2008-2010 Yamaha YW50AP Zuma service manual Preview image 1
2008-2010 Yamaha YW50AP Zuma service manual Preview image 2
2008-2010 Yamaha YW50AP Zuma service manual Preview image 3
2008-2010 Yamaha YW50AP Zuma service manual Preview image 4
2008-2010 Yamaha YW50AP Zuma service manual Preview image 5
2008-2010 Yamaha YW50AP Zuma service manual Preview image 6

2008-2010 Yamaha YW50AP Zuma service manual

Models covered in this manual:

  • 2008 Yamaha YW50X Zuma
  • 2009 Yamaha YW50Y Zuma
  • 2010 Yamaha YW50Z Zuma

File specifications

File size: 8.53 MB
File type: PDF
Language: English

Printable: Yes
Estimated download time: 0.17 Minutes
$15.99 Instant Download

Pay with Bitcoin

Product Information

Table of Contents

  1. General Information
    • Vehicle Identification
    • Vehicle Identification Number
    • Model Label
    • Features
    • Important Information
    • Preparation for Removal and Disassembly
    • Replacement Parts
    • Gaskets, Oil Seals, and O-Rings
    • Lock Washers/Plates and Cotter Pins
    • Bearings and Oil Seals
    • Circlips
    • Checking the Connections
    • Special Tools
  2. Specifications
    • General Specifications
    • Engine Specifications
    • Chassis Specifications
    • Electrical Specifications
    • Tightening Torques
    • Engine Tightening Torques
    • Chassis Tightening Torques
    • General Tightening Torque Specifications
    • Lubrication Points and Lubricant Types
    • Lubrication Diagrams
    • Cable Routing
  3. Periodic Checks and Adjustments
    • Introduction
    • Periodic Maintenance Chart for the Emission Control System
    • General Maintenance and Lubrication Chart
    • Seat, Carriers, Fenders, Fuel Tank, and Air Filter
    • Footrest Boards
    • Engine
    • Chassis
    • Electrical System
  4. Engine
    • Engine Removal
    • Muffler and Exhaust Pipe
    • Leads, Cables, and Hoses
    • Engine Mounting Bolts
    • Installing the Engine
    • Oil Cooler
    • Cylinder Head
    • Camshaft, Rocker Arms, and Valves
    • Cylinder and Piston
    • Recoil Starter and AC Magneto Rotor
    • Shift Shaft
    • Clutch
    • Balancer Gears and Oil Pump
    • Crankcase
    • Crankshaft
    • Transmission
    • Middle Gear
  5. Carburetor
    • Carburetor
    • Disassembling the Carburetor
    • Checking the Carburetor
    • Assembling the Carburetor
    • Adjusting the Fuel Level
  6. Drive Train
    • Troubleshooting
    • Front Constant Velocity Joints and Differential Gear
    • Rear Constant Velocity Joints and Final Drive Gear
  7. Chassis
    • Front and Rear Wheels
    • Front Brake
    • Rear Brake
    • Steering System
    • Front Arms and Front Shock Absorbers
    • Rear Knuckles and Stabilizer
    • Rear Arms and Rear Shock Absorbers
  8. Electrical
    • Electrical Components
    • Checking Switch Continuity
    • Checking the Switches
    • Checking the Bulbs and Bulb Sockets
    • Ignition System
    • Electric Starting System
    • Starter Motor
    • Charging System
    • Lighting System
    • Signaling System
    • Cooling System
    • 2WD/4WD Selecting System
    • Carburetor Warming System
  9. Troubleshooting
    • Starting Failure/Hard Starting
    • Poor Idle Speed Performance
    • Poor Medium and High-Speed Performance
    • Faulty Drive Train
    • Faulty Gear Shifting
    • Faulty Clutch Performance
    • Overheating
    • Faulty Brake
    • Shock Absorber Malfunction
    • Unstable Handling
    • Lighting System
