Yamaha YZ400F 1998–1999 Owner's Service Manual Set (P/N 5BE-28199-80)

1,119 Pages • ZIP Download: 2 Printable PDFs • 26.63 MB

4.5starstarstarstarstar_half(4)
$16.65 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Yamaha Models Covered & Key Technical Specifications

Models: YZ400F(K), YZ400FLC, YZ400FK1, YZ400F(L), YZ400FL1

Models & Model Codes:

YZ400F(K) — 5BE1 (Canada, Australia, New Zealand, South Africa)

YZ400FLC — 5BE2, 5GR2 (Europe)

YZ400FK1 — 5BE1 (USA)

YZ400F(L) — 5GR4 (Canada, Australia, New Zealand, South Africa)

YZ400FL1 — 5GR1 (USA)

Trade Names: YZ400F

Model Years: 1998–1999


  • Engine type: Liquid cooled 4-stroke, DOHC, single cylinder

  • Displacement: 400 cc (399 cc)

  • Bore x stroke: 92.0 x 60.1 mm

  • Compression ratio: 12.5:1

  • Starting system: Kick starter

  • Transmission: 5-speed, constant mesh

  • Fuel system: FCR 39H Keihin carburetor

  • Ignition system: CDI magneto

Yamaha Manual Features & Selected Content Preview

Publication Pages
1998 Yamaha Owner's Service Manual, P/N 5BE-28199-80. First edition, September 1997. YZ400FK1 (USA) and YZ400F(K) (Canada, Australia, New Zealand, South Africa): 5BE1; YZ400FLC (Europe): 5BE2. 536
1999 Yamaha Owner's Service Manual, P/N 5BE-28199-90. First edition, September 1998. YZ400FL1 (USA): 5GR1; YZ400F(L) (Canada, Australia, New Zealand, South Africa): 5GR4; YZ400FLC (Europe): 5GR2. 583

Each edition provides its own service procedures and specifications. Match the book to the machine's model code before selecting service quantities, inspection limits, or assembly data.

Printable PDFs and Bookmarked Sections

Text search and diagram detail: Neither PDF supports text search. Both have embedded bookmarks for chapters and many individual assemblies. Small connector markings and wire-color codes on the wiring diagrams require zooming for comfortable reading.

The ZIP contains two printable PDFs with English, French, and German text, totaling 1,119 pages. Each edition's page count includes its front and back covers plus 24 publication, introductory, and index pages.


Engine Overhaul, Ignition Testing and Chassis Setup

The selected coverage below highlights major workshop topics. Other material includes control functions, decompression-lever use, cold and warm starting, break-in, cleaning, and storage.

  • Engine repair: Engine removal, camshaft and timing-chain installation, cylinder-head service, valve-guide and seat work, and cylinder, piston, and ring inspection.
  • Clutch and transmission: Clutch inspection and assembly, crankcase separation, crankshaft installation, transmission gear inspection, and shift-cam and shift-fork positioning.
  • Cooling and lubrication: Cooling-system pressure checks, radiator service, oil-filter and strainer inspection, water-pump repair, oil-pump service, and balancer assembly.
  • Brakes and wheels: Brake bleeding, pad replacement, caliper and master-cylinder overhaul, hose inspection, and wheel, axle, bearing, spoke, and sprocket service.
  • Suspension and steering: Fork disassembly and oil setup, steering-head service, swingarm and linkage inspection, rear-shock bearing replacement, and spring and damping adjustments.
  • Fuel and ignition: Keihin carburetor disassembly, accelerator-pump inspection, TPS testing and adjustment, jetting charts, wiring diagrams, and ignition fault isolation.

These books suit mechanically experienced owners; internal engine and suspension work assumes access to measuring equipment and the listed special tools.

Engine Maintenance and Internal Repair

Despite the Owner's Service Manual title, the repair depth goes well beyond routine owner checks. Regular inspection covers clutch and throttle adjustment, air-filter and engine-oil service, pilot-screw and idle-speed settings, and valve-clearance measurement with pad-selection charts. Operating information also explains the fuel valve and valve joint.

