The manual is valid for the following models:
1994 Honda VF 750CR Magna
1995 Honda VF 750CDS Magna Deluxe
1995 Honda VF 750CS Magna
1996 Honda VF 750CDT Magna Deluxe
1996 Honda VF 750CT Magna
1997 Honda VF 750C Magna C2 Magna Deluxe
1998 Honda VF 750C Magna C2 Magna Deluxe
1999 Honda VF 750C Magna C2 Magna Deluxe
2000 Honda VF 750C Magna C2 Magna Deluxe
2001 Honda VF 750C Magna
2002 Honda VF 750C Magna
2003 Honda VF 750C Magna
Engine: 748 cc (45.6 cu in) DOHC 16-valve liquid-cooled 90-degree,
Production/model years: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Manual Language: English
Printable: Yes, all printers
Instant delivery: Download link will appear on the checkout page after your payment is complete.
#
³
"Download the Comprehensive Repair Manual for the 1994-2003 Honda VF750C CD Magna: Your Ultimate Guide to Honda Magna Maintenance and Repair"
If you own a 1994-2003 Honda VF750C CD Magna, this article is your one-stop resource for engine specifications, interesting facts, maintenance guidelines, common issues, tuning tips, available accessories, and owner reviews. Whether you're a motorcycle enthusiast or a DIY mechanic, this detailed repair manual will provide you with all the necessary information to service and repair your Honda Magna, ensuring its optimal performance and longevity.
Engine Specs/Technical Specifications:
• Engine Type: Liquid-cooled, 4-stroke, V4
• Displacement: 748cc
• Bore x Stroke: 70mm x 48.6mm
• Compression Ratio: 10.8:1
• Carburetion: Four 34mm Keihin CV carburetors
• Ignition: Solid-state digital, with electronic advance
• Starter: Electric
• Transmission: 5-speed, constant mesh
• Final Drive: Shaft
• Frame: Steel, double-cradle
• Front Suspension: 41mm telescopic fork, 135mm travel
• Rear Suspension: Dual shocks with adjustable spring preload, 110mm travel
• Front Brake: Dual hydraulic discs, 296mm
• Rear Brake: Single hydraulic disc, 276mm
• Front Tire: 120/80-17
• Rear Tire: 150/80-15
• Fuel Capacity: 12 liters
• Seat Height: Approximately 740mm
• Wheelbase: Approximately 1,595mm
• Dry Weight: Approximately 240kg
Facts and Details:
- The Honda VF750C CD Magna belongs to the popular Honda Magna series, renowned for its powerful V4 engines and distinctive cruiser styling.
- The V4 engine configuration provides a unique combination of smooth power delivery, strong torque, and a captivating exhaust note.
- The Magna features a reliable and low-maintenance shaft drive system, eliminating the need for chain adjustments and lubrication.
- Its comfortable seating position, coupled with a spacious riding position and ergonomic handlebars, make it suitable for long-distance cruising.
- The telescopic front fork and dual rear shocks deliver a balanced suspension setup, ensuring a comfortable and controlled ride.
- Honda's solid-state digital ignition system ensures precise timing and reliable starts for optimal engine performance.
- The Magna's double-cradle steel frame offers stability and rigidity, enhancing both handling and rider confidence.
- Many owners appreciate the ample power and torque produced by the 748cc engine, making it suitable for both city commuting and open-road adventures.
- The Magna's classic cruiser styling, including its chrome accents and sculpted lines, adds a touch of timeless elegance to its overall design.
- The bike's hydraulic disc braking system provides excellent stopping power and inspires confidence during various riding conditions.
- Commonly praised features include the Magna's user-friendly controls, clear instrumentation, and convenient storage options.
- With regular maintenance and proper care, the VF750C CD Magna has been known to provide reliable performance and longevity.
Maintenance Intervals, General Maintenance Tips, and Common Issues:
- Refer to the maintenance schedule outlined in the owner's manual for regular servicing, including oil changes, filter replacements, and valve adjustments.
- Keep the chain properly lubricated and tensioned to ensure smooth power delivery and prevent premature wear.
- Regularly inspect the brake pads and discs for wear, replacing them as necessary for optimal braking performance.
- Common issues may include carburetor tuning, electrical system faults, and occasional oil leaks. Consult the repair manual or seek professional assistance for specific solutions.
Popular Tuning Tips or Modifications:
- Aftermarket exhaust systems: Upgrading to a high-performance exhaust can enhance both the sound and performance of the Magna.
- Air filter upgrades: Installing a high-flow air filter can improve airflow and increase engine responsiveness.
- Suspension upgrades: Upgrading the front fork springs or rear shocks can enhance the bike's handling and comfort.
Available Accessories and Aftermarket Options:
- Windshields and fairings for improved wind protection during highway rides.
- Saddlebags and luggage racks for added storage capacity.
- Custom seats and backrests for enhanced comfort during long rides.
- LED lighting upgrades for improved visibility and aesthetics.
- Chrome accessories and trim pieces to personalize the bike's appearance.
Owner Reviews and Opinions:
Strengths:
- Smooth and powerful V4 engine performance
- Comfortable seating position for long-distance touring
- Reliability and durability
- Classic cruiser styling
- Ample power and torque
Weaknesses:
- Limited ground clearance for aggressive cornering
- Heavyweight can be noticeable at low speeds or during parking maneuvers
Start your Honda repair journey by purchasing the PDF version of the comprehensive service manual. Click the green button to securely buy the Honda service manual through RepairLoader using PayPal.
Upon completing your secure PayPal payment, you will gain instant access to the official Honda OEM shop manual/parts list download link on the checkout page. We will promptly email you all the necessary download information after your payment is successfully processed.
§
Price: 18.99 USD
