Jeep Wrangler TJ 2006 Service & Diagnostic Manual Set (P/N 81-370-06063)
2,519 Pages • Printable PDF • 58.88 MB • Download
Jeep Models Covered & Key Technical Specifications
Model & Model Code: Wrangler (TJ)
Sub-models / Variants: SE, X, Sport, Rubicon, 2.4L, 4.0L, LHD (TJJ), RHD (TJU), 93.4 in. Wheel Base (77), 103.4 in. Wheel Base (78)
Model Year: 2006
VIN Identifiers: Position 5 (vehicle line): A = Wrangler 4x4 LHD, 4 = Wrangler 4x4 RHD. Position 7 (body style): 9 = Open Body, 4 = Extended Open Body. Position 8 (engine): 1 = 2.4L, S = 4.0L. VIN position 10: 6=2006
-
Engine: 2.4L 4 cyl DOHC Gasoline (ED1), 4.0L 6 cyl MPI Gasoline (ERH)
-
Transmissions: NSG370 6-speed Manual (DEH), 42RLE 4-speed Automatic (DG6)
-
Axle Units: 181 FBI (Model 30), 216 FBI (Model 44), 194 RBI (Model 35), 216 RBI (Model 44)
-
Axle Nut Torque: 237 N-m (175 ft-lbs) for the 181 FBI and 216 FBI front axles
-
Stabilizer Bar Retainer Bolt Torque: 61 N-m (45 ft-lbs) for the front stabilizer bar
-
Suspension Arm Lower Nut Torque: 176 N-m (130 ft-lbs) for the front lower suspension arm axle and frame bracket nuts
-
Hub/Bearing Bolt Torque: 102 N-m (75 ft-lbs) for the 181 FBI and 216 FBI front axles
Jeep Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| 2006 Jeep Wrangler (TJ) Service Manual (P/N 81-370-06063) | 1,746 |
| 2006 Jeep Wrangler (TJ) Powertrain Diagnostic Procedures — NGC engines and 42RLE diagnostics | 486 |
| 2006 Jeep Wrangler (TJ) Body Diagnostic Procedures — restraints, body electronics, and PCI bus | 214 |
| 2006 Jeep Wrangler (TJ) Chassis Diagnostic Procedures — Teves Mark 20i ABS and axle lock | 72 |
The DaimlerChrysler Service Manual covers left- and right-hand-drive Wranglers, standard and extended open bodies, and both gasoline engines. The diagnostic books use trouble codes and symptoms to isolate faults and refer technicians to the Service Manual for component removal and repair.
PDF Search, Bookmarks, and Page Count
Search and navigation: Workshop text is searchable across all four publications. Many labels within the wiring drawings are graphical, and small pin numbers and wire codes are best read with zoom. The opening menu links to all four publications. Embedded bookmarks lead to chapters and diagnostic tests, although some legacy bookmarks point to separate files.
The four publications are combined in one printable English-language PDF with 2,519 pages, including the one-page publication menu. The Service Manual count includes five front-matter pages and 25 blank pages. Notes and feedback pages are included in their respective diagnostic volume counts.
Engine, Drivetrain, and Electrical Service
These are selected workshop topics. The Service Manual also includes domestic and export maintenance schedules and battery load testing.
- Engine repair: Engine removal, cylinder-head and valvetrain work, timing-belt and timing-chain service, and internal engine inspection.
- Transmission and transfer case: Clutch service, manual and automatic transmission disassembly, hydraulic pressure testing, and transfer-case inspection and assembly.
- Axles and driveshafts: Axle shaft and seal service, universal-joint replacement, driveshaft vibration diagnosis, and Tru-Lok differential and pump service.
- Suspension and steering: Front and rear link-and-coil service, control-arm bushings, hub bearings, ball joints, shocks, stabilizer bars, track bars, and steering linkage.
- Brakes and ABS: Hydraulic bleeding, caliper and rotor service, and diagnostic tests for wheel-speed sensors, the ABS pump, and controller circuits.
- Powertrain diagnostics: DRBIII tests for no-start and intermittent faults, transmission pressure switches and solenoids, and powertrain control module circuits.
- Body electrical: Airbag fault isolation, instrument cluster self-tests, and PCI bus diagnosis with component locations, connector pinouts, and wiring diagrams.
DaimlerChrysler wrote the Service Manual for working automotive technicians. Experienced owners can use the maintenance and inspection sections as a reference. Many diagnostic and overhaul procedures call for DRBIII access, lifting and support equipment, presses, or model-specific tools.
Engine Timing, Fuel, and Cooling
The 2.4L four-cylinder chapter covers timing-belt service, while the 4.0L six-cylinder chapter covers the timing chain and sprockets. Engine sections also address bottom-end inspection, lubrication, intake and exhaust hardware, and ignition and fuel-management diagnosis. Cooling procedures include combustion-leakage testing.
Gearbox and Transfer Case Service
The NSG370 section details internal geartrain service. The 42RLE section includes valve-body and solenoid/pressure-switch work, Quick Learn, and EATX event data. The powertrain diagnostic book specifies the Miller 8333 transmission simulator with the 8333-1A adapter and PCM terminal tools 3638 and 8815. The NV231 and NV241 have separate removal, disassembly, inspection, and assembly procedures.
Fluid charts distinguish Mopar ATF+4 applications for the automatic transmission, transfer cases, and power steering from the specified manual transmission and axle lubricants. The automatic transmission section warns that incorrect fluid can cause clutch chatter.
Differential Setup and Wheel Alignment
The front 181 FBI and 216 FBI and rear 194 RBI and 216 RBI chapters cover pinion depth, shim selection, bearing preload, backlash, and runout. Gear-contact illustrations help distinguish a pinion-depth error from a backlash error. The 181 FBI tool list includes dial indicator C-3339, spreader W-129-B, dummy bearings D-348, and pinion depth set 6774.
The alignment section covers caster and toe adjustment and checks for preset camber. Tightening rubber-bushed control arms or track bars at full droop can preload the bushings and shorten their life. During pinion service, backing off the nut to reduce rotating torque or over-crushing the collapsible spacer can damage the bearing setup.
Body Wiring, Restraints, and HVAC
Schematics include the 2.4L and 4.0L NGC circuits, 42RLE controls, the instrument cluster and axle locker, and the Teves Mark 20i ABS controller. The body diagnostic book distinguishes active and stored airbag faults and identifies the 8310 and 8443 load tools. The Service Manual covers A/C performance and refrigerant leak checks.
Airbag circuits, brake hydraulics, refrigerant systems, and heavy axle or drivetrain assemblies require the factory isolation, lifting, and test-equipment precautions stated in the publications.
Fuel Pressure and Gear Backlash Examples
For a P0171 lean-condition diagnosis on the NGC-controlled engines, the fuel rail pressure specification is 407 ± 34 kPa (59 ± 5 psi) during the DRBIII ASD fuel system test with the ignition on and the engine off.
During differential setup on the 181 FBI front axle, the ring gear backlash specification is 0.12–0.20 mm (0.005–0.008 in.), measured with a dial indicator.
