PFAFF Tiptronic 2040 & 2030 Sewing Machine Instruction Manual
Shop manual for the PFAFF Tiptronic 2040 & 2030 sewing machines, covering operation and maintenance. Features clear diagrams and step-by-step instructions. PN 29-629 989-33/000.
Manual Preview
Sample pages from the PFAFF Tiptronic 2040 & 2030 Sewing Machine Instruction Manual manual
Purchase & Download
Models Covered & Key Technical Specifications
PFAFF Tiptronic 2040 / 2030 (29-629 989-33/000) -- Instruction Manual Comprehensive guide for operating and maintaining your PFAFF sewing machine. Includes troubleshooting and care instructions. Instruction Manual | Operation & Maintenance Dossier.
- General Technical Data: Stitch length ranges from 0-6 mm for versatile sewing applications.
- Certified Stitch Width: The machine offers a stitch width of 0-6 mm, providing ample control.
- Design Power Rating: Operates with a power consumption of 75 W for efficient performance.
- Engineered Safety: Features a nominal voltage range of 120V/220-240V for universal compatibility.
- Verified Sewing Speed: Achieves a maximum sewing speed of 950 stitches/min for rapid work.
- Factory Needle System: Utilizes the 130/705 H needle system for consistent stitch formation.
Professional Workshop Service Manual & Technical Specifications
PFAFF Tiptronic 2040 & 2030 Sewing Machine Maintenance Manual: Expert Operation & Troubleshooting Guide
Procedure-Type: Instruction Manual // Product-Line: Tiptronic Sewing Machines // Procedure-Type: Operation & Maintenance Manual.
Technical Specs Table
| Specification | Operational-Logic | Framework |
|---|---|---|
| Dimensions (w x h x d) | 408 x 290 x 1 87 mm | Machine Specifications |
| Weight | 8.3 kg | Physical Characteristics |
| Power Consumption | 75 W | Electrical Performance |
| Sewing Lamp Wattage | 12V / 5W | Illumination Output |
| Max. Sewing Speed | 950 stitches/min | Operational Capacity |
| Stitching Width | 0 – 6 mm | Stitch Customization |
| Stitching Length | 0 – 6 mm | Stitch Customization |
| Presser Foot Lift | 8 mm | Mechanical Clearance |
| Needle System | 130 / 705 H | Needle Compatibility |
Technical chapters are organized around the comprehensive contents of this manual.
Contents Overview
- Bobbin winding and case management.
- Detailed needle threading procedures.
- Presser foot lift and thread cutter operation.
- Attaching and removing presser feet.
- Needle plate and sewing lamp maintenance.
This manual thoroughly describes the operation and maintenance of your PFAFF Tiptronic sewing machine. It covers essential procedures from initial setup to advanced features. Maintenance sections document procedures for changing the needle plate and sewing lamp, as well as essential cleaning and oiling instructions to ensure optimal machine performance and longevity. The manual also addresses common sewing problems and their solutions, providing guidance for troubleshooting and maintaining consistent stitch quality. "Thoroughly requiring proper adjustment and care, this manual guides users through the machine's functions and upkeep." The manual documents torque specifications for needle adjustments to ensure proper thread engagement security.
