Yamaha Grizzly 700 ATV Service & Owner’s Manual Set, 2007–2008 (P/N LIT-11616-20-11)

The supplement must be used with the included base service manual for complete 2008 service procedures. The owner’s manual covers controls, riding guidance, preventive maintenance, and minor repairs for YFM7FGPW.

Searchable Text, Bookmarks, and Wiring Detail

Search and diagram navigation: Both PDFs support text search through their main text and have embedded bookmarks. Some warning-label illustrations and ancillary pages in the owner’s PDF are not searchable. Three steering bookmarks in the service PDF’s supplement name the wrong variant; check the heading on the destination page. Small wiring labels and connector details require zooming to read comfortably.

The ZIP contains two printable PDFs totaling 725 pages: a combined service-and-supplement file and a separate owner’s manual. Covers and blank pages are included, along with three ancillary pages and two response-card pages in the owner’s PDF.

Engine, 4WD, and EPS Service Coverage

These selected coverage highlights summarize the main workshop areas. Other included topics range from spark-arrester cleaning to headlight adjustment.

• Engine repair: Engine removal, cylinder-head service, camshaft timing, crankcase separation, crankshaft inspection, and oil-pump repair.

• V-belt drive and transmission: Primary and secondary sheave disassembly, centrifugal-clutch inspection, shift-fork checks, and transmission assembly procedures.

• 4WD driveline: Front and rear CV-joint service, differential-motor checks, middle-gear shimming, and final-drive backlash adjustment.

• Brakes and chassis: Caliper and master-cylinder repair, hydraulic bleeding, steering-knuckle and ball-joint replacement, and suspension-arm service.

• Cooling system: Radiator-cap pressure testing, thermostat inspection, water-pump disassembly, and seal and bearing installation.

• EFI and electrical diagnosis: Meter-based sensor and actuator checks, fuel-pressure testing, starter-motor overhaul, and starting and charging fault tracing.

• EPS steering: Present and stored fault-code diagnosis, motor and torque-sensor testing, warning-light behavior, and steering-unit installation.

The service publications were written primarily for Yamaha dealers and qualified mechanics with a working knowledge of vehicle repair; the owner’s manual supports routine care and identifies work requiring dealer expertise.

Internal Engine and V-Belt Repair

Step-by-step instructions extend into valve-guide replacement and valve-seat refacing, rocker-arm measurements, piston and ring inspection, and crankshaft installation. Exploded assemblies identify replacement seals, lubrication points, special tools, and component-specific tightening requirements.

The sheave sections distinguish primary weights and sliders from secondary torque-cam grooves, guide pins, and spring components. Separate clutch procedures cover shoe wear and one-way-clutch operation. Tool references include the YM-04134 sheave spring compressor and YM-91042 universal clutch holder.

Differential and Final-Drive Setup

Middle-gear and rear final-drive sections explain shim selection using component markings, backlash measurements, and thrust-clearance checks with Plastigauge. These references support setup after gear, bearing-housing, or case replacement rather than stopping at removal and installation.

The front differential’s factory-assembled internal unit is not intended to be dismantled. Gear-lash measurement notes also warn that excessive force on the ring-gear retaining bolt can damage the ring gear.

EFI, EPS, and Model-Specific Updates

Fault isolation: EFI troubleshooting connects displayed fault codes with wiring checks, sensor readings, actuator operation, and reinstatement criteria. This lets a technician follow the documented checks for a reported fault instead of treating the code alone as a component-replacement instruction.

EPS coverage distinguishes normal warning-light operation from faults and explains present versus stored malfunctions, fault-history erasure, and motor and torque-sensor checks.

2008 changes: The supplement updates high-range gearing, valve-spring specifications, throttle-body arrangements, cable routing, and steering installation. It separates non-EPS steering work from EPS-specific procedures and identifies variant-specific electrical components.

FI and EPS circuit diagrams accompany the diagnostic material. Complete YFM7FGPW 2007 and YFM7FGPX/YFM7FGX 2008 wiring diagrams include component keys, connector information, and wire-color codes.

Brake, Chassis, and Cooling References

Brake repair includes piston and seal inspection, hose-routing details, and hydraulic bleeding. The manual warns that cleaning solvents can swell and distort internal brake seals. Steering and suspension sections add ball-joint tool applications, wheel-bearing replacement, toe-in adjustment, and spring-preload settings.

Coolant Flow Diagrams and Oil Flow Diagrams show the relevant circulation paths alongside thermostat, water-pump, and lubrication-system procedures.

Brake hydraulics, fuel-system testing, and spring-loaded sheave work require the manual’s safety precautions and appropriate workshop equipment.

Selected Valve-Clearance and EPS Test Specifications

For the base manual’s cold-engine valve-clearance checks at room temperature, intake clearance is 0.09–0.13 mm and exhaust clearance is 0.16–0.20 mm. The engine chapter pairs these specifications with the inspection and adjustment procedure.

For the EPS-equipped models, the electrical section specifies 1.00–1.50 kΩ for the torque-sensor resistance check, with an illustration identifying the relevant connector terminals.
