Nissan Versa 2011 Factory Service Manual (P/N SM1E-1C11U0)
3,787 Pages • ZIP Download: 42 Printable PDFs • 74.38 MB
Nissan Models Covered & Key Technical Specifications
Model: Versa
Models & Model Codes:
Versa — C11
-
Hatchback S, MR18DE, 6-speed manual (FDSALDY-EUA for U.S., FDSALDY-ENA for Canada)
-
Hatchback S, MR18DE, 4-speed automatic (FDSALDA-EUA for U.S., FDSALDA-ENA for Canada)
-
Hatchback SL, MR18DE, 6-speed manual (FDSALGY-ENA for Canada)
-
Hatchback SL, MR18DE, CVT (FDSALGZ-EUA for U.S., FDSALGZ-ENA for Canada)
-
Sedan S, MR18DE, 6-speed manual (BDSALDY-EUA for U.S.)
-
Sedan S, MR18DE, 4-speed automatic (BDSALDA-EUA for U.S.)
-
Sedan SL, MR18DE, 4-speed automatic (BDSALGA-EUA for U.S.)
-
Sedan Base, HR16DE, 5-speed manual (BDTALAF-EUA for U.S., BDTALAF-ENA for Canada)
-
Sedan 1.6 L, HR16DE, 5-speed manual (BDTALCF-EUA for U.S.)
-
Sedan 1.6 L, HR16DE, 4-speed automatic (BDTALCA-EUA for U.S.)
-
Sedan Base, HR16DE, 4-speed automatic (BDTALAA-ENA for Canada)
Sub-models / Variants: HR16DE engine models (5-speed manual RS5F91R or 4-speed automatic RE4F03B with assembly codes 3CX3D and 3CX3E), MR18DE engine models (6-speed manual RS6F94R, 4-speed automatic RE4F03B with assembly code 3CX0D, or CVT RE0F08B with assembly code 1XC6B)
VIN identification: Position 4 identifies the engine (B = MR18DE, C = HR16DE). Position 7 identifies the body (A = 4-door sedan, C = 4-door hatchback).
Model Year: 2011
-
Transmission type: Automatic transaxle (RE4F03B for the specifications below)
-
Fluid temperature operating range for checking: 50–80°C (122–176°F) for the hot fluid-level check
-
Stall test fluid temperature: 50–80°C (122–176°F)
-
Compressed air regulation for cooler cleaning: 5–9 kg/cm2 (490–883 kPa, 71–128 psi)
-
TCM terminal 29 output speed signal frequency: Approx. 150 Hz at 20 km/h (12 MPH)
-
TCM terminal 38 input speed sensor signal frequency: Approx. 360 Hz at 20 km/h (12 MPH)
Nissan Manual Features & Selected Content Preview
Nissan’s factory service manual (P/N SM1E-1C11U0, May 2010 edition and revision) covers the 2011 Versa C11 sedan and hatchback for the U.S. and Canadian markets. It provides separate service procedures for the HR16DE and MR18DE engines.
PDF Search, Bookmarks, and Diagram Detail
Text search and chapter navigation are available through searchable service text in every PDF and embedded bookmarks in most chapters. If a chapter’s return link to the index fails, open fwd.pdf directly. Zoom in to read small pin numbers and wire-color codes in the diagram images.
The ZIP contains 41 chapter PDFs and an 11-page quick-reference PDF, for 3,787 pages total. That count includes the cover and index, foreword and safety notice, feedback form, and quick-reference tables.
Engine Repair, Transaxles, and Electrical Diagnosis
This selection of service and repair topics covers the main workshop procedures below. Other sections cover refrigerant leak testing and sunroof removal on equipped models.
- Engine mechanical procedures cover valve clearance and compression checks, timing chain removal and installation, and cylinder block disassembly and inspection.
- Automatic transaxle service includes stall and line-pressure tests, fluid-level checks, cooler flushing, and internal clutch and control valve work.
- Manual transaxle and CVT procedures cover clutch hydraulics, manual gearbox disassembly and inspection, and CVT fault diagnosis and assembly replacement.
- Brake and chassis service includes hydraulic bleeding, front disc and rear drum service, ABS wheel speed sensor diagnosis, and wheel alignment checks.
- Engine and electrical diagnosis includes OBD-II tests for misfires and emissions faults, ECM terminal references, CAN wiring diagrams, and CONSULT-III procedures.
- Scheduled maintenance pairs service intervals with procedures for fluid changes, drive belt inspection, and spark plug replacement.
The manual suits technicians familiar with scan-tool data and electrical measurements, which Nissan uses throughout the fault-isolation procedures.
Automatic Transaxle Diagnosis and Overhaul
The symptom charts cover harsh shifts, engagement problems, overheating, and loss of torque converter lock-up. The TCM terminal tables give reference voltages for the transmission range switch and shift solenoids. Used with the hydraulic line-pressure and engine-specific stall-speed tables, they help narrow down whether a shift complaint points to an electrical circuit or the transaxle hydraulics.
Nissan provides on-vehicle control valve and accumulator procedures and step-by-step RE4F03B overhaul instructions. The radiator-mounted ATF cooler gets its own cleaning and debris inspection procedure because trapped metal or friction material can contaminate a rebuilt unit or restrict fluid flow. Follow the manual’s precautions for securing the vehicle during stall tests and handling hot ATF during service.
CVT Service and Manual Gearbox Repair
The RE0F08B chapter covers fluid checks, oil warmer and cooler hose service, and speed sensor replacement. For faults inside the CVT, Nissan specifies replacing the transaxle as an assembly.
For the RS5F91R and RS6F94R manual gearboxes, exploded views and bench procedures cover shaft disassembly, gear and synchronizer inspection, and reassembly.
Control Systems and Wiring
The engine control chapter includes idle air volume learning and cruise-control (ASCD) switch diagnostics. The brake control chapter covers steering angle sensor neutral-position adjustment on models equipped with Vehicle Dynamic Control.
Wiring examples include the transmission range switch (AT-TR/SW), shift solenoid A (AT-SSV/A), ECM power and ground (EC-MAIN), ABS wheel speed sensors (BRC-ABS), the CAN network (LAN-CAN), and the starting circuit (SC-START). Connector views and harness layouts help locate the terminals called out in the diagnostic tests.
ATF Sensor Voltage and Compression Test Examples
With the engine running, the RE4F03B ATF temperature sensor signal across TCM terminals 47 and 42 is approximately 1.5 V at 20°C (68°F) and 0.5 V at 80°C (176°F).
For warm-engine compression testing, Nissan lists a standard of 1,510 kPa (219 psi) at 200 rpm for the HR16DE and 1,500 kPa (217.6 psi) at 250 rpm for the MR18DE.
