Mazda 929 Repair Manual Collection, 1988–1991

867 Pages • ZIP Download: 45 Printable PDFs • 26.59 MB

5.0starstarstarstarstar(1)
$17.89 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Mazda Models Covered & Key Technical Specifications

Models: 929, B2000, 626, MX-6, MPV, B2200

Sub-models / Variants: 2.0L 4-Cylinder (FE, B2000); 2.2L 4-Cylinder (F2, B2200/626/MX-6); 2.2L 4-Cylinder Turbo (F2, 626/MX-6); 3.0L V6 SOHC (JE, 929/MPV); 2.6L 4-Cylinder (G6, MPV shared component sections); Manual Transmission (929: R-Type; MPV 2WD: R-Type/R5M-D; MPV 4WD: R5MX-D); Automatic Transmission (929: N4A-EL; MPV 2.6L: N4A-HL); PFI (Port Fuel Injection); 2-Barrel Carburetor

Model Years: 1986–1998 (1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998)

Serial Breaks: MPV 2.6L distributor configuration: before VIN No. JM3LV521L0225171 (shared component article).


  • Engine displacement: 121.9 cu. in. (2.0L), 133.2 cu. in. (2.2L), 180.2 cu. in. (3.0L)

  • Horsepower output: 80 HP (2.0L FE), 91 HP (B2200 2.2L PFI), 110 HP (626/MX-6 2.2L non-turbo), 145 HP (626/MX-6 2.2L Turbo), 158 HP (3.0L JE V6)

  • Torque delivery: 110–190 ft. lbs. @ 2500–4000 RPM (model dependent)

  • Compression ratios: 7.8:1 (2.2L F2 Turbo), 8.5:1 (3.0L JE), 8.6:1 (2.0L FE/2.2L F2 non-turbo)

  • Fuel system: Multi-point electronic fuel injection and 2-barrel carburetor variants

  • Valve configuration: 12-valve SOHC cylinder head (626/MX-6 F2); hydraulic auto-lash adjusters (F2 and 3.0L JE)

Mazda Manual Features & Selected Content Preview

Publication Pages
3.0L JE V6 engine repair — 1989 929, with shared MPV procedures 30
V6 on-vehicle adjustments — 1989 929/MPV 6
Mazda 3.0L SOHC V6 timing-belt service 6
N4A-EL automatic-transmission diagnosis — 929 applications, 1988–1991 61
N4A-EL/N4A-HL/NC4A-EL automatic-transmission overhaul — shared applications 67
Automatic-transmission removal and installation — 1989 929 1
R-Type manual-transmission overhaul — 1988–1989 929 and shared applications 18
Hydraulic clutch service 10
Anti-lock brake system — 1988–1991 Mazda applications 41
Conventional disc and drum brake service 15
929 axle-shaft service — 1990–1991 18
Differential and drive-axle service — 1990–1991 shared applications 29
Front suspension 6
Rear suspension 5
929 Auto Adjust Suspension (AAS) 10
Power rack-and-pinion steering 6
Electronic power steering 4
Steering-column service 6
V6 engine-management system and component tests 41
V6 self-diagnostic codes and fault charts 26
Engine-performance component removal, overhaul and installation — shared applications 26
929 vacuum diagrams 2
EGR function testing 1
Electrical component locator 8
Mitsubishi alternator service — 1989 7
Mitsubishi alternator and regulator service — 1990–1992 14
Gear-reduction starter service 14
929 automatic A/C-heater system 41
General A/C diagnostic procedures 7
Standard instrument panel 5
Electronic instrument panel 6
Anti-theft system 6
Cruise-control system 14
Rear-window defogger 2
Wiper/washer systems 10
Fuses and circuit breakers 3
929 system wiring diagrams — 1990 27
Cooling-system specifications 1
Drive-belt adjustment specifications 1
Service-reminder reset procedures — shared Mazda applications 6
B2000 2.0L FE engine — 1986 20
2.2L F2/F2 Turbo engine — 1990–1991 B2200/626/MX-6 applications 38
General engine-overhaul procedures 54
General troubleshooting and basic procedures 61
Rotary-engine chapter — turbo/non-turbo removal, inspection, rebuild and installation 87

Use the mechanical service articles alongside the component-test charts and wiring diagrams for diagnosis and repair planning. Many illustrations are credited to Mazda Motors Corp.

Coverage is article-specific. The main 929 engine, chassis and electrical material centers on 1989; the other principal year ranges appear in the table. Shared FE/F2 engine articles, MPV procedures and the rotary-engine chapter do not provide complete vehicle coverage for every model named. The SOHC timing-belt article carries maintenance guidance through 1998; this does not extend the coverage of the other repair articles.

Text Search, Bookmarks and Diagram Detail

Reading and navigation: Text search is available in 44 PDFs, although many diagram and diagnostic-chart labels are not searchable. The rotary chapter has no searchable text. The 44 article PDFs have no embedded bookmarks; the rotary file’s three bookmarks all open its first page. Dense wiring labels require zooming, and some fault-code charts have faint characters.

