2014 Ford Mustang 3.7L V6 and 5.0L V8 Workshop Manual (P/N W710141, W709865, W710909)

5,007 Pages • 198.23 MB • Instant, Printable PDF

4.5starstarstarstarstar_half(4)
visibility Preview Available
$18.57 Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW

Cards and eligible digital wallets

verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
Stripe

Ford Models Covered & Key Technical Specifications

Models: Mustang

Sub-models / Variants: 2-door coupe, 2-door convertible, GT, Shelby

Model Year: 2014

Serial Numbers: 100001–599999


  • Engine displacement: 3.7L, 5.0L, 5.8L supercharged

  • Engine configuration: 6-cylinder, 8-cylinder

  • Transmission type: 6-speed manual (MT82, TR6060), 6-speed automatic (6R80)

  • Lower ball joint deflection: 0.0–0.3 mm (0–0.012 in)

  • Front camber (all vehicles): -0.75° ± 0.75°

  • Caster (all vehicles): 7.1° ± 0.75°

  • Brake hose bracket bolt torque: 20 Nm (177 lb-in)

  • Strut-to-wheel spindle bolt torque: 225 Nm (166 lb-ft)

  • Stabilizer bar bracket nut torque: 70 Nm (52 lb-ft)

  • Steering gear bolt torque: 115 Nm (85 lb-ft)

Technical Specifications
keyboard_arrow_down
Document Number / Seller:
31856 / Lisa Jones
File Size:
198.23 MB
File Type:
PDF
Language:
English
Pages:
5,007
Printable:
Yes
Category:
Car
Last updated / verified
Sep 4, 2026

Ford Manual Features & Content Preview

  • 2014 Mustang factory workshop coverage: 2-door coupe and convertible, GT, and Shelby VIN series; 3.7L V6, 5.0L V8, and supercharged 5.8L V8 identification; production sequence 100001–599999; 5,007-page PDF.
  • Full internal 3.7L and 5.0L engine repair coverage includes removal and installation, teardown and assembly, cylinder heads, pistons, camshafts, timing drives, lubrication components, seals, and in-vehicle procedures.
  • The 6R80 automatic and MT82 6-speed manual are covered for diagnosis, removal, internal inspection, and assembly. 5.8L-specific clutch procedures are present, but the separately referenced TR6060 Section 308-03B is not included.
  • Front and solid-axle rear suspension chapters cover struts, springs, control arms, hubs, spindles, stabilizer systems, Panhard rod, upper-arm bushing, GT500 shocks, Vehicle Dynamic Suspension, EPAS steering, and alignment work.
  • Brake and wheel sections address two-, four-, and six-piston front brake packages, rear disc and parking brakes, hydraulic bleeding, ABS and stability control, TPMS training, tire-wear diagnosis, Road Force® testing, and runout checks.
  • Electrical and body repair covers climate control, module networks and configuration, PATS key programming, lighting, audio, SRS, convertible-top service, glass adjustment, body sectioning, weld-bonding, corrosion protection, and subframes.
  • Diagnostic support includes DTC and PID charts, pinpoint tests, symptom charts, hydraulic circuits, exploded views, torque tables, pressure-test data, wear limits, adjustment specifications, electrical test values, and Ford special-tool callouts.

Vehicle Identification and Powertrain

The identification section decodes the VIN and Vehicle Certification label for body series, engine, paint, interior trim, axle ratio, transmission, spring, and powertrain calibration. It also lists factory spring codes and the transmission codes for the 6R80, MT82, and Shelby TR6060—useful when separating base, GT, convertible, Shelby, and GT500 parts or procedures.

The 3.7L and 5.0L chapters cover internal engine disassembly and assembly, cylinder-head and piston work, valve train and camshafts, timing components, oil pumps and pans, seals, intake components, and engine support insulators. Engine removal and installation procedures are divided by powertrain where required.

For the 6R80, the manual provides separate early- and late-build teardown and assembly information, clutch-pack and pump work, main-control service, torque-converter diagnosis, fluid procedures, and adaptive drive-cycle testing. MT82 coverage reaches the countershaft, output shaft, synchronizers, shift rails, case, seals, clutch slave cylinder, and shifter components.

Supercharged 5.8L coverage includes supercharger cooling diagnosis, pressure testing, draining, filling, and bleeding; accessory and supercharger drive service; intake-air and engine-control components; exhaust and clutch work; GT500 suspension; and model-specific front subframe procedures. The separately referenced Section 303-01C 5.8L engine-mechanical chapter is not part of this file.

Chassis, Steering, and NVH

Suspension repair procedures address lower arms, stabilizer bars and links, strut and spring assemblies, wheel bearings and hubs, spindles, wheel studs, rear springs and shocks, Panhard rod, lateral stiffener, upper arm, and axle-mounted upper-arm bushing. Alignment material covers camber, caster, toe, ride-height measurement, ball-joint inspection, drift/pull, tire-wear patterns, and wheel/tire runout.

GT500/SVT Vehicle Dynamic Suspension material explains Normal and Sport damper modes, VDM network inputs, valve-solenoid control, DTC diagnosis, component replacement, and configuration programming. The 5.8L front lower-arm procedure identifies engine lifting bracket 303-D087 and support bar 303-F070 for steering-gear bolt access.

NVH diagnosis separates tire-, driveshaft-, engine-, accessory-, and engine-firing-speed vibrations. Road-test routines, symptom charts, the Frequency and RPM Calculations Worksheet, and tool-based isolation methods support fault tracing. Named tools include Electronic Vibration Analyzer 100-F027, EngineEAR 107-R2100, EngineEAR/ChassisEAR 107-R2102, and MTS 4000 analyzer 257-00018.

Two repair traps are especially clear. Disconnecting the EPAS power connector with the ignition on can damage the internal relay or create non-clearable module faults. Rear control-arm, Panhard-rod, upper-arm, and shock fasteners must be finalized at curb height to avoid bushing damage and incorrect clamp load.

Electrical, Body, and Reference Material

Electrical and body sections cover A/C recovery, evacuation, charging, flushing, and leak diagnosis; HS-CAN communication and module configuration; lighting, parking aid, audio, anti-theft, and BCM/SJB fault tracing; SRS depowering and post-deployment inspection; convertible-top alignment and hydraulic bleeding; and structural panel, frame-member, weld-bonding, sectioning, and corrosion-protection repair.

Representative visual references include 6R80 Hydraulic Circuits, Engine Lubrication Components — Exploded View, Disc Brake System — Exploded View, Convertible Top — Exploded View, and Subframe and Components — Exploded View, Front. Related chapters provide component-specific torque tables, approved material and fluid data, pressure-test specifications, wear and deflection limits, adjustment data, electrical test values, and special-tool requirements.

Scope and Safety

The separate Ford Wiring Diagrams publication is not included; electrical pinpoint tests refer to numbered wiring-diagram cells for schematic and connector information. Routine maintenance schedules are directed to the Owner’s Guide rather than reproduced here.

This manual covers repair work involving compressed coil springs, pressurized cooling and A/C systems, SRS components, brake hydraulics, and heavy drivetrain or suspension assemblies. Follow the factory warnings, lift points, support methods, and special-tool requirements before beginning a repair.
