2009 Polaris Sportsman 500 EFI Complete Service Manual

2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 1
2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 1
2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 2
2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 3
2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 4
2009 Polaris Sportsman 500 EFI Complete Service Manual Preview image 5
$18.99 (incl. VAT) - Instant Download
OR

File Specifications

  • File Size: 28.12 MB
  • File Type: PDF
  • Language: English
  • Printable: Yes
  • Estimated Download Time: 0.58 Minutes
verified_user
Lifetime Guarantee
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal & Bitcoin

Models Covered in this Manual

  • 2009 Sportsman 500 H.O.
  • 2009 Sportsman 500 EFI
  • 2009 Sportsman X2 500 EFI
  • 2009 Sportsman Touring 500 EFI

Product Information

2009 Polaris Sportsman 500 EFI Complete Service Manual

Overview

This comprehensive service manual is an essential resource for all 2009 Polaris Sportsman 500 EFI owners and mechanics. With detailed instructions, wiring diagrams, and troubleshooting tips, this manual ensures that you can maintain and repair your ATV effectively. Whether you're performing routine maintenance or complex repairs, this guide has you covered.

What's Inside

  • General Information: Learn about your ATV’s specifications, model details, and safety warnings.
  • Maintenance Procedures: Specific steps for routine checks, cleaner use, and specified service intervals to ensure your ATV runs smoothly.
  • Engine Overhaul: Detailed disassembly and assembly instructions, including crankshaft adjustments, valve adjustments, and pistons.
  • Fuel Injection System: In-depth coverage on diagnosing and repairing the fuel system, including the throttle position sensor (TPS), manifold absolute pressure sensor (MAP), and engine temperature sensor (ECT).
  • Electronics and Wiring: A guide to specialized diagnostic equipment and electrical troubleshooting.
  • Torque Specifications: A quick reference for proper torque values to ensure correct assembly.
  • Diagrams and Exploded Views: Visual aid for easy identification of parts and assembly.

This manual is your go-to guide for keeping your Polaris Sportsman 500 EFI in optimal condition, enhancing its performance and longevity.

Maintenance & Repair

Well-maintained ATVs perform better and offer longer service life. Engage with our step-by-step guides for:

  • Lubrication & fluid changes.
  • Fuel system tests and replacements.
  • Engine diagnostics and repairs.

Whether you’re a seasoned mechanic or a DIY enthusiast, this manual provides the exact guidelines needed to keep your ATV running strong.
