JCB 1400B, 1550B, 1700B Backhoe Loader repair manual

Price: 39.99 USD
File specifications
File size: 389.21 MB
File ending in: pdf
Estimated download time: 7.97 Minutes
Manual details, specs and technical data:
Pages: 550+
From machine no.337001
Publication No. 9803/3257
Related:
John Deere 310G Backhoe loader tractor Repair Technical Manual - TM-1886
or manufacturer: 310G / Deere & Company / John Deere - all trim levels and all styles covered Engine details: 4045D, diesel, 4-cylinder, liquid-cooled, 276
39.99 USD

Models / manufacturer: 1400B, 1550B, 1700B, 200 series / JC Bamford Excavators Ltd
Engine specs (1400B): 1004 THR, Perkins, 4 l, 4 cylinders, 309 Nm, 100x127 mm, 62 kW.
Engine specs (1550B): Perkins, see 1400B.
Engine specs (1700B): Perkins, 1004 T3HR, 70.5 kW, 4 cylinders, 4 L, 357 Nm, 100x127 mm,
Production years (depending on model): 1989, 1990, 1991, 1992, 1993, 1994, 1995.
Language: English (some of our manuals are multilingual)
Manual format: PDF / e-book (zip)
