Yamaha Stryker / V-Star 1300 2011–2013 Service & Owner's Manual Set (P/N LIT-11616-24-48)

The service manual covers workshop diagnosis and repair, while the owner's manual explains operation, pre-ride inspections, preventive maintenance, and minor repairs.

PDF Search, Navigation and Download Contents

Text search and diagram viewing: Both PDFs have searchable text and section bookmarks. The service PDF does not have a separate bookmark for the final Stryker wiring sheets. Small wiring labels require zooming; sampled connector markings and wire codes are legible when enlarged.

ZIP download containing two printable English PDFs with 634 pages total. This total already includes covers and blank pages, four appended wiring-diagram sheets in the service PDF, and two promotional pages in the owner's PDF.

Engine, Chassis and EFI Service Coverage

The following is a selection of covered topics, rather than a complete contents list. Other documented work includes balancer-gear service and generator/starter-clutch inspection.

• Engine repair: Step-by-step engine removal and installation, camshaft and timing-chain service, cylinder-head and valve work, and cylinder, piston, and ring inspection.
• Clutch and transmission: Clutch disassembly and inspection, shift-shaft service, crankcase separation, and transmission shaft, shift-fork, and shift-drum inspection and assembly.
• Brakes and chassis: Wheel removal and static balancing, caliper and master-cylinder service, hydraulic brake bleeding, front-fork rebuilding, steering-head inspection, swingarm service, and belt-drive work.
• Fuel injection: Fuel-tank and pump removal, injector and throttle-body checks, fuel-pressure testing, throttle-position-sensor adjustment, and throttle-body synchronization.
• Cooling system: Radiator testing, thermostat inspection, and water-pump disassembly, seal replacement, inspection, and assembly.
• Electrical diagnosis: Ignition, starting, charging, lighting, signaling, cooling-fan, fuel-injection, and fuel-pump circuits, with ECU self-diagnostics, diagnostic mode, sensor tests, and system-specific troubleshooting.
• Owner's reference: Controls and instruments, ignition circuit cut-off checks, pre-operation inspections, riding and break-in guidance, scheduled maintenance, minor repairs, care, storage, and troubleshooting charts.

Yamaha produced the service manual primarily for its dealers and qualified mechanics; it assumes basic motorcycle mechanics and repair knowledge. The owner's manual supports rider inspections, preventive maintenance, and minor repairs, with dealer assistance recommended when the necessary tools or experience are lacking.

Model-Specific Procedures and California Equipment

Separate service information distinguishes XVS13CA(C) from XVS13AA(C)/XVS13CTA(C) in chassis torque data, cable routing, drive-belt adjustment, headlight service, brake hardware, and electrical circuits. California-only evaporative-emission canister checks are identified as well.

The full wiring sheets are specifically labeled 2011 and include separate diagrams for XVS13AA(C)/XVS13CTA(C) and XVS13CA(C).

Internal Engine Work and Repair Cautions

Internal inspection extends to valve seats, piston-ring wear, oil-pump clearances, crankshaft condition, and connecting-rod bearing selection. Reference sections provide component-specific torque tables, lubrication data, fluid capacities, wear limits, clearances, and electrical test specifications.

The camshaft section warns that turning the crankshaft during camshaft installation can cause damage or incorrect valve timing. Front-fork procedures caution against scratching the inner tube and using excessive separation force, which can damage the oil seal and bushing.

Rear-shock coverage addresses assembly removal, inspection, replacement, and linkage service. Yamaha warns against opening the pressurized shock absorber.

Diagnostic References and Tool Planning

Named references include the engine-oil lubrication chart, cooling-system diagrams, model-specific cable-routing views, fuel-injection circuit diagrams, and the ECU self-diagnostic function table. The separate troubleshooting chapter addresses starting, idle and higher-speed performance, shifting and clutch faults, overheating, braking, fork and handling problems, and lighting or signaling failures.

Each removal or disassembly section opens with an exploded view and an ordered job chart, so the repair sequence, replacement parts, lubricants, and special-tool calls can be reviewed together before work begins.

For tool planning, Yamaha lists the Vacuummate YU-44456 / 90890-03094, rear drive-belt tension gauge YM-03170 / 90890-03170, adjustable fork-seal driver YM-01442 / 90890-01442, and fuel-pressure adapter YM-03176 / 90890-03176.

Brake, steering, suspension, fuel-system, and engine-timing repairs can affect safe operation if performed incorrectly. Yamaha calls for the correct tools and qualified mechanical knowledge; safety-critical repair work should be referred to a Yamaha dealer or qualified motorcycle technician when either is lacking.

A Preview of Valve-Clearance and Fuel-Pressure Data

For the covered engines, valve-clearance specifications are 0.09–0.13 mm at the intake valves and 0.14–0.18 mm at the exhaust valves, measured with the engine cold at room temperature.

The running-engine fuel-pressure check specifies 324 kPa (46.1 psi), alongside the pressure-gauge and adapter references for that test.
