2009 Arctic Cat all models repair manual

Models covered in this manual:

  • 2009 Arctic Cat Bearcat 570
  • 2009 Arctic Cat Bearcat 570 XT
  • 2009 Arctic Cat Crossfire 500
  • 2009 Arctic Cat Crossfire 600
  • 2009 Arctic Cat Crossfire 800
  • 2009 Arctic Cat Crossfire 800 Sno Pro
  • 2009 Arctic Cat Crossfire R 800
  • 2009 Arctic Cat Crossfire 1000
  • 2009 Arctic Cat Crossfire 1000 Sno Pro
  • 2009 Arctic Cat Crossfire R 1000
  • 2009 Arctic Cat F570
  • 2009 Arctic Cat F5
  • 2009 Arctic Cat F5 LXR
  • 2009 Arctic Cat F6 Sno Pro
  • 2009 Arctic Cat F8
  • 2009 Arctic Cat F8 LXR
  • 2009 Arctic Cat F8 Sno Pro
  • 2009 Arctic Cat F1000 Sno Pro
  • 2009 Arctic Cat M6
  • 2009 Arctic Cat M8
  • 2009 Arctic Cat M8 Sno Pro
  • 2009 Arctic Cat M8 HCR
  • 2009 Arctic Cat M1000
  • 2009 Arctic Cat M1000 Sno Pro
  • 2009 Arctic Cat T500
  • 2009 Arctic Cat T570
  • (4-strokes)
  • 2009 Arctic Cat 120 Sno Pro
  • 2009 Arctic Cat Bearcat Z1 XT
  • 2009 Arctic Cat TZ1 Park
  • 2009 Arctic Cat TZ1 Touring
  • 2009 Arctic Cat TZ1 Touring LXR
  • 2009 Arctic Cat TZ1 Turbo LXR
  • 2009 Arctic Cat Z1
  • 2009 Arctic Cat Z1 LXR
  • 2009 Arctic Cat Z1 Turbo LXR
  • 2009 Arctic Cat Z1 Turbo
  • 2009 Arctic Cat Z1 Turbo Sno Pro

File specifications

File size: 152.21 MB
File type: PDF
Language: English
Pages:671

Printable: Yes
Estimated download time: 3.12 Minutes
$17.99 Instant Download

Pay with Bitcoin

Product Information

Table of Contents

SECTION 1 — GENERAL INFORMATION/SPECIFICATIONS

  • General Specifications
  • Snowmobile Identification
  • Recommended Gasoline and Oil
  • Break-In Procedure
  • Genuine Parts
  • High Altitude Operation
  • Drive Chain Lubrication (120 cc)
  • Low Oil Pressure Warning Light (1100 cc)
  • Preparation for Storage
  • Preparation After Storage
  • After Break-In Checkup (100 Miles - 2-Stroke/600 Miles - 4-Stroke)
  • After Break-In Checkup Checklist
  • Engine Specifications (2-Stroke)
  • Engine Specifications (4-Stroke)
  • Cylinder Head Volumes Specifications (2-Stroke)
  • Engine Piston Travel Versus Crank Angle Chart (2-Stroke)
  • Crankshaft Runout/Repair Specifications (2-Stroke)
  • Fraction/Decimal Conversions
  • MM/IN. Conversions
  • Torque Conversions (ft-lb/N-m)
  • Tightening Torque (General Bolts)
  • Assembly Schematics/Torque Specifications (Table of Contents)
  • Engine Torque Patterns (1100 cc)
  • Arctic Power Valve (APV) System Specifications (2-Stroke)
  • Oil Consumption Specifications (2-Stroke)
  • EFI Specifications
  • Throttle Valve Angle Specifications
  • Fuel Pump Specifications (570 cc)
  • Carburetor Specifications
  • Electrical Specifications
  • Ignition Timing Specifications (2-Stroke)
  • Steering/Body Torque Specifications
  • Drive System Specifications
  • Drive Clutch/Driven Pulley-Related Specifications
  • Arctic Cat Drive Belt Dimensions
  • Drive System Components
  • Gear Case Performance Calibrations
  • Drive System Torque Specifications
  • Rear Suspension Torque Specifications
  • Track Warranty Guidelines
  • Track Specifications
  • Front Suspension Specifications
  • Rear Suspension Specifications
  • Shock Absorber Specifications
  • Idler Wheel Dimensions
