1986 Yamaha SRX600S / SRX600SC Service Manual

Technical reference for SRX600S/SC models including engine, chassis, and electrical systems. Documents maintenance, diagnostics, and component replacement. PN LIT-11616-05-49

5.0starstarstarstarstar(1)
visibility Preview Available
Yamaha 1986 Yamaha SRX600S / SRX600SC Service Manual manual page preview - page 1 of 238

Sample pages from the 1986 Yamaha SRX600S / SRX600SC Service Manual manual

Yamaha 1986 Yamaha SRX600S / SRX600SC Service Manual manual preview page 1 - thumbnail
Yamaha 1986 Yamaha SRX600S / SRX600SC Service Manual manual preview page 5 - thumbnail
info_outline Click thumbnails to preview different pages
$18.60 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
1 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Yamaha Models Covered & Key Technical Specifications

Models: SRX600S, SRX600SC
Build Years: 1986
Serial Numbers: SRX600S: JYA2EF00GA000101 (USA), JYA2EG00GA000101 (California). Engine: 2EF-000101, 2EG-000101
Technical Data:

  • Engine oil capacity: 2.0 L (Periodic change), 2.1 L (With oil filter change)
  • Valve clearance (Intake): 0.05–0.10 mm (0.002–0.004 in)
  • Valve clearance (Exhaust): 0.12–0.17 mm (0.005–0.007 in)
  • Compression pressure (Standard): 1,079 kPa (11 kg/cm², 156 psi)
  • Drive chain slack: 15–20 mm (0.6–0.8 in)
  • Fork oil capacity (each): 321 cm³ (11.3 Imp oz, 10.9 US oz)
  • Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)
  • Cylinder bore (Standard): 95.00–95.02 mm (3.740–3.741 in)
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
24576 / Elizabeth Morgan
File Size:
57.82 MB
File Type:
PDF
Language:
English
Pages:
238
Printable:
Yes
Category:
Motorcycle
Last updated / verified
Aug 21, 2025

Yamaha Manual Features & Content Preview

1986 Yamaha SRX600S and SRX600SC Workshop Manual

  • Covers 1986 Yamaha SRX600S and SRX600SC motorcycles, including California-specific emission configuration models.
  • Official Yamaha OEM publication P/N LIT-11616-05-49, 1st Edition, April 1986.
  • Contains 238 pages of technical specifications, exploded-view diagrams, and maintenance tables.
  • Stored against your account so you can retrieve it after a hard-drive loss.
  • Indexed PDF search covers every chapter and appendix.
  • This 1986 first edition serves as the original reference for the SRX600 build, detailing the specific single-cylinder mechanical architecture of the era.

Document Scope and Technical Walkthrough

This 1986 Yamaha SRX600S and SRX600SC service manual details foundational maintenance and comprehensive engine overhaul procedures. Chapter coverage progresses from general motorcycle identification, including frame and engine serial number locations, through periodic inspections and specialized engine service. The documentation highlights technical procedures for valve clearance adjustments, carburetor tuning, and chassis maintenance including steering head inspection, brake system fluid levels, and drive chain slack adjustment. Later chapters focus on the engine internal components, providing detailed inspection limits for the crankshaft, transmission gears, piston assemblies, and oil pump systems.

Engine and Chassis Specification Highlights

Technical data within this publication provides essential reference values for maintenance and assembly tasks. Piston clearance is documented at 0.045–0.065 mm (0.0018–0.0026 in) in the engine specification tables. Valve stem clearance for the intake is listed at 0.010–0.037 mm in the cylinder head specification table. Compression pressure at sea level is specified as 1,079 kPa (156 psi) for standard operating conditions. Torque values, such as the 30 Nm (22 ft-lb) drain plug specification, are listed alongside factory-recommended procedures for reassembly. Note: This page is a contents overview for the manual. It does not provide repair or diagnostic instructions. An official 238-page Yamaha OEM workshop manual covering the 1986 Yamaha SRX600S and SRX600SC, documenting engine, chassis, electrical, and carburetor specifications for the 2EF and 2EG series builds.

Manual FAQ, Purchase & Download Details

Are lubrication charts and maintenance interval tables included in the periodic inspections section? keyboard_arrow_down

Manual includes detailed maintenance interval charts that outline requirements for lubrication and periodic inspections. These tables are located within the second chapter to provide a summary of the recommended service intervals.

Does this manual cover the SRX600S and SRX600SC submodels produced for 1986? keyboard_arrow_down

Yes, this official service manual is designated for both the SRX600S and SRX600SC model variants produced in 1986.

Can I use the exploded diagrams in this document to identify the assembly order of engine and chassis components? keyboard_arrow_down

Document provides exploded diagrams for various systems to assist with the identification of component arrangement. These illustrations are positioned before each disassembly section throughout the manual to show the relationship between parts. They are intended as a visual reference for the composition of the engine and chassis.

Is there specific chapter coverage for the carburetion and engine systems in this service publication? keyboard_arrow_down

Document contains dedicated chapters for both the carburetion system and the engine overhaul procedures.

What information regarding electrical components and connector usage is found in the electrical chapter? keyboard_arrow_down

Electrical chapter references the specific instruments needed for checking system components. It also shows the general layout and inspection points for the electrical circuits and related parts.