Step-by-step procedures address top-end disassembly and assembly, including camshaft inspection, timing-chain tensioner checks, valve guides and seats, and piston-ring installation. Lower-end sections cover the kick axle, shift shaft, CDI magneto, crankcase bearings, transmission shafts, and final shifter and transmission operation checks.

Exploded order charts place inspection limits, lubrication calls, sealant locations, and fastener data beside the related procedures, allowing assembly requirements to be consulted with the repair sequence.

Camshaft-installation cautions identify timing errors from crankshaft movement and damage to the head, caps, or camshafts from uneven cap tightening. Separate cautions address forced case separation and hammer-driven crankshaft removal or installation.

Brakes, Forks and Race Setup

Brake documentation extends to caliper pistons and seals, master-cylinder components, hoses, and reassembly checks. Routine chassis work includes drive-chain adjustment, steering-head preload, spoke checks, and lubrication points.

Fork coverage includes damper-rod and base-valve service, bushings, seals, air bleeding, oil-level setting, and damping adjustment. The instructions address cleanliness, pressure release, and matching oil levels between the fork legs.

Rear-shock work covers removal, mounting, bearing service, spring setup, and external adjustment. The nitrogen-charged cylinder and reservoir are not to be disassembled; this is not an internal shock-rebuilding guide.

The tuning sections connect gearing, fork spring and preload choices, oil level, rear spring selection, loaded sag, and damping changes with track conditions. Suspension symptom charts relate harshness, bottoming, and poor initial movement to the relevant checks and adjustments.

Carburetor Tuning and Ignition Diagnosis

Keihin FCR39H/FLATCR tuning is organized by circuit. Main and pilot systems, main and pilot air jets, needle diameter and clip position, and pilot-screw behavior are explained alongside atmospheric corrections, setting-part tables, and symptom-based examples.

Carburetor service includes float and needle-valve inspection, starter-plunger checks, accelerator-pump components, and TPS inspection. The editions retain their own adjustment instructions and service baselines.

The electrical diagrams identify the CDI unit, CDI magneto, ignition coil, spark plug, TPS, neutral switch, and engine-stop button. The map-controlled CDI schematic explains the relationship between engine speed, throttle position, and ignition timing.

No-spark diagnosis combines connection and switch checks with spark-gap testing, ignition-coil tests, source-coil and pickup-coil resistance checks, and timing verification. The inspection chart helps separate circuit and component faults before the CDI unit is considered. Electrical coverage centers on the competition ignition system rather than street-use lighting or charging equipment.

Workshop Tools and Diagram References

Engine lubrication diagrams and cable-routing drawings complement the wiring diagram, map-controlled CDI schematic, ignition inspection chart, and exploded assembly views. Component torque tables, capacities, wear limits, and electrical test specifications support the documented work.

The tool lists distinguish U.S./Canadian YM/YU numbers from 90890-series equivalents. Examples include the YU-01135-A/90890-01135 crankcase separating tool, YM-01442/90890-01442 fork-seal driver, and YU-03112/90890-03112 Yamaha pocket tester.

Valve and clutch work also identifies the YM-04019/90890-04019 valve-spring compressor and YM-91042/90890-04086 clutch holding tool.

Preview: Cold Valve Clearances and Oil-Service Quantities

Both editions specify cold valve clearances of 0.15–0.20 mm for the intake valves and 0.25–0.30 mm for the exhaust valves. Their adjustment sections include pad-selection charts for choosing replacement shims from the measured clearance and installed pad.

For a periodic engine-oil change, the 1998 edition lists 1.4 L, while the 1999 edition lists 1.5 L. These are periodic-change quantities; oil-filter replacement and total engine capacity have separate entries.

Use the year-specific tables and factory procedures before repair work, especially for valve timing, brakes, pressurized suspension components, and final torque checks.
