2005 Nissan Sentra Service Manual

2005 Nissan Sentra Automatic Transaxle Technical Documentation

• This official reference supports the 2005 Nissan Sentra, detailing repair procedures for the RE4F03B and RE4F04B automatic transaxle configurations.
• Official Nissan publication, revision July 2004, serving as the factory-authorized diagnostic and overhaul standard for the specified powertrain.
• Includes 12 electrical wiring diagrams, extensive diagnostic flowcharts for trouble codes P0705 through U1000, and 7 detailed cross-sectional component illustrations.
• Downloads to your account within seconds of checkout.
• Permanent availability in your purchase account — no re-buy required.
• OCR text layer lets you jump to a torque spec by keyword.
• This July 2004 revision is the definitive factory reference for the 2005 Sentra transmission overhaul, providing precise tolerances and inspection criteria for internal clutches, brake bands, and valve body assemblies.

Component and System Documentation

This 2005 Nissan Sentra factory publication documents internal transmission components, including torque converter assembly, oil pump, clutch packs, band servo piston, and final drive gear sets. The text outlines structural disassembly and inspection sequences, referencing necessary special service tools and clearances required for precision assembly. Coverage extends to hydraulic control circuit operation, shift mechanism construction, and electronic control system logic, providing the necessary specifications for professional-grade component assessment.

Diagnostic Reference and Specification Preview

Specifications documented include pedal travel ranges and stall revolution speeds for QG18DE engine configurations. The data section provides comprehensive line pressure test protocols, shifting schedule charts, and troubleshooting logic for shift lock and interlock systems. Sensor reference values for throttle position, fluid temperature, and revolution signals are indexed alongside diagnostic trouble codes to facilitate accurate electrical incident identification. An official 96-page Nissan OEM service document covering 2005 Nissan Sentra automatic transaxle diagnostic, mechanical, and electrical specifications for the RE4F03B and RE4F04B transmissions.
