2003 Komatsu PC40MR-2/PC50MR-2 Hydraulic Excavator Operation and Maintenance Manual
Full technical coverage for Komatsu GALEO series excavators including hydraulic systems, engine specifications, and service schedules. Part No. SEAM055301T for models PC40MR-2, PC40MRx-2, PC50MR-2, and PC50MRx-2.
Manual Preview
Sample pages from the 2003 Komatsu PC40MR-2/PC50MR-2 Hydraulic Excavator Operation and Maintenance Manual manual
Purchase & Download
Models Covered & Key Technical Specifications
KOMATSU GALEO PC40MR-2 / PC50MR-2 — 2003 Advanced Systematic Repository | SEAM055301T Series Compendium.
- Calibrated Displacement Data: 2.189 liters (133.5 cu in) is specified as the engine cylinder volume Architecture.
- Measured Power Output: For optimal performance, 29.4 kW (39 hp) at 2,350 rpm represents the maximum rated horsepower Topology.
- Primary Torque Specification: 17.2–21.6 MPa (2,490–2,980 PSI) is rated at peak hydraulic relief pressure Matrix.
- Defined Travel Speed: The track system produces 2.8–4.6 km/h (1.7–2.9 mph) low-to-high speed range Standards.
- Key Swing Rating: For continuous operation, 9.0 rpm maintains the swing bearing velocity Margin.
- Baseline Bucket Capacity: Tank volume delivers 0.14–0.16 m³ (0.18–0.21 cu/yd) depending on configuration Protocol.
Professional Workshop Service Manual & Technical Specifications
Full-Coverage Technical Resource Manual: Komatsu PC40MR-2 and PC50MR-2 Hydraulic Excavator Factory-Standards
Conceptual-Layout: PC40MR-2 (Serial 8001+), PC40MRx-2, PC50MR-2 (Serial 5001+), PC50MRx-2 // Technical-Domain: Hydraulic Excavator Operation and Maintenance Logic // Model-Designation: 29.4 kW (39 HP) Diesel-Engine Equipment with Dual-Speed Travel and Swing Systems.
| Document Section | Coverage Scope | Reference Materials |
|---|---|---|
| Safety Framework | Warning labels, operation protocols, maintenance precautions | ROPS protection information, hazard identification, emergency procedures documented |
| Machine Systems | Engine, hydraulic, travel, swing, work equipment | 4D88E-5X diesel specifications, pressure settings, component diagrams provided |
| Operational Procedures | Starting, steering, loading, unloading, storage | Cold-weather operation data, slope-travel guidelines, parking protocols included |
Documentation sections include operation of swing and arm systems, carry traveling on slopes and uneven terrain, execute attachment combinations with breaker or general equipment, and prepare machines for extended storage in winter or seasonal dormancy. The manual documents baseline inspection procedures for daily work, weekly maintenance checks, and comprehensive service intervals including lubrication points for all rotating components. Verification procedures are included for cooling systems, engine oil levels, hydraulic system pressure, battery electrolyte concentration, and fuel tank sediment drainage. The document includes coverage of replacement intervals for critical filter elements, hydraulic fluid specifications, engine oil viscosity selection according to ambient temperature, and grease composition recommendations.
Special procedures are addressed for opening and closing the tilting floor without engine operation, properly securing the machine during transportation on trailers, and executing the lift procedure using external cranes with proper rigging technique. Repair information is provided for troubleshooting electrical system failures, addressing hydraulic circuit pressure problems, resolving travel speed inconsistencies, and correcting swing mechanism holding brake malfunction. The manual contains specifications for bucket attachment installation, compatibility tables for narrow and standard bucket configurations, guide information for hydraulic breaker operation during demolition activities, and documentation of attachment control pedal operation for crusher and breaker equipment.
Torque specifications are documented for floor-tilt lock bolts to ensure proper reassembly (156.8 to 196 N·m) and final-drive case fastening procedures to maintain service interval reliability. The document provides reference tables for fuel-system bleeding procedures following filter element replacement, guidelines for hydraulic air-removal from pump circuits and work-equipment cylinders, and specifications for antifreeze mixture ratios based on minimum atmospheric temperature prediction in operating regions.
