2009 Arctic Cat Bearcat, Crossfire, F1000, F8, F5, F570, M1000, M8, Sno Pro, TZ1, T500, T570, Z1 snowmobile repair manual

Includes the following models

  • Bearcat Z1 XT - Engine: 1056 cc, 4-stroke, liquid-cooled, twin; 48 mm dual throttle body, electronic fuel injection,
  • Bearcat 570 (XT)
  • Crossfire 1000
  • Crossfire 1000 Sno Pro (LE)
  • Crossfire R 1000 (LE)
  • Crossfire 8
  • Crossfire 8 Sno Pro (LE)
  • Crossfire R 8 (LE)
  • Crossfire 6
  • Crossfire 5
  • F1000 Sno Pro
  • F8 (LE)
  • F8 LXR
  • F8 Sno Pro
  • F6 Sno Pro
  • F5
  • F5 LXR
  • F570
  • M1000 162
  • M1000 153
  • M1000 Sno Pro 162 (LE)
  • M1000 Sno Pro 153
  • M8 162
  • M8 162 Sno Pro
  • M8 153
  • M8 153 HCR
  • M8 153 Sno Pro
  • M8 Sno Pro 153 (LE)
  • M6 153
  • Sno Pro 120
  • T Z1
  • T Z1 LXR
  • T Z1 Turbo LE
  • T Z1 Turbo Touring LXR
  • T500
  • T570
  • Z1
  • Z1 LXR
  • Z1 Turbo (LE)
  • Z1 Turbo LXR
  • Z1 Turbo Sno Pro

Production/model years: 2009

File specifications

File size: 143.38 MB
File type: PDF
Language: English

Printable: Yes
Estimated download time: 2.94 Minutes
$17.99 Instant Download

Product Information

Table of Contents:

General Specifications
Snowmobile Identification
Recommended Gasoline and Oil
Break-In Procedure
Genuine Parts
High Altitude Operation
Drive Chain Lubrication (120 cc)
Low Oil Pressure Warning Light (1100 cc)
Preparation For Storage
Preparation After Storage
After Break-In Checkup (100 Miles - 2-Stroke/600 Miles - 4-Stroke)
After Break-In Checkup Checklist
Engine Specifications (2-Stroke)
Engine Specifications (4-Stroke)
Cylinder Head Volume Specifications (2-Stroke)
Engine Piston Travel Versus Crank Angle Chart (2-Stroke)
Crankshaft Runout/Repair Specifications (2-Stroke)
Fraction/Decimal Conversions
MM/IN. Conversions
Torque Conversions (ft-lb/N-m)
Tightening Torque (General Bolts)
Assembly Schematics/Torque Specifications (Table of Contents)
Engine Torque Patterns (1100 cc)
Arctic Power Valve (APV) System Specifications (2-Stroke)
Oil Consumption Specifications (2-Stroke)
EFI Specifications
Throttle Valve Angle Specifications
Fuel Pump Specifications (570 cc)
Carburetor Specifications
Electrical Specifications
Ignition Timing Specifications (2-Stroke)
Steering/Body Torque Specifications
Drive System Specifications
Drive Clutch/Driven Pulley-Related Specifications
Arctic Cat Drive Belt Dimensions
Drive System Components
Gear Case Performance Calibrations
Drive System Torque Specifications
Rear Suspension Torque Specifications
Track Warranty Guidelines
Track Specifications
Front Suspension Specifications
Rear Suspension Specifications
Shock Absorber Specifications
Idler Wheel Dimensions
