Yamaha V-Star XVS650 / XVS650A 1998–2000 Service & Owner’s Manual Set (P/N LIT-11616-11-16)

Both supplements must be used with the included XVS650AK(C) base service manual. They provide model-specific changes to its workshop information.

The P(C)/AP(C) volume covers operation, inspection, routine maintenance and minor repair. It is not a P(C)/AP(C)-specific engine-and-chassis overhaul supplement.

PDF Search, Bookmarks and Page Breakdown

Search and diagram detail: The combined service file has no PDF text search or embedded bookmarks. The AN(C) supplement has searchable text and section bookmarks. The owner’s manual has chapter bookmarks and searchable text, although the body text on its four warranty and promotional pages is not searchable. Small wiring labels require zooming; some labels in the combined file’s system circuit diagrams remain difficult to read.

The ZIP download contains three printable PDFs totaling 515 pages: the 360-page combined service file, the 36-page AN(C) supplement and the 119-page owner’s manual. This total includes original covers and blank pages, the two additional cover sheets listed above and two promotional pages within the owner’s manual.

Engine Overhaul, Shaft Drive and Electrical Diagnosis

The selected topics below show the repair and operating coverage rather than a complete contents list. Further subjects include spoke inspection and exhaust-system checks.

• Engine overhaul: Step-by-step procedures for engine removal, cylinder-head service, rocker arms and camshafts, valves and springs, cylinders and pistons, crankcase separation, and crankshaft and connecting-rod inspection.

• Clutch and transmission: Clutch and primary-drive repair, shift-shaft service, transmission disassembly and inspection, oil-pump checks, and AC magneto and starter-clutch work.

• Shaft drive: Drive-shaft inspection, final-drive disassembly, backlash measurement, shim selection, ring-gear positioning and bearing service.

• Brakes and chassis: Wheel service and balancing, disc and drum brakes, master-cylinder and caliper inspection, hydraulic bleeding, fork repair, steering-head service, and swingarm and rear-shock inspection.

• Carburetion: Dual-carburetor disassembly and assembly, synchronization, fuel-level adjustment, throttle-position-sensor testing and adjustment, and air-induction-system inspection.

• Electrical troubleshooting: Ignition, starting, charging, lighting and signal diagnosis, plus fuel-pump and carburetor-heater circuit tests, switch continuity checks and self-diagnosis.

• Owner operation: Main switch and steering lock, self-canceling turn signals, fuel-cock use, ignition cut-off checks, starting and shifting, maintenance schedules, and storage.

The service publications were written primarily for Yamaha dealers and qualified mechanics and assume basic motorcycle-repair knowledge; the owner’s manual explains operation and basic care.

Engine Inspection and Workshop Equipment

Internal repair coverage for the air-cooled SOHC V-twin and five-speed transmission includes valve-guide and seat inspection, piston-to-cylinder measurement, bearing-clearance checks and front/rear cam-timing alignment. Component-specific torque tables, lubricant data, wear limits, compression specifications and electrical test values accompany the procedures.

Numbered exploded views and job instruction charts connect parts with removal and assembly work. Together with the special-tool listings, they help a mechanic identify the measuring and holding equipment needed before disassembly.

Factory-tool references include the final-gear backlash band YM-01231 / 90890-01231, middle-gear backlash tool YM-33222 / 90890-04080, clutch holding tool YM-91042 / 90890-04086, fuel-level gauge YM-01312-A / 90890-01312, and steering-stem ring-nut wrench YU-33975 / 90890-01403.

Variant Updates and Owner Maintenance

The K(C) supplement provides revised specifications and cable routing, fuel-tank and seat removal, headlight service, front-fork repair and steering-head procedures.

The AN(C) supplement updates specifications and routing, rear-brake and shift-pedal adjustments, air-induction-system testing, and front-brake pad and caliper service. These changes keep variant-specific information alongside the base procedures.

Owner-level maintenance includes engine-oil and final-gear service, brake and wheel checks, battery care and bulb replacement. Separate XVS650 and XVS650A dimensions, tire and wheel data, and maximum-load specifications support model matching.

Circuit Diagrams and Fault Isolation

Diagram examples include the XVS650AK(C) wiring diagram, XVS650AN(C) wiring diagram, ignition-system circuit diagram, electric-starting-system circuit diagram, fuel-pump-system circuit diagram and air-induction-system diagrams.

Electrical fault charts combine connector checks, continuity tests and component measurements. The starting-circuit explanation shows how the neutral, clutch and sidestand switches affect starter operation, helping distinguish an interlock fault from a starter-motor problem.

The troubleshooting chapter also addresses hard starting, poor idle and high-speed performance, shifting and clutch faults, overheating, weak braking, fork leakage, unstable handling, and lighting or signal failures.

Bearing, Gear and Brake Repair Cautions

The manual warns that spinning cleaned bearings with compressed air can damage their surfaces, while hammering the middle-gear universal joint can distort the collapsible collar. Overtightening the bearing housing can damage the gears by reducing backlash; unsuitable cleaning solvents, used or mixed brake fluid, and contamination can damage brake seals or impair braking.

Securely support the motorcycle before wheel, fork, brake, shaft-drive or engine work.

Sample Valve-Clearance and Gear-Backlash Data

For the XVS650AK(C), the base service manual specifies cold valve clearances of 0.07–0.12 mm for the intake valves and 0.12–0.17 mm for the exhaust valves. Its inspection section includes the cylinder-specific timing references used for these checks.

The middle-gear section specifies backlash of 0.05–0.10 mm, while the final-drive section gives 0.1–0.2 mm. The accompanying measuring illustrations and shim-selection information distinguish these two adjustments.
