2000 Nissan Altima L30 series Service Manual

Official 2000 Nissan Altima Transmission Documentation

• Covers 2000 Nissan Altima L30 series vehicles equipped with automatic transaxles, including diagnostic data for shift controls and lock-up systems
• Official OEM publication with comprehensive component inspection criteria and hydraulic control circuit diagrams
• Contains 37 diagnostic trouble code (DTC) confirmation procedures, 23 wiring schematic references, and 12 detailed component specification tables
• File delivered as a direct download the moment payment clears
• Indexed PDF search covers every chapter and appendix
• Stored against your account so you can retrieve it after a hard-drive loss
• Laid out for standard letter and A4 printing
• This L30 series service manual is the original factory reference for verifying solenoid resistance, sensor tolerances, and internal gear shift patterns

Diagnostic and System Coverage

The 2000 Nissan Altima automatic transaxle documentation provides an technical breakdown of shift mechanisms and hydraulic logic. It documents the operational requirements for the TCM, including signal inputs from the throttle position sensor, park/neutral position switch, and vehicle speed sensor inputs. The text details the specific conditions for electronic fail-safe operation and provides flow charts for identifying hydraulic control circuit concerns.

Technical Preview and Reference Values

This manual provides detailed reference values for the TCM terminal layout, listing expected voltages for power sources, solenoids, and sensor feedback loops. For instance, the A/T fluid temperature sensor resistance is documented at 2.5 k ohms at 20°C. Shift solenoid valve resistance is specified at 20–40 ohms for both A and B valves. The revolution sensor is calibrated to provide 1V or more when cruising at 30 km/h.

Reference only — always consult a certified technician before performing service on this equipment.
