1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 1
1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 2
1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 3
1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 4
1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 5
1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual Preview image 6

1973-1989 Johnson Evinrude 48hp -235hp outboard motor/sea drives shop manual

Models covered in this manual:

Evinrude/Johnson

- 48 hp
- 50 hp
- 55 hp
- 60 hp
- 65 hp
- 70 hp
- 75 hp
- 85 hp
- 88 hp
- 90 hp
- 100 hp
- 110 hp
- 115 hp
- 120 hp
- 140 hp
- 150 hp
- 175 hp
- 185 hp
- 200 hp
- 235 hp

Production/model years: 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989

File specifications

File size: 157.38 MB
File type: PDF
Language: English

Printable: Yes
Estimated download time: 3.22 Minutes
$13.99 Instant Download

Pay with Bitcoin

Product Information

Table of Contents

QUICK REFERENCE DATA

CHAPTER ONE

  • General Information
    • Model designation
    • Serial number and warranty
    • Standard dimensions and torque
    • Fasteners
    • Propellers
    • Capacities
    • Fuels, lubricants, and service products
    • Engine oil
    • Fuel mix
    • Storage and corrosion protection
    • Propellers (continued)
    • Explosions, fires, and poisonous emissions

CHAPTER TWO

  • Tools and Techniques
    • Special tools
    • Engine lifting
    • Cleaning
    • Measurements and techniques

CHAPTER THREE

  • Troubleshooting
    • Operating problems
    • Compression testing
    • Fuel system troubleshooting
    • Electrical system troubleshooting
    • Ignition system troubleshooting
    • Cooling system troubleshooting
    • Starting and charging system troubleshooting
    • Engine mechanical troubleshooting
    • Troubleshooting summary

CHAPTER FOUR

  • Adjustments, Repair, and Overhaul
    • Engine cover removal and installation
    • Powerhead removal and installation
    • Cylinder head removal and installation
    • Powerhead disassembly
    • Powerhead cleaning and inspection
    • Crankshaft and piston removal and installation
    • Cylinder block and crankcase
    • Cylinder block assembly
    • Cylinder block installation
    • Powerhead assembly and installation

CHAPTER FIVE

  • Fuel System
    • Fuel system components
    • Fuel pump service
    • Carburetor service and adjustment
    • Fuel system cleaning and inspection
    • Fuel tank and lines

CHAPTER SIX

  • Ignition and Electrical Systems
    • Ignition system components
    • Ignition system service and adjustment
    • Charging system components
    • Charging system service and adjustment
    • Electrical system troubleshooting
    • Battery service and maintenance

CHAPTER SEVEN

  • Cooling System
    • Cooling system components
    • Water pump service
    • Thermostat service and adjustment
    • Cooling system cleaning and inspection

CHAPTER EIGHT

  • Powerhead
    • Powerhead components
    • Powerhead service and adjustment
    • Powerhead cleaning and inspection

CHAPTER NINE

  • Lower Unit
    • Lower unit components
    • Lower unit service and adjustment
    • Lower unit cleaning and inspection
    • Lower unit disassembly and reassembly

CHAPTER TEN

  • Tilt and Trim
    • Tilt and trim components
    • Tilt and trim service and adjustment
    • Tilt and trim cleaning and inspection

CHAPTER ELEVEN

  • Remote Control
    • Remote control components
    • Remote control service and adjustment
    • Remote control cleaning and inspection

APPENDIX

  • Wiring Diagrams
  • Service Specifications
  • Conversion Tables
  • Index
