To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years.
Repair your ATV: Buy and download a copy of this Yamaha Motor Corporation, Ltd technical workshop and factory service (FSM) / repair manual (PDF).
Manual details, specs and technical data:
Production year(s): 91, 92, 93, 94, 95, 96, 97, 98, 99, 00, 01, 02, 03, 04, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
The following models are included in this manual: Warrior 350 / Yamaha Motor Corporation, Ltd - all trim levels and all styles covered
Engine: engine
Manual/e-book format: PDF / .zip / .exe
Language: English (some of our manuals are multi-language)
#
³
The 1991-2004 Yamaha Warrior 350 ATV is a powerful and durable machine that is designed for off-road use. To keep this ATV in top condition, a comprehensive repair and service manual is essential. At repairloader, you can instantly download a 1991-2004 Yamaha Warrior 350 repair, service, and workshop manual in PDF format.
The repair manual includes everything you need to know about the engine, transmission, suspension, brakes, and electrical system, making it easy to troubleshoot, repair, and maintain the ATV. Additionally, a detailed parts list and catalog make it easy to find and order replacement parts for the machine.
Here are 15 tech specs about the 1991-2004 Yamaha Warrior 350 ATV:
1. Engine type: 4-stroke, air-cooled, single-cylinder.
2. Displacement: 348 cc.
3. Bore x Stroke: 83 mm x 64.5 mm.
4. Compression ratio: 9.2:1.
5. Fuel delivery: Mikuni BST34 carburetor.
6. Ignition: CDI.
7. Transmission: 6-speed manual.
8. Drive system: Chain drive.
9. Front suspension: Independent double wishbone, 5-way preload adjustment.
10. Rear suspension: Swingarm, adjustable shock absorber.
11. Front brakes: Dual hydraulic discs.
12. Rear brakes: Hydraulic disc.
13. Front tire size: AT22x7-10.
14. Rear tire size: AT20x10-9.
15. Fuel tank capacity: 2.4 gallons.
The Yamaha Warrior 350 is a highly capable and versatile ATV that can handle a wide range of terrains and conditions. With a comprehensive repair and service manual in hand, you can easily perform routine maintenance, troubleshoot and fix issues, and keep the machine running smoothly for years to come.
