1954 Ford 600/800 Series Tractor Owner's Manual (P/N SE 6085)

67 Pages • Printable PDF • 27.21 MB • Download

$16.90 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

print
Save & print
Keep a copy on your device
flash_on
Instant Download
Get it immediately
lock
Secure Payment
Stripe

Ford Models Covered & Key Technical Specifications

Models: 640, 650, 660, 850, 860

Sub-models / Variants: 4-speed transmission (640), 5-speed transmission (650, 660, 850, 860), regular-duty wheel weights (Series 600), heavy-duty wheel weights (Series 800 only), live PTO clutch models (660, 860)

Model Year: 1954


  • Engine: 4-cylinder, in-line, overhead valve

  • Displacement: Series 600: 134 cu. inches; Series 800: 172 cu. inches

  • Bore: Series 600: 3.44 inches; Series 800: 3.90 inches

  • Fuel Tank Capacity: Series 600: 11 U.S. gallons; Series 800: 14 U.S. gallons

  • Cooling System Capacity: 15 U.S. quarts

  • Transmission Types: Constant mesh, 4 speed or 5 speed

  • Electrical System: 6-volt, positive ground, 20-amp generator

  • Hydraulic Pump Type: Vane

  • Hydraulic System Max Pressure: 2000 psi

File & Download Details
keyboard_arrow_down
Listing ID:
28657
Seller:
Susan Wilson
File Size:
27.21 MB
File Type:
PDF
Language:
English
Pages:
67
Printable:
Yes
Delivery:
Download link on the confirmation page and by email after payment.
Download link validity:
3 days after purchase. Your saved PDF does not expire.

Ford Manual Features & Content Preview

This 1954 Ford Series 600 and 800 owner's manual covers the 640, 650, 660, 850, and 860 tractors. Prepared by Ford Motor Company's Tractor and Implement Division, manual SE 6085 explains operation, scheduled maintenance, and routine mechanical adjustments.

  • Controls and operation: Proof-Meter readings, normal and cold-weather starting, break-in guidance, gear selection for field work, and seasonal tractor storage.

  • Hydraulics and hitch: Live Action hydraulics, Constant Draft Control, Implement Position Control, Hy-Trol adjustment, three-point linkage, and live PTO clutch operation.

  • Engine and fuel: Carburetor idle and main-needle adjustments, oil-bath air cleaner service, valve tappet adjustment, and governor linkage checks.

  • Ignition and charging: Distributor point replacement, spark plug inspection, timing-light procedures, and generator/regulator fault isolation with the Generating System wiring diagram.

  • Clutch, wheels, and brakes: Clutch pedal adjustment, front wheel toe-in, wheel-bearing adjustment, brake adjustment, and tire removal and installation.

  • Lubrication and specifications: Hour-based service schedules, a lubrication chart, fluid-capacity tables, oil classifications, and model-specific engine, clutch, transmission, and rear axle data.

It suits owners who handle routine upkeep and adjustments, with a timing light and feeler gauges needed for the documented ignition work.

Proof-Meter, Hydraulic Controls, and PTO

The Proof-Meter section explains engine speed, ground speed, PTO speed, belt pulley speed, and accumulated engine hours. Separate instrument illustrations and a field-work chart distinguish the transmission configurations, helping you use the appropriate speed scale for your tractor.

Hydraulic operating guidance explains how draft control responds to changing soil resistance and how position control holds an implement setting. The hitch section covers the two hole hydraulic lift rocker, adjustable top link, and drawbar stays.

The live PTO discussion identifies the two-stage clutch on models 660 and 860 and explains its alternative single-clutch setting. The drawbar-stay section also warns that raising the hydraulic Touch Control Lever with the stays installed can damage the stays.

Engine, Fuel, and Cooling Maintenance

The maintenance chapter lays out an hourly service schedule, supported by a lubrication chart for chassis and engine service points. Fluid-grade recommendations account for seasonal conditions, and storage instructions cover both lay-up and return to service.

Carburetor coverage distinguishes the idle-speed stop, idle air needle, and main adjusting needle. The cooling section covers thermostat operation, radiator flushing, and fan/generator belt tension.

Valve tappet and governor linkage adjustments are documented. Major repairs, overhauls, and valve reconditioning are referred to a dealer; internal engine and transmission overhaul procedures fall outside this owner's manual's scope.

Electrical Checks and Chassis Adjustments

The generating-circuit check helps distinguish a regulator fault from a generator fault before component repair or replacement. The ignition section links distributor point replacement to checking the timing with a timing light.

Clutch adjustment instructions distinguish the model 640 linkage from the other covered models. Front wheel toe-in, bearing adjustment, and internal expanding brake adjustment have their own illustrations.

The 63 numbered figures include Gear Shift Positions, Front Wheel Tread Adjustments, Ford Tractor Engine Cooling System, Sectional View of Carburetor Air Cleaner, Generating System, and Distributor Assembly.

Working on these tractors involves heavy lifting, hydraulic equipment, and moving PTO shafts. Review the manual's operating and maintenance precautions before work.

Attachments, Seat Adjustment, and Ballast

The accessory section describes the Selec-Trol valve and remote control cylinder for auxiliary hydraulic equipment, plus the stabilizer link kit for limiting implement side sway. Separate entries cover the power take-off conversion kit, belt pulley, swinging drawbar, dual rear wheel assembly, and vertical exhaust kit.

Rest-O-Ride seat adjustment is explained, with the seat identified as standard on Series 800 tractors. The wheel-weight chart separates regular-duty, heavy-duty, and industrial ballast; heavy-duty weights are expressly excluded from Series 600 tractors.

Examples of Ignition and Valve Adjustment Data

These examples show a small selection of the tune-up specifications in this owner's manual.

For both engine series, intake and exhaust tappet clearance is 0.014-0.016 inch with the engine at normal operating temperature. The valve adjustment section provides the associated setting procedure.

Initial ignition timing differs by series: 8° before top dead center for Series 600 and 5° for Series 800, both at 475 engine RPM. Those settings accompany the timing-light instructions.

PDF Bookmarks and the Wide Lubrication Chart

Search, navigation, and diagram labels: PDF text search is not available. Embedded bookmarks provide access to the main sections and selected subsections. Zooming in makes the small labels in the Generating System wiring illustration easier to read.

The download contains one printable 67-page PDF: 63 interior manual pages, front and back covers, and two additional pages. The lubrication chart spans two printed pages combined into one wide PDF page. All covers and additional pages are already included in the total.
