
  3. Air Filter
  4. Spark Plug
  5. Valve Clearance
  6. Carburetor Adjustment
  7. Idle Speed Adjustment
  8. Throttle Cable Adjustment
  9. Brake Adjustment
  10. Drive Chain/Belt Adjustment
  11. Suspension Adjustment
  12. Battery Maintenance
  13. Tire Pressure

POWER TRAIN

  1. Engine
    • Engine Removal and Installation
    • Cylinder Head and Valves
    • Cylinder and Piston
    • Crankshaft
    • Clutch and Primary Drive
    • Transmission and Shift Mechanism
    • Lubrication System
    • Cooling System
  2. Carburetion
    • Carburetor Removal and Installation
    • Carburetor Disassembly and Reassembly
    • Carburetor Adjustment
  3. Drive System
    • Drive Shaft
    • Drive Chain/Belt
    • Final Drive
    • Differential Gear

SPECIFICATIONS

  1. General Specifications
  2. Engine Specifications
  3. Chassis Specifications
  4. Electrical Specifications
  5. Tightening Torques

How to Download Your Manual - Delivery Policy
