1981–1993 John Deere 316, 318 & 420 Lawn and Garden Tractor Service and Engine Repair Manual Set (P/N TM1590, CTM2)

665 Pages • 1 Printable PDF (English) • Download

4.5starstarstarstarstar_half(2)
$23.75 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

John Deere Models Covered & Key Technical Specifications

Models: 316, 318, 420

Sub-models / Variants: One-Speed Differential (316, 318), Two-Speed Differential with Differential Lock (420), Early Model (316: Onan B43E; 318: Onan B43G; 420: Onan B48G, Spec A/Spec B/Spec C), Later Model (316/318: Onan P218G, Spec A/Spec B/Spec C; 420: Onan P220G, Spec A/Spec B/Spec C)

Model Years: 1981–1993 (1981, 1982, 1983, 1984, 1985, 1986, 1987 1988, 1989, 1990, 1991, 1992, 1993)

Serial Numbers: Starter-system breaks: 316 (S.N. —362983, 362984—), 318 (S.N. —364137, 364138—), 420 (S.N. —360009, 360010—); ignition-system break (all models): breaker points (S.N. —420000), electronic ignition (S.N. 420001—); brake-switch interlock: not fitted on 316 (S.N. —596120), 318 (S.N. —600304), 420 (S.N. —595880), fitted on 316 (S.N. 596121—), 318 (S.N. 600305—), 420 (S.N. 595881—); fuse configuration: tubular fuses on 316/318 (S.N. —475000) and 420 (S.N. —595880), blade fuses on 316/318 (S.N. 475001—) and 420 (S.N. 595881—); wiring, grounding and lighting/PTO connector changes (all models): S.N. —475000, 475001—; adjustable starter-bracket applications in CTM2: 318 (S.N. —231,857), 420 (S.N. —224, 882)


  • Engine: Onan Gasoline, 2-Cylinder, Horizontal, 4-Cycle

  • Engine Displacement: 710 cm³ (43.3 cu in.) to 782 cm³ (47.7 cu in.)

  • Horsepower: 11.9 kW (16 hp) to 14.9 kW (20 hp)

  • Transmission Type: Hydrostatic (316/318), Hydrostatic 2-Range (420)

  • Fuel Type: Gasoline (85 Octane Unleaded)

  • Transmission Capacity: 6.1 L (13 U.S. pt) to 7.1 L (15 U.S. pt)

  • Steering: Manual (316), Power Hydrostatic (318/420)

John Deere Manual Features & Selected Content Preview

Publication Pages
John Deere 316, 318 and 420 Lawn and Garden Tractors Technical Manual — P/N TM1590, May 17, 1995; tractor repair and diagnosis for the listed 1981–1993 models 440
John Deere 16, 18, 20 and 24HP Onan Engines Component Technical Manual — P/N CTM2, April 19, 1990; engine repair procedures and application chart 224

TM1590 provides tractor-level diagnosis and engine removal instructions; CTM2 supplies the internal engine repair procedures it calls for. Use the two publications together for engine overhaul.

Some tractor versions may not be covered by this edition; match the documented configuration and serial breaks to your machine.

PDF Search, Bookmarks and Diagram Detail

Search and schematic detail: Service text in both publications is searchable, but labels embedded in wiring and hydraulic schematic images are not. Small schematic labels require zooming. Section and group bookmarks cover both publications; the Contents entry and top-level CTM2 bookmark have faulty destinations.

Both publications are combined in one printable, English-language PDF with 665 pages. This total includes one additional introductory page, the publications’ covers and blank pages, and 14 repeated schematic pages within the tractor manual.


Tractor Systems and Onan Engine Repair

These selected coverage highlights outline the main workshop areas. Further topics include fuel-transfer-pump testing and service recommendations for O-ring hydraulic fittings.

  • Engine repair: Engine removal and installation, internal overhaul, valve and bearing inspection, carburetor service, and compression, crankcase-vacuum, and oil-pressure tests.

  • Hydrostatic drive: Charge-pump and transmission overhaul, differential and rear-axle repair, drive-shaft removal, pressure and flow testing, and neutral-linkage adjustments.

