Daewoo Musso Service & Repair Manual (1993–2004)
1,463 Pages • 1 Printable PDF (English) • Download
Daewoo Models Covered & Key Technical Specifications
Model: Musso
Sub-models / Variants: 661LA (2.3L Diesel, OM661LA, 4WD diagnostic code D23LA), 662NA (2.9L Diesel, 4WD diagnostic code D29NA), 662LA (2.9L Diesel, OM662LA, 4WD diagnostic code D29LA), 2.0L DOHC Gasoline (E20, M161.940; front-cover illustration: M161.943), 2.3L DOHC Gasoline (E23, M161.970; front-cover illustration: M161.973), 3.2L DOHC Gasoline (E32, M162.990), Manual Transmission (T5/T5WC), Automatic Transmission (MB W4A040: 662LA, E23, E32; BTRA M74 4WD: 661LA [0574-000001], 662LA [0574-000004], E23 [0574-000005], E32 [0574-000002]), 4WD Transfer Cases (Part-Time 4408 (E), TOD 4423E), LHD (line model P), RHD (line model R)
Model Years: 1993–2004 (1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004)
VIN identification: Position 4 identifies Musso LHD (P) or RHD (R). For gasoline engines, position 8 identifies E20 (8), E23 (6), or E32 (9).
-
Engine displacement: 1998 cc (2.0L), 2295 cc (2.3L), 2299 cc (661LA), 2874 cc (662LA/NA), 3199 cc (3.2L)
-
Engine configuration: 4-cylinder, 5-cylinder, 6-cylinder inline
-
Transmission: 5-speed manual (TREMEC T5), 4-speed automatic (MB W4A040, BTRA M74)
-
Drive system: RWD / 4WD
-
Steering: Rack and pinion
-
Suspension: Double wishbone front, 5-link rear
-
Brake system: Ventilated front disc, solid rear disc
Daewoo Manual Features & Selected Content Preview
This Daewoo Motor Co. service manual covers Musso maintenance, diagnosis, and repair, with separate sections for M161 and M162 gasoline engines and OM600 diesels. Drivetrain specifications and procedures are organized by configuration.
PDF Search, Bookmarks, and Diagram Readability
Text search and diagrams: Search works in the body text. Fine labels embedded in wiring images require zooming and are outside the text search. Two bookmarks open the section index and table of contents. The E32 Low Mode shift chart on PDF p. 991 may appear blank in some PDF viewers.
The download is one printable English PDF with 1,463 pages, including the 12 opening pages of front matter and section indexes.
Engine Overhaul, Drivetrain Diagnosis, and Chassis Service
The bullets highlight selected procedures and references. Other examples include front and rear wiper motor replacement and remote keyless entry connector pinouts.
-
Engine mechanical: Cylinder-head and timing-chain work, compression and cylinder leakage tests, and internal inspections for M161, M162, and OM600 engines.
-
Fuel and cooling: Diesel injector nozzle testing and repair, RIV start-of-delivery checks, cooling-system leak testing, thermostat service, and water pump replacement.
-
Transmission and 4WD: T5WC manual and BTRA M74 automatic overhaul, clutch service, and fault diagnosis and internal repair for the Part Time and TOD transfer cases.
-
Brakes, steering, and suspension: ABS/ABD diagnosis and bleeding, power-steering pump pressure checks, wheel alignment, suspension repair, and front and rear differential inspection.
-
Electrical, restraints, and HVAC: Engine and transmission control circuits, starting and charging diagrams, SRS and immobilizer troubleshooting, and manual and semiautomatic HVAC service.
This manual is suited to technicians and experienced mechanics who use diagnostic test equipment and workshop tools for internal engine and transmission service.
Engine Mechanical Work and Diesel Injection Timing
The gasoline sections distinguish the M161 E20 and E23 from the M162 E32. OM600 repair procedures focus on the OM661LA and OM662LA. The 662NA appears in general vehicle and axle specifications and in the automatic transmission diagnostic coding list.
The mechanical chapters cover crankshafts, pistons, cylinder bores, and camshaft timing. Diesel procedures include prechamber and valve-seat work. Engine performance curves and OM662LA sectional views accompany bore, stroke, compression ratio, ignition timing, clearance, and torque data.
The diesel pump-timing section covers position-sensor and digital-tester RIV methods and identifies position sensor 617 589 08 21 00. The engine and maintenance sections also cover intake and exhaust manifold service, turbocharger and intercooler work, and scheduled fluid and component replacement.
Transmission Overhaul and Transfer-Case Troubleshooting
Automatic transmission: The BTRA M74 overhaul chapter covers clutch packs, valve-body components, and band adjustment. TCU pin descriptions and shift-pattern diagrams support diagnosis. MB W4A040 coverage is limited to specifications, scheduled fluid service, and wiring references.
The BTRA chapter distinguishes electronic, hydraulic, and mechanical faults. Its teardown notes identify the risk of permanent thrust-bearing damage if the output shaft is hammered during center-support removal.
Manual transmission and 4WD: T5WC procedures cover shaft and synchronizer inspection and pre-installation checks. The Part Time 4408 and TOD 4423E chapters include internal repair and control-system diagnosis. TOD service treats the shift motor and oil pump as assemblies.
TOD diagnostic tables connect SCAN-100 fault codes to connector, wiring, speed sensor, and control-unit checks. A mechanic can use them to trace a 4WD warning before selecting a replacement part. The Part Time 4408 chapter also identifies the risk of case-thread damage from impact tools on the oil plugs.
Brake Bleeding, Suspension Tests, and Body Systems
Brakes and chassis: The ABS and ABS/ABD sections distinguish the 5.0 and 5.3 systems in circuit diagrams, fault codes, and hydraulic operation. Bleeding procedures cover master cylinder, caliper or hose, and hydraulic unit replacement. Chassis chapters cover the double wishbone front and 5-link rear suspensions, ECS actuator testing, differential gear contact, power-steering bleeding, and vehicle lifting and support points.
Electrical and HVAC: Gasoline and diesel wiring references include starting and charging diagrams. SRS fault charts and immobilizer no-start flowcharts provide system-specific checks. Manual and semiautomatic HVAC have dedicated repair procedures. Full-automatic A/C coverage is limited to a component locator in the body wiring section.
Selected Cooling, Drivetrain, and Fastener Specifications
The M162 E32 cooling chapter lists an 11.3 L coolant capacity. The T5WC manual transmission specifications list a 3.4 L oil capacity.
The BTRA M74 4WD specifications list final-drive ratios of 5.38 for the 661LA and 4.89 for the 662LA. The M162 vibration-damper center bolt has a two-stage tightening specification of 200–220 Nm followed by 90° +10°.
