To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years.
The following models are encompassed by this manual: 4475, 5575, 6675, 7775, Series 220 / Deere & Company / John Deere
John Deere 4475 Skid Steer Loader
John Deere 5575 Skid Steer Loader
John Deere 6675 Skid Steer Loader
John Deere 7775 Skid Steer Loader
Serial Numbers:
For the 4475 model: From 010001 to 039999
For the 5575 model: From 020001 to 029999
For the 6675 model: From 010001 to 039999
For the 7775 model: From 020001 to 029999
Engine 4475 specs: 91.3cu in, 4 cylinders, Gross Power 32hp, Net Power 31hp, 3000rpm
Engine 5575 specs: 3017D001, 100.1 cu in, 3 cylinders, 39 hp (29 kw), 3000 rpm.
Engine 6675 specs: Series 220, 121.7cu in, 4 cylinders, Gross Power 45hp, Net Power 42hp, 3000rpm.
Engine 7775 specs: Series 220, 133.5cu in, 4 cylinders, 52hp, 49hp.
Publication number: TM-1553
Manual Language: English
Pages: 433
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
#
³
"Download John Deere 4475, 5575, 6675, 7775 Skid Steer Loader Manual/Parts Catalog in PDF Format for Easy Maintenance and Repair"
Whether you're an experienced mechanic or a novice, having access to a reliable repair manual can make a big difference when it comes to maintaining and repairing your John Deere 4475, 5575, 6675, and 7775 skid steer loaders. In this article, we will provide you with a list of 30 engine specifications and technical information, as well as some interesting facts and details about these machines.
Engine Specifications/Technical Specs:
• Engine: John Deere 3029T
• Gross power: 49 hp
• Net power: 46 hp
• Displacement: 179 cu. in.
• Operating weight: 6,300-7,600 lbs.
• Loader capacity: 1,500-2,150 lbs.
• Tipping load: 3,000-4,300 lbs.
• Hydraulic pump flow: 15.1-20.1 gpm
• Fuel capacity: 17.7-24.6 gal.
• Length with bucket: 10.2-10.6 ft.
• Width over tires: 5.7-6.1 ft.
• Height to top of cab: 6.5-6.7 ft.
• Ground clearance: 7.5-9.5 in.
• Maximum speed: 7.3-7.5 mph
• Travel speed: 7.3-7.5 mph
• Operating pressure: 3,000 psi
• Hydraulic system capacity: 7.9-10.1 gal.
• Turning radius from center machine: 79.1-82.1 in.
• Wheelbase: 4.2-4.6 ft.
• Bucket hinge pin height: 9.2-10.4 ft.
• Breakout force: 4,000-4,450 lbs.
• Dump clearance at full height: 7.2-8.2 ft.
• Dump reach at full height: 23.2-26.2 in.
• Rollback angle: 30 degrees
• Maximum reach: 29.5-34.7 in.
• Max. dump angle: 42 degrees
• Max. dump height: 8.7-9.2 ft.
• Max. dump reach: 22.5-26.5 in.
• Max. roll back angle: 87 degrees
• Max. hinge pin height: 10.7-11.8 ft.
The John Deere 4475, 5575, 6675, and 7775 skid steer loaders are designed to be powerful, versatile, and easy to operate. They are ideal for a wide range of applications, from construction and landscaping to agriculture and material handling. With a comfortable operator station, advanced hydraulics, and a variety of attachments available, these machines can help you get the job done quickly and efficiently.
The John Deere 4475, 5575, 6675, and 7775 are popular skid steer loaders used in various industries. Here's the information you requested:
Maintenance Intervals and Tips:
Follow the manufacturer's recommended maintenance schedule, which typically includes regular inspections, lubrication, and component replacement at specified intervals.
* Change the engine oil and replace the oil filter every 250 hours or as recommended by John Deere.
* Clean or replace the air filter regularly to maintain optimal engine performance.
* Check and maintain proper coolant levels and inspect the cooling system for leaks or damage.
* Inspect and adjust the drive chains or tracks for proper tension and alignment.
* Regularly inspect and clean the hydraulic system, including filters, lines, and connections.
* Keep the machine clean of debris and mud to prevent clogging and damage to components.
* Check and maintain proper tire pressure for optimum performance and traction.
* Lubricate all grease fittings, pivot points, and linkage points according to the manufacturer's guidelines.
* Store the skid steer loader in a dry and secure location when not in use.
Common Issues and Solutions:
While the John Deere skid steer loaders are generally reliable, some common issues that may arise include:
- Hydraulic leaks: Inspect the hydraulic system regularly for leaks, paying attention to hoses, fittings, and cylinders. Repair or replace any damaged or leaking components.
- Electrical problems: Faulty switches, wiring issues, or blown fuses can cause electrical malfunctions. Inspect the electrical system, replace faulty components, and ensure proper wiring connections.
- Drive system issues: If the skid steer loader experiences issues with drive power or control, it may be due to problems with the drive chains, tracks, or drive motors. Inspect and maintain these components, adjusting tension and replacing worn parts as necessary.
- Cooling system overheating: Monitor the coolant levels and inspect the cooling system for leaks or blockages. Clean the radiator and ensure proper airflow to prevent overheating.
- Engine starting or performance issues: Starting problems or decreased engine performance can be caused by issues such as a weak battery, clogged fuel filters, or problems with fuel delivery. Check the battery charge, replace clogged filters, and inspect the fuel system for any issues.
Tuning Tips and Modifications:
Tuning and modifications for these skid steer loaders are typically limited, as they are designed for specific applications. However, some popular options include:
1.Upgrading to heavy-duty tires for improved traction and durability in challenging conditions.
2. Installing auxiliary lights for better visibility in low-light environments.
3. Adding a backup camera or sensor system to enhance safety during operation.
4. Upgrading the seat to a more comfortable and ergonomic option for operators.
Available Accessories and Aftermarket Options:
John Deere offers various accessories and aftermarket options for these skid steer loaders, including:
+ Various types of buckets and attachments for specific tasks, such as pallet forks, grapples, and augers.
+ Cab enclosures and heating systems for operator comfort in extreme weather conditions.
+ Hydraulic quick couplers for easy attachment changes.
+ Fire extinguisher mounts and other safety equipment.
+ Rubber track options for increased traction and reduced ground disturbance.
Owner Reviews and Opinions:
Owners of the John Deere skid steer loaders appreciate their durability, versatility, and ease of use. Strengths commonly mentioned include the reliable performance, robust construction, and the availability of a wide range of attachments. However, some owners note that these loaders may have limited visibility from the operator's seat, and the controls can take time to become accustomed to. Overall, these loaders are valued for their productivity and ability to handle various tasks.
Repairs Needing Frequent Attention:
The repairs that may need to be carried out most frequently on these skid steer loaders can vary based on usage, maintenance practices, and operating conditions. However, some components that may require attention include:
■ Hydraulic hoses and fittings.
■ Drive chains or tracks.
■ Filters (air, fuel, hydraulic).
■ Electrical switches and wiring.
■ Cooling system components.
To buy the OEM John Deere repair guide for the 4475, 5575, 6675, and 7775 skid steer loaders, simply go to www.repairloader.com and use PayPal to complete your purchase. After your payment is processed, you will be able to instantly download the necessary information. Within a minute of completing your payment through PayPal on www.repairloader.com, you will receive an email containing all the necessary download information for your original John Deere repair guide. The checkout page will also display the download link after your payment is processed. Please ensure to download and save the manual within three days.
§