The ZIP contains 45 printable English PDFs totaling 867 pages, including the 87-page rotary-engine supplement, with its two index pages included.


V6 Repair, Transmission Overhaul and Electrical Diagnosis

These coverage highlights sample the repair and diagnostic content. Other topics include cruise-control testing and rear-window defogger filament checks.

  • JE V6 repair: Step-by-step engine removal, cylinder-head and timing-belt service, internal inspection, water-pump work, and lubrication-system repair.

  • Transmission service: N4A-EL hydraulic and electronic diagnosis, automatic-transmission bench overhaul, R-Type manual-transmission rebuilding, and hydraulic clutch service.

  • Brakes and axles: ABS-tester diagnosis, hydraulic-unit and wheel-speed-sensor checks, conventional brake service, CV-joint overhaul, and differential setup.

  • Steering and suspension: Power-steering pressure testing and bleeding, electronic-assist diagnosis, front/rear suspension work, and Auto Adjust Suspension circuit tests.

  • Engine controls and electrical: Self-diagnostic fault charts, V6 component tests, charging/starter testing, anti-theft diagnosis, and model-year-specific wiring diagrams.

  • Automatic climate control: Self-diagnostics, actuator and sensor checks, plus removal procedures for the compressor, condenser, receiver-drier, evaporator housing, and expansion valve.

These articles are suited to technicians and experienced DIY owners already comfortable with mechanical teardown, electrical testing, pressure gauges, DVOM work, and model-specific service data.

Engine Repair and Oil-Pump Configurations

Cylinder-head work includes intake and exhaust manifolds, camshafts, rocker shafts, valves, and hydraulic lash adjuster checks. Bottom-end coverage extends to pistons and rods, crankshaft inspection, main and connecting-rod bearings, and oil seals.

The manual distinguishes the 929’s Trochoid and positive-displacement oil-pump arrangements, an important configuration difference when selecting the correct procedure and specifications. The Trochoid pump is housed in the front cover; the other arrangement mounts beneath the cylinder block. The MPV procedures use the Trochoid configuration.

Timing-belt sections include alignment and belt-reuse rotation precautions. Related reference tables provide fastener torques, connecting-rod specifications, valve stem/guide limits, camshaft and crankshaft journal data, and oil-pressure/capacity information.

Transmission Diagnosis and Bench Work

Stall-speed, shift time-lag and line-pressure tests accompany road testing, shift-speed charts, self-diagnosis, and shift-lock checks. Together, the hydraulic tests and electrical fault charts support fault isolation before internal transmission work.

The overhaul article covers the oil pump, direct/front/rear clutches, brake bands and servos, planetary assemblies, one-way clutches, valve body, internal clearances, and reassembly. The torque converter is a sealed unit and is not disassembled for service.

Separate R-Type manual-transmission content covers disassembly, mainshaft work, synchronizer inspection, bearing-shim selection, and reassembly. Hydraulic clutch coverage includes the release components and master/release cylinders.

Brake, Differential and Chassis Service

Differential procedures cover pinion position, bearing preload, ring-gear backlash, and carrier checks, with Pinion Height Gauge 49 0727 570 specified for setup. Brake coverage includes master-cylinder service and the 929 parking-brake shoe assembly; chassis articles add steering-gear overhaul and AAS actuator/sensor testing.

ABS precautions address wheel-speed signal errors from impact-damaged sensor rings and control-unit damage from connector changes with the ignition on. Differential setup cautions against damaging the collapsible pinion spacer during pressing.

Engine Controls, Instruments and HVAC

Engine-management tests include the Triple Induction Control System and Variable Resonance Induction System, with sensor, solenoid, relay, fuel-delivery, and EGR checks.

Both standard and electronic instrument panels are covered. Gauge tests reference Checker 49 0839 285. Automatic climate-control charts address control-panel, blower, air-door actuator, and sensor faults; the HVAC specifications describe the original R-12 system.

Assembly Views and Circuit Diagrams

Illustrations include Exploded View Of Engine & Related Components (929) and Internal View Of Transmission (N4A-EL). The 929 Vacuum System Schematic supports hose tracing, while 929 AAS Component Locations and the electronic power-steering 929 Diagnostic Chart support chassis fault checks.

The dedicated 1990 wiring file includes Charging, Starting, Power Door Lock, and Wiper/Washer circuits, along with power-accessory and radio circuits. The transmission diagnosis file also separates 929 automatic-transmission schematics by model year.

Use appropriate lifting, electrical-isolation, brake-pressure, fuel-system, and refrigerant-safety practices for the repair being performed.

Examples from the V6 Electrical Test Data

For the 1989 V6 component tests, the coolant thermosensor table lists 2,300–2,700 ohms at 68°F (20°C) and 200–400 ohms at 176°F (80°C).

The separate fuel-injector test specifies 12–16 ohms for MPV and 929 injectors, providing an application-specific resistance range alongside the component-testing procedures.
