1984-1985 Yamaha FJ600 Service Manual

Technical reference for FJ600N/NC models, covering essential maintenance and repair procedures. Includes detailed diagrams and specifications for optimal performance. PN LIT-11616-04-52.

4.5starstarstarstarstar_half(2)
visibility Preview Available
Yamaha 1984-1985 Yamaha FJ600 Service Manual manual page preview - page 1 of

Sample pages from the 1984-1985 Yamaha FJ600 Service Manual manual

Yamaha 1984-1985 Yamaha FJ600 Service Manual manual preview page 1 - thumbnail
Yamaha 1984-1985 Yamaha FJ600 Service Manual manual preview page 4 - thumbnail
Yamaha 1984-1985 Yamaha FJ600 Service Manual manual preview page 5 - thumbnail
info_outline Click thumbnails to preview different pages
$18.25 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Yamaha Models Covered & Key Technical Specifications

Models: Yamaha FJ600N, Yamaha FJ600NC
Sub-models / Variants: 49A, 51K
Build Years: 1984–1985
Serial Numbers: 49A-007101 and up (FJ600N), 51K-001101 and up (FJ600NC)
Technical Data:

  • Engine: Air-cooled 4-stroke, 4-cylinder parallel, DOHC
  • Displacement: 598 cc
  • Bore x Stroke: 58.5 x 55.7 mm (2.30 x 2.19 in)
  • Compression Ratio: 10.0:1
  • Transmission: Constant-mesh 6-speed
  • Carburetion: BS32 x 4 / MIKUNI
  • Ignition System: T.C.I. (Full Transistor Ignition)
  • Lubrication System: Wet sump, Trochoid oil pump
  • Front Suspension: Telescopic fork, pneumatic-mechanical
  • Rear Suspension: New Monocross swingarm
  • Tire (Front): 90/90-18 51H
  • Tire (Rear): 120/80-18 62H
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
26511 / Donald Peterson
File Size:
34.64 MB
File Type:
ZIP
Language:
English
Printable:
Yes
Category:
Bike
Last updated / verified
Sep 17, 2025

Yamaha Manual Features & Content Preview

Yamaha FJ600N/NC 1984–1985 Service Information

  • Covers 1984–1985 Yamaha FJ600N and FJ600NC motorcycles, documenting 598cc DOHC 4-cylinder engine, chassis, and electrical system specifications
  • Official Yamaha publication P/N LIT-11616-04-52, first edition November 1984
  • Contains 50+ pages of detailed exploded-view diagrams, maintenance intervals, and torque-specification tables for engine and chassis fasteners
  • Delivered as a direct download the moment payment clears
  • Indexed PDF search covers every chapter and appendix
  • Stored against your account so you can retrieve it after a hard-drive loss
  • This 1st edition is the primary OEM documentation for the FJ600N/NC series, detailing specific service requirements for the 49A and 51K model variants

Technical Scope and Documentation

The 1984–1985 Yamaha FJ600 service documentation provides structured details for the FJ600N and FJ600NC variants. Chapters include general information, periodic inspection, engine overhaul, fuel system adjustments, and chassis maintenance. This publication also addresses electrical components and appendices, offering what an OEM service publication covers for owners and mechanics.

Specification Highlights

General specifications include engine compression at 1,079 kPa and a constant-mesh 6-speed transmission configuration. Valve clearance for the intake is listed at 0.11–0.15 mm in the cylinder head specification table. The Yamaha FJ600 1984–1985 carburetor main jet size is specified at #105 for cylinders 1 and 2, while cylinders 3 and 4 utilize #102.5. Front fork oil capacity is documented at 287 cm³ for each fork leg. The Yamaha FJ600 1984–1985 ignition timing is specified at 10° B.T.D.C. at 1,200 r/min. Reference only — always consult a certified technician before performing service on this equipment.

An official Yamaha OEM service publication for the 1984–1985 Yamaha FJ600N/NC, documenting engine, chassis, electrical, and fuel-injection specifications for the 49A and 51K series builds.
