1997–2000 Dodge Dakota Service Manual (P/N 81-370-0010)

• 2000 Dodge Dakota (AN) factory service coverage for 4x2 and 4x4 Conventional Cab, Club Cab, and Quad Cab configurations. DaimlerChrysler document identification: 2000 AN Service Manual, Publication No. 81-370-0010.
• Dedicated engine repair chapters cover the 2.5L I-4, 3.9L V-6, 4.7L V-8, and 5.9L V-8, including diagnosis, engine removal, cylinder-head work, timing service, bearing fitting, lubrication checks, and internal inspection.
• Transmission and transfer-case overhaul coverage includes NV1500 and NV3500 manual transmissions, 42RE, 46RE, and 45RFE automatics, plus NV231 and NV242 transfer cases. Sections include pressure and air tests, valve-body and geartrain teardown, clutch and band service, cable adjustment, cooler flushing, and hydraulic schematics.
• Axle and suspension sections cover the C205F front axle, 8 1/4- and 9 1/4-inch rear axles with standard and Trac-Lok differentials, 4x2 coil-spring front suspension, 4x4 torsion-bar front suspension, rear leaf springs, wheel alignment, hub/bearing service, and ball-joint diagnosis.
• Brake and steering repair data covers base brakes, rear-wheel antilock brakes, four-wheel ABS, bleeding, hydraulic-control-unit and wheel-speed-sensor service, rotor/drum inspection, power-steering flow and pressure testing, rack-and-pinion service, and steering-column work.
• Fuel, emissions, and electrical diagnosis covers battery, starting and charging tests; fuel-pump pressure, capacity, and leak-down checks; injectors and PCM inputs/outputs; OBD monitor logic; EVAP/PCV components; and Group 8W circuit, connector, and splice documentation.
• Body and HVAC repair sections include frame dimensions, body gap/flush and weld-location views, glass, doors, seats, Quad Cab components, A/C performance testing, refrigerant recovery/evacuation/charging, and heater/evaporator/compressor service.
• Provides component-specific torque tables, capacities, pressure-test values, wear and clearance limits, alignment data, axle setup specifications, electrical tests, special-tool identifications, and system diagrams throughout the PDF.

Drivetrain and Suspension Coverage

The C205F chapter covers front-axle removal, pinion and axle-shaft seals, axle-shaft bearings, differential and ring-gear service, pinion-depth setup, differential-bearing preload, backlash, and contact-pattern analysis. Rear-axle material separates the 8 1/4 and 9 1/4 assemblies and adds standard and Trac-Lok differential teardown, clutch-disc inspection, side-gear clearance, exciter-ring service, and matched gear setup.

Propeller-shaft and front-drive-shaft chapters address one- and two-piece shafts, center bearings, single- and double-Cardan joints, C/V boots, runout, unbalance, driveline-angle measurement, and drive-away shudder correction. Suspension coverage distinguishes 4x2 coil springs from 4x4 torsion bars, with control-arm, knuckle, hub, ball-joint, shock, leaf-spring, ride-height, and camber/caster/toe procedures.

Engine, Transmission, and Electrical Coverage

Engine material includes compression, combustion-leakage, oil-pressure, oil-leak, tappet or lash-adjuster, and intake-leak diagnosis before moving into engine removal and internal repair. The 4.7L chapter is especially detailed, with primary and secondary timing-chain inspection, chain and sprocket installation, camshaft service, main-bearing selection, separate 4x2/4x4 oil-pan procedures, and the related special tools. The 2.5L, 3.9L, and 5.9L chapters provide comparable cylinder-head, valvetrain, timing, piston, connecting-rod, crankshaft, oil-pump, and seal work.

The transmission chapters support diagnosis and bench repair. 42RE and 46RE coverage includes road and pressure testing, clutch/band air checks, converter leak diagnosis, governor electronics, valve-body teardown, clutch and planetary service, band/cable adjustment, and hydraulic flow diagrams. The 45RFE section adds speed and pressure sensors, solenoid/pressure-switch assemblies, input and holding clutches, clutch-volume indexes, and a dedicated hydraulic schematic. NV1500/NV3500 chapters cover case and geartrain disassembly, synchronizers, shift forks, bearings, and reassembly; NV231/NV242 chapters cover chains, sprockets, range hubs, oil pumps, planetary carriers, seals, bushings, and shifter adjustment.

Group 8W ties these systems together with power and ground distribution, fuel/ignition and transmission-control circuits, rear-wheel and four-wheel ABS, airbag and HVAC wiring, trailer-tow diagrams, connector pin-outs, connector locations, and splice maps.

Technical Specification Preview

Reference sections supply torque charts, capacities, axle setup data, transmission pressure-test specifications, engine wear/clearance limits, brake limits, alignment geometry, electrical checks, and A/C application data. Special-tool pages identify the DD-1278 coil-spring compressor, C-4150A ball-joint remover, D-103/C-4171 pinion-bearing cup tools, 8514/8515 timing-chain tools, and 6906A transmission cooler flusher.

Useful illustrations include the 4.7L Timing Chain System, C205F pinion-depth and gear-contact-pattern views, 42RE/46RE Hydraulic Flow diagrams, the 45RFE Hydraulic Schematic, connector pin-out sheets, and component/splice location views. Together, these support parts identification, assembly orientation, hydraulic diagnosis, and harness tracing.

Manual-specific cautions matter during major repair work. C205F and rear-axle ring-and-pinion gears are matched sets; ring-gear bolts are not reused, and an over-crushed collapsible preload spacer cannot be corrected by backing off the pinion nut. On the 4.7L, forcing the camshafts and crankshaft independently can cause valve-to-piston contact, while damage or magnetization of the camshaft target wheel can create a no-start condition. During NV231/NV242 repair, replacement bearings must remain clear of the case oil-feed holes to avoid starving internal components.

Coverage is the 2000 model year, not a combined 1997-2000 service-manual set. The publication contains 5.2L references in ignition, fuel, cooling, and related systems, but no standalone 5.2L engine-overhaul chapter. AX15 appears in identification and fluid-capacity data, while 44RE appears in the identification codes; neither receives a dedicated teardown chapter. Group 25 explains OBD monitor logic, DTC descriptions, EVAP/PCV hardware, and selected tests, but directs certain DRB scan-tool operations and Leak Detection Pump testing to the separate Powertrain Diagnostic Procedures manual.

Support the truck and heavy drivetrain assemblies with rated equipment, isolate the battery for restraint or steering-column repair, and use approved equipment for fuel, cooling-system, and refrigerant service.
