1996–2004 Honda XR250R Factory Service Manual (OEM)

277 Pages • 59.22 MB • Instant, Printable PDF

4.7starstarstarstarstar_half(3)
visibility Preview Available
$18.90 Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW

Cards and eligible digital wallets

verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
Stripe

Honda Models Covered & Key Technical Specifications

Models: XR250R

Modell Years: 1996–2004 (1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004)

Technical Data:

  • Engine type: Air cooled, 4-stroke, SOHC, single cylinder inclined 15°

  • Displacement: 249 cc (15.2 cu-in)

  • Bore x Stroke: 73.0 x 59.5 mm (2.87 x 2.34 in)

  • Compression Ratio: 10.2:1

  • Transmission: 6-speed, left foot operated return system

  • Clutch: Multi-plate, wet type

  • Ignition system: CDI (Capacitive Discharge Ignition)

  • Lubrication system: Forced pressure dry sump

Technical Specifications
keyboard_arrow_down
Document Number / Seller:
27844 / Walter Lee
File Size:
59.22 MB
File Type:
PDF
Language:
English
Pages:
277
Printable:
Yes
Category:
Motorcycle
Last updated / verified
Aug 24, 2026

Honda Manual Features & Content Preview

  • Honda Service Manual: Covers the 1996–2004 Honda XR250R in a 277-page PDF. The publication is organized into 18 service and troubleshooting sections plus the Section 19 index, with dedicated coverage for engine, chassis, suspension, brakes, electrical diagnosis, and the wiring diagram.
  • Model-Year and California Differences: The fuel-system data distinguishes 1996–97, post-1997 non-California, and post-1997 California configurations. PDG1A carburetors use a #132 main jet, while the post-1997 California PDG1C specification uses #122; the manual also separates the applicable pilot-screw procedures and California emission-control information.
  • Repair Scope Made Clear: Oil pump, cylinder head/valves, cylinder/piston, clutch/kickstarter/gearshift linkage, and alternator work can be performed with the engine in the frame. Crankshaft/balancer and transmission/shift-fork/shift-drum repair requires engine removal, and the lower-end sections call for crankcase separation.

Mechanical System Documentation

This technical reference covers the air-cooled 249cc four-stroke SOHC single, including the 73.0 x 59.5 mm bore and stroke, 10.2:1 compression ratio, four-valve chain-driven valvetrain, forced-pressure dry-sump lubrication, and trochoid oil pump. The drivetrain uses a cable-operated wet multi-plate clutch and 6-speed transmission. Chassis coverage includes the telescopic fork, Pro-Link rear suspension with a reservoir-type nitrogen damper, and hydraulic single-disc brakes front and rear.

Factory repair procedures extend well beyond routine maintenance. The manual covers cylinder-head and camshaft service, valve-guide replacement and valve-seat refacing, piston/cylinder inspection, carburetor disassembly and calibration, oil-pump overhaul, clutch and kickstarter repair, flywheel and stator service, crankcase splitting, crankshaft/balancer work, transmission inspection and assembly, fork overhaul, rear-shock bladder and damper service, brake caliper/master-cylinder rebuilding, and electrical fault finding. Because several of these jobs involve gasoline, hydraulic brakes, heavy engine handling, or a nitrogen-charged shock, the specified shop support, pressure-control practices, and service tools matter.

Model-Year Calibration and Service Differences

The carburetor section is one of the strongest year-specific areas. It identifies PDG1A for 1996–97 and post-1997 non-California models, versus PDG1C for post-1997 California models. The manual separates the 1996–97 “Best Idle Procedure” from the post-1997 “Idle Drop Procedure,” and gives different California/non-California pilot-screw settings. A Temperature and Altitude Adjustment chart provides the correction factor used when jetting must be changed for operating conditions. The clutch/primary-drive section also calls out 1996–97-specific oil-pump drive-gear alignment, so the repair data does not treat all years as mechanically identical.

Engine and Chassis Specifications

  • Cylinder compression is 637–735 kPa (92–107 psi) with the decompressor effective and 1,177–1,275 kPa (171–185 psi) with it not effective. Intake valve clearance is 0.10 ± 0.02 mm; exhaust is 0.12 ± 0.02 mm.
  • Dry-sump engine-oil capacity is 1.3 L at draining, 1.4 L with filter replacement, and 1.7 L after disassembly. Front-fork data specifies Pro Honda Suspension Fluid SS-7 or equivalent, a 477 cm³ oil capacity, and an 82 mm standard oil level. Rear-damper charge is 981 kPa (142 psi) nitrogen.
  • Wear data includes a 73.11 mm cylinder I.D. service limit; piston-ring end-gap limits of 0.40 mm top, 0.55 mm second, and 0.86 mm oil rail; a 2.69 mm clutch-disc thickness limit; 0.30 mm clutch-plate warpage limit; and brake-disc thickness limits of 2.5 mm front and 4.0 mm rear.

Electrical Diagnostics, Tools, and Reference Views

Electrical diagnosis covers the ICM/CDI ignition, ignition coil, exciter coil, ignition pulse generator, alternator lighting coil, AC regulator, engine stop switch, headlight, and taillight. Useful test thresholds include 100 V minimum for ignition-coil primary and exciter-coil peak voltage, 0.7 V minimum for the ignition pulse generator, and 12.0–14.0 V AC-regulator output at 3,000 rpm. Honda specifies an Imrie Model 625 tester or peak-voltage adapter 07HGJ-0020100 with a 10 MΩ/DCV minimum digital multimeter.

Special-tool coverage is equally specific: carburetor float-level gauge 07401-0010000, valve-spring compressor 07757-0010000, fork-rod holder 07PMB-KZ40101, and clutch-center holder 07923-KE10000 are all identified by number. Reference material includes Cable & Harness Routing, Lubrication & Seal Points, Temperature and Altitude Adjustment, Transmission Assembly/Installation, the Damper Assembly exploded view, and the full Wiring Diagram 0030Z-KCE-0000.

Repair Notes That Matter

The manual warns that installing the oil filter backward can cause severe engine damage. Hard-seating the carburetor pilot screw can damage its seat, and burrs left in the rear-shock stopper-ring groove can damage the damper-rod piston ring. These details are easy to miss during repair work and are exactly the kind of assembly-specific cautions that generic maintenance information does not supply.

Scope note: the service manual refers the pre-ride inspection and detailed rider-specific rear-shock preload/damping setup to the Owner’s Manual. Those owner-level setup instructions are therefore outside this publication’s main repair scope.
