John Deere Models Covered & Key Technical Specifications

Model: 2653

Model Year: 1995

Serial Number Break (optional backlapping valve): Before MO2653A/B030001; MO2653A/B030001 onward


  • Engine: Kawasaki FD620D, 13.4 kW (18 HP), 585 cc, 2-cylinder, 4-cycle

  • Transmission: Eaton hydrostatic, ball/variable displacement, 16 GPM

  • Torqmotors: TRW MB series geroler type

  • Fuel: Gasoline (87 AKI or higher, unleaded recommended)

  • Electrical: 12V system, 430 CCA battery, 15 Amp regulated output

  • Hydraulic System: 15.1 L (4 U.S. gal) reservoir, 10 micron filtration, 20685 kPa (3000 psi) max reel circuit pressure

John Deere Manual Features & Selected Content Preview

John Deere’s technical manual P/N TM1533 (01JAN95) covers the 1995 2653 Professional Utility Mower with the Kawasaki FD620D engine, Eaton hydrostatic drive, and E.S.P. reel cutting units. This edition replaces TM1533 (OCT94).

PDF Search and Wiring Diagram Detail

Search and circuit detail: Text search is limited to the cover. The PDF has no embedded bookmarks. Zoom in to read small wire codes and connector labels. Several circuit diagrams are printed sideways and are easier to read with the page view rotated.

The English-language download contains one printable, 174-page PDF, including the original cover, 15 blank or notes pages, and the three-page index.


Engine, Hydrostatic Drive, and Reel Service

These selected workshop topics give a preview of the manual. It also includes oil-pump inspection and torque charts for hydraulic fittings.

  • Engine repair: Engine removal and installation, cylinder-head and valve service, crankcase inspection, piston-ring fitting, cylinder boring, and crankshaft and camshaft installation.

  • Fuel and cooling: Carburetor overhaul, float and governor adjustments, fuel-pump testing, cooling-system pressure checks, water-pump service, fan-belt adjustment, and thermostat testing.

  • Electrical diagnosis: Cranking, ignition, mow, and optional backlapping circuits, with control-module and interlock tests, charging-system checks, and starter disassembly and inspection.

  • Hydrostatic drive: Step-by-step instructions for Eaton pump disassembly and assembly, plus charge-pump service, TRW MB Torqmotor testing and repair, startup checks, and neutral adjustment.

  • Steering and reel hydraulics: Eaton Char-Lynn 2 Series steering-control service, Danfoss 37B reel-pump repair, reel-motor case-drain testing, and backlapping- and lift-valve repair.

  • E.S.P. cutting units: Heavy-duty five- and eight-blade reel configurations, roller and bedknife service, pivot-arm and reel repairs, relief grinding, backlapping, and height-of-cut adjustment.

John Deere wrote this manual for experienced technicians. Engine repair and hydraulic testing assume suitable shop equipment and established service skills.

FD620D Inspection, Fuel, and Cooling

Engine inspection data covers cylinder-head flatness, valve guides, piston and ring wear, connecting rods, and crankshaft bearings. Valve seating drawings show contact patterns, and the cylinder-boring procedure covers finish honing.

The carburetor section includes an exploded view, idle adjustment, and a fuel shutoff-solenoid test. Cooling procedures cover flushing, water-pump seal and impeller inspection, fan-bearing replacement, and thermal-switch checks.

Wiring, Test Points, and Interlocks

The Electrical Schematic, Wiring Harness drawing, and component views map wire colors, circuit numbers, and connector terminals. The Cranking Circuit Test Points pair expected readings with individual connections to help trace a no-start fault.

Separate checks cover the TDC control module, transmission-neutral and park-brake switches, raise/lower switch, mow-valve solenoid, and optional third-wheel-drive solenoid. Backlapping diagnosis covers the defeat relay and operator-off-seat circuit. Engine electrical tests cover the ignition coils, pulsers, stator, and starter.

Hydrostatic Pump and Wheel Motors

Pump-output and Torqmotor tests help distinguish low pump output from internal wheel-motor leakage when ground speed drops. The Hydrostatic Drive Hydraulic Circuit shows how the optional third wheel is driven.

The pump’s ball pistons are matched to the rotor and must stay with it during service. The Torqmotor Components view supports inspection and reassembly. Removing the main shaft bearings destroys them, and replacement bearings are unavailable. If the rotor set needs replacing, the complete Torqmotor must be replaced. The manual also covers post-service checks and neutral-safety-switch adjustment.

Steering, Reel Drive, and Backlapping Valves

Steering leakage tests help isolate a fault to the control unit or the steering cylinder. The manual covers steering-control disassembly and assembly, relief-pressure testing, and rear-wheel pivot and bushing service.

Reel-drive coverage includes gear-motor repair, the flow-control valve, and the logic element. The hydraulic schematic shows the steering and lift circuits, and the Lift Valve Repair exploded view identifies the valve’s internal parts. On machines with optional backlapping, the forward/reverse valve uses a pull-and-turn detent before serial number MO2653A/B030001 and a push-pull control from that number onward.

Reel Setup and Cut-Quality Checks

The 26-inch cutting-unit section links streaking, marcelling, and changes in cutting height to specific checks. It distinguishes smooth and grooved rollers and covers roller bearings and seals, bedknife supports, and reel bearings. Height-of-cut guidance shows how to use a two-bolt gauge bar and explains why the effective cut can differ from the bench setting.

Follow the manual’s battery-isolation, hydraulic-pressure-relief, and rotating-reel precautions during service.

A Preview of FD620D Capacities and Reassembly Specs

The capacity table lists 0.95 L of coolant and 2.1 L of crankcase oil with the filter.

The cylinder-head procedure uses staged tightening and specifies a final torque of 21 N·m with the intake manifold fitted. The flywheel nut has a separate specification of 108 N·m (80 lb-ft.).
