To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years.
The following models are included in this manual: Timberwolf 250 / Yamaha Motor Co., Ltd
1994 Yamaha Timberwolf 250 4x4 ATV
1995 Yamaha Timberwolf 250 4x4 ATV
1996 Yamaha Timberwolf 250 4x4 ATV
1997 Yamaha Timberwolf 250 4x4 ATV
1998 Yamaha Timberwolf 250 4x4 ATV
1999 Yamaha Timberwolf 250 4x4 ATV
2000 Yamaha Timberwolf 250 4x4 ATV
Engine: 250 cc.
2x4 all-terrain vehicle
Production year(s): 1994, 1995, 1996, 1997, 1998, 1999, 2000
Manual Language: English
Number of pages: 341
Instant delivery: Your download link will appear on the checkout page after your payment is complete.
#
³
"Get Access to the Ultimate Manual for the 1994-2000 Yamaha Timberwolf 250 4x4 ATV and Unleash Its Power"
Are you an owner of a 1994-2000 Yamaha Timberwolf 250 4x4 ATV? If so, you're in luck! We have curated a comprehensive manual that provides you with all the engine specifications, maintenance tips, common issues, tuning options, accessories, and more for your ATV. Whether you're a seasoned rider or a new owner, this manual is your key to unlocking the full potential of your Yamaha Timberwolf 250. Get ready to enhance your off-road adventures with this versatile and reliable ATV. Let's explore everything you need to know about the Yamaha Timberwolf 250!
Engine Specifications/Tech Specs:
• The Yamaha Timberwolf 250 is powered by a 229cc, air-cooled, four-stroke engine.
• It features a single-cylinder configuration for smooth power delivery.
• The engine incorporates a SOHC (Single Overhead Cam) for efficient valve operation.
• The Timberwolf 250 has a bore and stroke of 71mm x 58mm.
• It utilizes a Mikuni VM24SS carburetor for optimal fuel delivery.
• The ATV features an electric starting system with a backup kick-starter.
• It has a maintenance-free CDI ignition system for reliable starting and performance.
• The Timberwolf 250 comes with a wet sump lubrication system.
• It has a five-speed manual transmission with a reverse gear.
• The ATV features a dual-range drive system for improved off-road capabilities.
• It has a selectable four-wheel-drive system for enhanced traction.
• The Timberwolf 250 incorporates a shaft drive for reliable power transfer.
• It features a front suspension with independent double wishbone design.
• The ATV has a rear suspension with a swingarm and adjustable preload.
• It offers a ground clearance of 7.3 inches for traversing rough terrains.
• The Timberwolf 250 has a fuel tank capacity of approximately 2.4 gallons.
• It features front drum brakes and a rear sealed drum brake for stopping power.
• The ATV has a dry weight of around 485 pounds.
• It comes with 23x8-10 front tires and 23x10-10 rear tires.
• The Timberwolf 250 has a towing capacity of 720 pounds.
Facts and Details:
- The Timberwolf 250 offers comfortable seating for one rider.
- It features a rugged steel frame for durability and stability.
- The ATV comes with a front and rear cargo rack for carrying equipment and gear.
- It incorporates a compact and lightweight design for maneuverability.
- The Timberwolf 250 is known for its reliability and ease of maintenance.
- It has a maximum speed of approximately 40-45 mph.
- The ATV offers excellent off-road capabilities, thanks to its suspension and four-wheel-drive system.
- It is suitable for a variety of outdoor activities, including trail riding, hunting, and utility work.
- The Timberwolf 250 has a comfortable and ergonomic handlebar design.
- It features a comfortable seat with ample padding for long rides.
- The ATV comes with a convenient pull-start backup option for emergencies.
- It has a durable and efficient lighting system for nighttime rides.
- The Timberwolf 250 offers a smooth and controlled ride on various terrains.
Maintenance Intervals:
► Oil Change: Every 10 hours of operation or annually, whichever comes first.
► Air Filter: Clean or replace every 25 hours of operation or annually.
► Spark Plug: Check and replace if necessary every 50 hours of operation or annually.
► Valve Clearance: Check and adjust if necessary every 100 hours of operation or annually.
General Maintenance Tips:
* Clean the ATV thoroughly after each ride to remove dirt and debris.
* Check tire pressure regularly and adjust as needed for optimal performance.
* Lubricate all pivot points, cables, and moving parts to prevent rust and ensure smooth operation.
* Inspect the brake system and adjust or replace brake pads when worn.
* Check the battery regularly and clean the terminals to maintain proper electrical connections.
Common Issues and Solutions:
■ Hard Starting: Check the spark plug, fuel system, and carburetor for any issues or clogs.
■ Overheating: Ensure the cooling system is functioning properly and clean the radiator if necessary.
■ Electrical Problems: Check all wiring connections and fuses for any loose or damaged components.
■ Transmission Issues: Check the transmission fluid level and condition, and adjust or replace if needed.
■ Fuel System Problems: Clean or rebuild the carburetor and check fuel lines for any blockages.
Tuning Tips or Modifications:
+ Performance Exhaust System: Upgrade to a high-flow exhaust system for improved power and a more aggressive sound.
+ Air Filter Upgrade: Replace the stock air filter with a high-performance filter to improve airflow and engine performance.
+ Suspension Upgrades: Install aftermarket shocks or springs to enhance the ATV's off-road capabilities and ride comfort.
+ Tires and Wheels: Upgrade to more aggressive off-road tires and durable wheels for better traction and durability.
Available Accessories and Aftermarket Options:
Winches: Add a winch to your ATV for added utility and assistance in off-road situations.
Skid Plates: Protect the underside of your Timberwolf 250 with skid plates for added durability.
Gun Racks: Install gun racks to securely carry firearms for hunting or recreational shooting.
Snow Plows: Attach a snow plow to your ATV for convenient snow removal during winter months.
Cargo Boxes and Bags: Increase your storage capacity with specially designed cargo boxes and bags.
Owner Reviews and Opinions (Strengths and Weaknesses):
Strengths:
☺ Reliability and durability for long-lasting performance.
☺ Excellent off-road capabilities and versatility.
☺ Smooth and comfortable ride on various terrains.
☺ Easy maintenance and accessibility for DIY owners.
☺ Yamaha's reputation for quality and customer support.
Weaknesses:
☻ Limited top speed compared to higher-performance models.
☻ Lack of advanced features found in newer ATV models.
☻ Stock suspension may be too soft for aggressive off-road riding.
Repairs Needed Most Frequently and Commonly Broken Parts:
→ Carburetor cleaning or rebuild due to fuel-related issues.
→ Starter motor repair or replacement.
→ Brake pads replacement.
→ Battery replacement.
→ Ignition switch repair or replacement.
Purchase and download the comprehensive Yamaha Timberwolf 250 4x4 ATV shop handbook in PDF format by clicking on the green button and choosing PayPal or credit card payment.
Upon completing the payment, you will gain access to the official Yamaha OEM shop manual and parts list for the 1994-2000 Yamaha Timberwolf 250. The download link will be provided on the checkout page, and we will promptly email you the payment and download information.
§
