Models Covered & Key Technical Specifications

Infiniti G35 Coupe (2005) Automatic Transmission Service Manual | Repair Data

  • Measured Electrical Specs: 4.3 Nm (39 - 52 in-lb) -- Tighten accelerator pedal assembly.
  • Established Torque Specs: 34 N·m (3.5 kg-m, 25 ft-lb) -- Drain plug.
  • Factory Capacities: 10.3 L (10-7/8 US qt, 9-1/8 Imp qt) -- Genuine Nissan Matic J ATF.
  • Approved Clearances: 47 mm (1.85 in) dia. -- Drift for installing oil pump housing oil seal.
  • Reference Dimensions: 60 mm (2.36 in) dia. -- Drift for installing rear oil seal.
  • Critical Measurements: 5.1 N·m (0.52 kg-m, 45 in-lb) -- Tighten level gauge bolt.

Manual Description & Preview

Automatic Transmission (AT) Manual: Infiniti G35 Coupe manual Procedure-Database

Model-Type: V35 Series // Documentation-Type: Service Manual Logic // Series-Validation: 2005 Infiniti G35 Coupe.

TABLE TOP

Performance-Element Technical-Path Logic
Model Variant Automatic Transmission V35 Series
Transmission Type AT Automatic
Year Range 2005 Vehicle Specfic
Control Module TCM Transmission Control
Primary Function Shift Control Line Pressure Control
System Interface CAN Communication Diagnosis Support

Service sections detail the automatic transmission's construction, shift mechanism, clutch and band charts, and power transmission configurations. Efficiently requiring detailed system procedures for optimal performance. Specialized diagnostic troubleshooting guides cover common issues and DTCs for the AT system. Specific troubleshooting procedures for various DTCs including U1000 CAN Communication Line, P0700 TCM, P0705 Park/Neutral Position Switch, and P0720 Vehicle Speed Sensor. The manual documents torque specifications for the TCM to ensure proper thermal expansion compensation.

FAQ

Is the 2005 Infiniti G35 Coupe automatic transmission service manual available in a downloadable format? keyboard_arrow_down

Yes, this service manual is provided as a downloadable PDF document, allowing for convenient access on various devices.

Does the manual include specific fluid capacity references for the automatic transmission? keyboard_arrow_down

Yes, the document contains a section listing fluid capacities for the automatic transmission, along with specifications for the recommended Genuine Nissan Matic J ATF.

Are there reference values provided for the TCM input and output signals in the electrical sections? keyboard_arrow_down

Manual includes a dedicated inspection table for the transmission control module that lists terminal pinouts, wire colors, and reference voltage values for various connector states.

Does the document contain diagnostic information related to automatic transmission trouble codes? keyboard_arrow_down

Includes comprehensive sections on the on-board diagnostic system, listing both DTC and 1st trip diagnostic trouble codes, along with priority charts for system inspections.

Can I find information regarding the automatic transmission clutch and band operating conditions in the manual? keyboard_arrow_down

Transmission control system chapters include a detailed clutch and band chart that shows which components operate during specific gear positions, from P and N through all drive ranges.
