Revitalize your 1-cylinder or 2-cylinder, 2-stroke outboard engine with our Johnson Evinrude Service Manual and Repair Guide for 1.5 hp to 40 hp models.
Specs:
Production/model years: 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970
This manual applies to the following models:
1.5 Hp
3.0 Hp
4.0 Hp
5.0 Hp
5.5 Hp
6.0 Hp
7.5 Hp
9.5 Hp
10 Hp
15 Hp
18 Hp
20 Hp
25 Hp
28 Hp
30 Hp
33 Hp
35 Hp
40 Hp
1.5 HP (CD Series)
3 HP (CD Series)
4 HP (CD Series)
5.5 HP (CD Series)
6 HP (CD Series)
7.5 HP (CD Series)
10 HP (QD Series)
15 HP (QD Series)
18 HP (FD Series)
20 HP (QD Series)
25 HP (RD Series)
28 HP (FD Series)
33 HP (RD Series)
35 HP (RD Series)
40 HP (RD Series)
Manual Language: English
Manual format: PDF / e-book (zip)
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
#
³
"Revive Your Classic Johnson Evinrude Outboard Engine: Instantly Download the Manual, Parts List, and Maintenance Tips at RepairLoader.com"
If you own a classic Johnson Evinrude outboard engine built between 1956 and 1970, you know how important it is to keep it in excellent condition. To help you do just that, we offer a comprehensive manual, parts list, and maintenance tips, all available for instant download at RepairLoader.com. Our materials cover Johnson Evinrude outboard engines ranging from 1.5 hp to 40 hp models.
Here are 15 technical specifications for the 1956-1970 Johnson Evinrude outboard engine:
• The engines have a 2-stroke, 1-cylinder or 2-cylinder configuration.
• The horsepower ranges from 1.5 hp to 40 hp depending on the model.
• The engines feature a manual recoil starter.
• The ignition system includes a spark plug and distributor.
• The engines have a propeller made of aluminum or stainless steel, depending on the model.
• The fuel tank capacity ranges from 1.2 gallons to 6 gallons depending on the model.
• The engines have a dry weight ranging from 32 pounds to 188 pounds.
• The engines feature a water-cooled cooling system.
• The oil capacity ranges from 0.3 to 2 quarts depending on the model.
• The engines have a maximum RPM range between 4,000 and 5,500.
• The gear ratio ranges from 1.3:1 to 2.6:1 depending on the model.
• The engines feature a manual tilt method.
• The engines have a bore and stroke ranging from 1.4375 x 1.25 inches to 2.625 x 2.75 inches depending on the model.
• The engines come with an exploded view diagram for easier repair and maintenance.
• The engines are designed to run on regular unleaded gasoline.
To purchase and instantly download our manual, parts list, and maintenance tips, simply click on the "buy" button and complete your purchase using PayPal. Click on the green button to start the instant download once your payment is complete.
Upon completing your payment through PayPal, you will immediately gain access to the download link on the checkout page. Additionally, we will email you with all necessary download information within one minute of payment. We strongly recommend that you download and save the manual for future reference.
Price: 14.99 USD
