2010-2011 Suzuki Kizashi Air Bag System Service Manual

Comprehensive service manual covering the 2010-2011 Suzuki Kizashi air bag system, detailing component functions, diagnostic procedures, and wiring diagrams. Part ref: 09932-76010.

4.6starstarstarstarstar_half(5)
Suzuki Car manual preview - 2010-2011 Suzuki Kizashi Air Bag System Service Manual

Purchase & Download

$17.49 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Suzuki Models Covered & Key Technical Specifications

Models: 2010–2011 Suzuki Kizashi
Sub-models / Variants: GTS
Build Years: 2010–2011
Technical Data:

  • Ambient storage temperature: Below 65°C (149°F)
  • Capacitor voltage reference: 27.0–33.0 V
  • Power supply voltage reference: 10–14 V
  • Initiator circuit resistance (standard): 1.0–3.8 ohms
  • Driver air bag 1st stage initiator resistance: 1.0–4.5 ohms
  • Air bag warning light illumination check: 6 seconds
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
29576 / Margaret Moore
File Size:
93.32 MB
File Type:
ZIP
Language:
English
Printable:
Yes
Category:
Car
Last updated / verified
May 26, 2025

Suzuki Manual Features & Content Preview

Suzuki Kizashi SRS System Documentation

  • Covers 2010–2011 Suzuki Kizashi GTS models equipped with the comprehensive supplemental restraint air bag system
  • Official OEM publication for the 2010 Restraints Air Bag System, detailing system diagnostics and circuit routing
  • Contains 40 detailed circuit diagrams, 15 troubleshooting flow charts, and extensive diagnostic code tables ranging from B1011 through B1399
  • Laid out for standard letter and A4 printing
  • Full-text search finds any part number in seconds
  • This 2010 edition serves as the core technical reference for the Kizashi SRS wiring architecture, documenting every sensor, connector, and module pinout for accurate circuit analysis.

Diagnostic Information and Architecture

This 2010 Suzuki Kizashi service manual provides a structured breakdown of the SRS system components, including driver, passenger, side, and curtain air bags, along with seat belt and lap pretensioner activation parameters. The documentation explains the integration of the occupant classification system, pressure pattern sensors, and the side impact sensors that monitor atmospheric pressure changes in the door trim. Detailed wiring circuit diagrams map the main harness, instrument panel harness, and floor harness, identifying all connector locations for the SDM and associated safety modules.

Specification Highlights

The 2010 Suzuki Kizashi SRS manual documents essential operating values and diagnostic thresholds for technicians. Capacitor voltage is documented at 27.0–33.0 V, while system power supply is rated at 10–14 V. Initiator circuit resistance for side air bags and pretensioners is specified at 1.0–3.8 ohms. Driver air bag 1st stage initiator resistance is listed at 1.0–4.5 ohms in the data list. How factory workshop documentation is structured assists in understanding the troubleshooting logic provided for each DTC. Reference to official maintenance manuals is recommended for broader vehicle service. Reference only — always consult a certified technician before performing service on this equipment.

An official 2010 Suzuki Kizashi SRS service publication documenting the air bag restraint system including wiring, connector terminal references, troubleshooting flowcharts, and diagnostic trouble code definitions for the 2010–2011 model year build.

Manual FAQ, Purchase & Download Details

What system components and wiring layouts does this manual show for the 2010 Suzuki Kizashi air bag system? keyboard_arrow_down

Document contains detailed exploded views and component location diagrams for the SRS system, including driver, passenger, side, and curtain air bag inflator modules. It also includes comprehensive wiring circuit diagrams and component identification charts to assist with system understanding.

Is the official Suzuki special tool list included for maintaining the Kizashi electrical connectors? keyboard_arrow_down

Yes, the manual references special tool 09932-76010 for use when conducting continuity checks on the wiring harness to maintain terminal integrity.

Are the terminal arrangements and pinout references for the SDM connector listed in the document? keyboard_arrow_down

Manual provides comprehensive terminal reference tables for G11, L04, and L05 connectors. These tables list each terminal alongside its corresponding circuit, such as impact sensors, seat belt pretensioners, and occupant classification signals. The document also includes visual diagrams that map the layout of these connectors for clear identification.

Which diagnostic trouble codes are referenced within the air bag system manual? keyboard_arrow_down

Documentation references fault codes ranging from DTC B1011 through B1399.

Can I find information regarding the construction and input output logic of the Kizashi air bag system? keyboard_arrow_down

Manual contains a general description chapter that outlines the construction of the entire air bag and occupant classification system. It also includes an input/output table and block diagram showing how the SDM processes signals from various sensors to trigger the appropriate safety components.