  • Steering and brakes: Manual steering gearbox overhaul, power-steering valve repair and leakage tests, shoe-and-drum brake adjustments, and parking-brake service.

  • Hydraulic system: Single-, two-, and three-spool control-valve repair, rockshaft-cylinder leakage tests, hydraulic schematics, float operation, and system bleeding.

  • Electrical diagnosis: Single- and dual-PTO wiring diagrams, starting and charging tests, ignition and seat-switch interlock diagnosis, and front PTO clutch service.

  • Mowers and front axle: Mower gear-case rebuilds, blade-spindle and jack-sheave service, axle-pivot and spindle-bushing replacement, wheel-bearing inspection, and toe-in adjustment.

Both publications were written for experienced service technicians and identify the special tools required for the work.

Onan Engine Overhaul

CTM2 provides step-by-step instructions for engine teardown and assembly, including cylinder heads, valve seats and guides, tappets, camshafts, pistons, connecting rods, and crankshaft main bearings. Inspection limits accompany the component checks.

Fuel and lubrication coverage extends to governor overhaul, carburetor cleaning and float adjustment, oil-pump repair, and oil-pressure regulating-valve inspection.

The crankshaft section explains how forcing the bearing plate inward with its screws can damage the lock pins, thrust washer, or crankshaft.

Hydrostatic Transmission and Differential Variants

The transmission sections cover the pump, motor, and swashplate, with diagnostic paths for loss of drive, neutral creep, overheating, and repeated charge-pump seal failures. Pressure and flow tests connect these symptoms with component inspections.

Four transmission-control linkage versions are illustrated separately. Differential coverage distinguishes early flat thrust washers from later tabbed washers and explains the revised frame support used to address differential-gasket leakage.

Steering, Brakes and Hydraulic Controls

The 316 steering gearbox procedures include worm-bearing and over-center preload checks. Power-steering coverage distinguishes four-port and five-port valves, with fabrication drawings for the DFMX1 Steering Valve Fixture and DFMX2 Alignment Shims.

Separate system and valve leakage tests help distinguish a steering-cylinder fault from internal valve leakage before selecting a repair. The steering cylinder is replaced as a complete assembly.

Control-valve repair distinguishes five two-spool versions and four three-spool versions. The Early 318 Hydraulic System Schematic and Later 420 Hydraulic System Schematic illustrate the different routing associated with four-port and five-port steering.

Brake sections distinguish the model-specific pedal and neutral-return linkages, including service, parking, and individual turning-brake checks.

Electrical Circuits and PTO Components

The Single PTO Electrical Schematic, Dual PTO Electrical Schematic, and Electrical Component Location views support circuit tracing and component identification. Diagnostic branches distinguish breaker-point and electronic ignition, brake-switch interlocks, fuse configurations, and harness-grounding changes.

Engine electrical repair includes Bendix-drive and solenoid-drive starter overhaul, stator and rectifier-regulator replacement, and ignition-module service. Front PTO clutch coverage includes field-coil checks, bearing work, and armature-clearance adjustment.

Mower Gear Cases and Workshop References

Gear-case procedures distinguish the 50-inch mower, early 60-inch Curtis, later 60-inch Peerless, and 260 Rotary Mower. Spindle and jack-sheave sections identify the applicable early and later deck arrangements.

The 50-inch gear-case section addresses crush-ring replacement and warns that overtightening the input-shaft locknut can damage the bearing cone.

Metric-series, inch-series, and set-screw torque charts supplement component torque specifications, fluid capacities, pressure-test data, electrical test values, and wear limits.

Working on pressurized hydraulics and heavy tractor powertrains carries inherent physical risks. Follow the manual’s precautions for hydraulic pressure and supporting raised machinery.

Sample PTO Clearance and Crankshaft End-Play Specifications

The front PTO clutch section specifies an armature-to-rotor clearance of 0.46 mm (0.018 in.), alongside its inspection and adjustment instructions.

For B43E, B43G, B48G, P218G, and P220G engines, CTM2 specifies crankshaft end play of 0.15–0.30 mm (0.006–0.012 in.). The accompanying bearing-plate section covers the related measurement and shim selection.
