Repair your Diesel Engine with the help of this professional electronic PDF download version of the Deutz F2-4L 1011F, BF4L 1011F, F3-4M 1011F, BF4M 1011F service workshop manual / repair guide.
Specs:
The Deutz F2-4L 1011F, BF4L 1011F, F3-4M 1011F, and BF4M 1011F diesel engines were produced from 1980 to 2012.
Models:
F2-4L 1011F
BF4L 1011F
F3-4M 1011F
BF4M 1011F
Manual Language: English
Manual format: PDF / e-book (zip)
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
#
³
Here are the engine specs for the Deutz F2-4L 1011F, BF4L 1011F, F3-4M 1011F, and BF4M 1011F:
F2-4L 1011F:
• Type: Four-stroke, two-cylinder diesel engine with fluid cooling
• Displacement: 1.046 liters (63.8 cubic inches)
• Bore x Stroke: 76mm x 90mm
• Compression Ratio: 22:1
• Power Output: 14.7 kW (19.7 hp) at 2800 rpm
• Torque: 58 Nm at 1800 rpm
• Fuel System: Direct fuel injection with individual pump injectors
• Cooling System: Liquid cooled
• Lubrication System: Forced-feed lubrication with gear pump and oil filter
• Dry Weight: 165 kg (363.8 lbs)
BF4L 1011F:
• Type: Four-stroke, four-cylinder diesel engine with fluid cooling
• Displacement: 3.11 liters (189.7 cubic inches)
• Bore x Stroke: 94mm x 100mm
• Compression Ratio: 21:1
• Power Output: 49 kW (65.8 hp) at 2800 rpm
• Torque: 228 Nm at 1800 rpm
• Fuel System: Direct fuel injection with individual pump injectors
• Cooling System: Liquid cooled
• Lubrication System: Forced-feed lubrication with gear pump and oil filter
• Dry Weight: 280 kg (617.3 lbs)
F3-4M 1011F:
• Type: Four-stroke, three-cylinder diesel engine with fluid cooling
• Displacement: 2.828 liters (172.5 cubic inches)
• Bore x Stroke: 101mm x 126mm
• Compression Ratio: 21:1
• Power Output: 44 kW (59 hp) at 2800 rpm
• Torque: 210 Nm at 1800 rpm
• Fuel System: Direct fuel injection with individual pump injectors
• Cooling System: Liquid cooled
• Lubrication System: Forced-feed lubrication with gear pump and oil filter
• Dry Weight: 230 kg (507.1 lbs)
BF4M 1011F:
• Type: Four-stroke, four-cylinder diesel engine with fluid cooling
• Displacement: 4.038 liters (246.5 cubic inches)
• Bore x Stroke: 101mm x 126mm
• Compression Ratio: 21:1
• Power Output: 67 kW (90 hp) at 2800 rpm
• Torque: 316 Nm at 1800 rpm
• Fuel System: Direct fuel injection with individual pump injectors
• Cooling System: Liquid cooled
• Lubrication System: Forced-feed lubrication with gear pump and oil filter
• Dry Weight: 335 kg (738.5 lbs)
"Complete Diesel Engine Repair Manual for Deutz F2 BF4M 1011F: Buy Now at www.repairloader.com"
A Deutz F2 BF4M 1011F Diesel Engine Repair Manual is an essential tool for anyone who uses diesel engines. Whether you own a diesel engine or work with them in factories, homes, or on farm fields, this repair manual is perfect for you. It covers all the essential knowledge you need to know about maintaining and repairing your engine.
This comprehensive manual provides detailed information on how to take care of different parts of your engine. It explains what each part is, what its function is, and how to maintain it properly. You'll learn not only how to change the oil but also how to clean different parts of your engine. If you need to replace any parts, this manual will give you step-by-step instructions so you can do it yourself.
The manual covers major parts of the engine such as the camshaft, cylinder head, crankshaft, main bearings, alternator, battery, starter motor, driveless roller, radiator, and fans. It also includes instructions on how to use them and easy-to-understand illustrations. Additionally, it has a list of frequently asked questions that answers most common doubts.
The manual also contains important safety precautions that you should follow when handling any engine. It also includes instructions on how to use certain parts of the engine that are used regularly and how to service parts that are frequently used for maintenance and repair.
There are many benefits to using a manual for diesel engines. It provides detailed descriptions of each part, troubleshooting tips, and a list of spare parts and engine oil that are needed. It also contains clear instructions for every step of the process.
This manual can be used in conjunction with the FPR 4 engine scan tool to check the engine scan results of your engine to ensure it is working properly. If you find any issues, this manual has solutions for all engine-related problems, making it easy to fix your diesel engine safely, accurately, and efficiently.
To buy the Deutz F2 BF4M 1011F Diesel Engine Repair Manual, visit www.repairloader.com and click on the "Buy Now" button. After purchasing, you will receive an email with all the download information. Please note that the email may end up in your spam folder, so be sure to check there if you don't see it in your inbox.
