2007 Dodge Sprinter 2500 / 3500 3.0L V6 BlueTEC or 3.5L V6 Gasoline engine Owner's Manual (P/N C4256-90954)

• Covers 2007 Dodge Sprinter 2500 and 3500 configurations, including both diesel and gasoline engine variants
• Official DaimlerChrysler OEM publication P/N C4256-90954 dated 2007
• Delivers 393 pages of operational data, maintenance schedules, and technical reference material for the NCV2 platform

Vehicle Systems and Operation

Navigating the NCV2 electrical and mechanical systems requires exact factory data. This guide breaks down the cockpit layout and instrument cluster navigation in detail. You will find specific button logics for multi-function steering wheels, which is highly useful when diagnosing driver input errors. It also covers the operation of lighting systems, including front and rear foglamps, along with comfort and suspension seat configurations found in the 2500 and 3500 chassis.

Beyond the cabin, the manual details exterior body components. This includes electric-sliding door programming, partition doors, and rear door opening procedures. Diagnosing security faults gets easier with the provided operational logic for the immobilizer, tow-away protection, and interior motion sensors. Crucially, it maps out the factory intended behaviors for complex safety networks like ABS, BAS, ESP, and ASR.

Technical Data and Maintenance Preview

Knowing the exact fluid capacities and torque specs is what separates a quick turnaround from a costly comeback. Always verify these factory specifications and utilize proper safety gear before lifting the chassis or beginning any heavy line work to avoid serious injury.

Specification Highlights

The reference tables inside outline crucial figures for the 3.0L V6 BlueTEC diesel and 3.5L V6 gas architectures. Expect to find precise capacity lists, such as the 13.21 US qt requirement for the 3.0L engine oil and the 10.5 US qt coolant system fill rate.

Electrical and chassis specs are clearly defined. The factory battery rating sits at 12 V and 100 Ah. For suspension work, the wheel bolt torque is explicitly stated at 177 lb-ft (240 Nm). Tire inflation values are also mapped out, ranging from 46 to 70 psi depending on your current payload conditions.
