2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual

Detailed service manual covering the 2001-2003 Acura 3.2 CL, including air bag system operation, component locations, and diagnostic procedures. Ref: 77304-SEC-A00

4.5starstarstarstarstar_half(2)
visibility Preview Available
Acura 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual page preview - page 1 of

Sample pages from the 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual

Acura 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual preview page 1 - thumbnail
Acura 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual preview page 2 - thumbnail
Acura 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual preview page 3 - thumbnail
Acura 2001-2003 Acura 3.2CL Air Bag Restraint Systems Service Manual manual preview page 4 - thumbnail
info_outline Click thumbnails to preview different pages
$15.80 (incl. VAT) Instant Download / No Shipping Fees
3 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal

Acura Models Covered & Key Technical Specifications

Models: Acura 3.2CL
Build Years: 2001–2003
Technical Data:

  • Occupant Position Detection System (OPDS) initialization: Required after passenger seat-back replacement
  • SRS indicator light initialization time: 6 seconds
  • Multimeter test limit: 10 milliamp (0.01-amp) or less
  • Air bag assembly mounting torque: 87 in-lbs. (9.8 N.m)
  • Seat belt tensioner upper bolt torque: 87 in-lbs. (9.8 N.m)
  • Seat belt tensioner lower bolt torque: 24 ft. lbs. (32 N.m)
  • Steering wheel bolt torque: 28 ft. lbs. (38 N.m)
  • Disposal cooling time: 30 minutes after deployment
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
26808 / Mary Diaz
File Size:
220.38 MB
File Type:
ZIP
Language:
English
Printable:
Yes
Category:
Car
Last updated / verified
May 1, 2025

Acura Manual Features & Content Preview

Air Bag Restraint Systems and Electrical Documentation

  • Covers 2001–2003 Acura 3.2CL Supplemental Restraint System (SRS), including side-impact components, seat belt tensioners, and Occupant Position Detection System (OPDS)
  • Official OEM American Honda Motor Co., Inc. publication for 2001 Acura 3.2CL accessories
  • Contains 38 illustrated figures featuring connector pinouts, component locations, and SRS testing configurations
  • Accessible from your device as soon as the order is placed
  • OCR text layer lets you jump to a torque spec by keyword
  • This 100-page service manual is the verified resource for 2001–2003 Acura 3.2CL passive restraint and cruise control systems

System Coverage and Diagnostics

This Acura 3.2CL service publication details the operation, removal, installation, and inspection of passive restraint systems. The content includes guidance for disabling and enabling the SRS, managing cable reel centering, and deploying air bags for vehicle disposal. The document provides clear direction on working with spring-loaded lock connectors and handling sensitive SRS sensors to maintain safety standards.

Diagnostic content describes retrieval of diagnostic trouble codes (DTCs) using the Honda PGM Tester or the indicator light flashing method. Coverage includes procedures for clearing memory codes, initializing the OPDS unit, and troubleshooting intermittent system failures. The manual lists comprehensive trouble code definitions for SRS unit faults, inflator circuits, and sensor failures.

Technical Data Preview

This Acura 3.2CL service manual presents extensive specification tables, including torque values and wiring diagrams for the SRS and cruise control system. SRS unit initialization is specified at 6 seconds as a system operation check. Mounting torque for air bag assembly bolts is documented at 87 in-lbs. (9.8 N.m). Circuit testing requires a digital multimeter with a maximum output of 10 milliamps. Reference only — always consult a certified technician before performing service on this equipment. An official 100-page Acura 3.2CL OEM service manual covering the 2001–2003 model years, documenting air bag restraint system components, SRS diagnostics, cruise control adjustments, and power seat testing procedures.

Document Reference: Courtesy of AMERICAN HONDA MOTOR CO., INC.

Manual FAQ, Purchase & Download Details

What system areas are included in this air bag restraint systems service manual for the 2001 to 2003 Acura 3.2CL? keyboard_arrow_down

Document covers the Supplemental Restraint System components including the driver-side and passenger-side air bags, side-impact air bags, SRS unit, cable reel, and seat belt tensioners.

Is there graphical documentation showing component locations and assembly breakdowns in the manual? keyboard_arrow_down

Yes, the manual contains numerous diagrams and exploded views, such as those detailing the SRS restraint system components, steering column covers, and individual air bag assemblies. These illustrations are provided to show the layout and connections for the covered restraint systems.

Are there reference sections detailing electrical connection handling, safety precautions, or installation specifications for these components? keyboard_arrow_down

Document includes dedicated sections that list safety precautions for handling air bag systems and technical procedures for the disposal of restraint components. Additionally, the manual references specific connector handling, such as the use of spring-loaded lock connectors, and provides general technical specification references for assembly mounting. These sections serve as a guide for understanding the system requirements without providing repair or diagnostic instructions.
