2004-2007 Honda Aquatrax F-12, ARX 1200 PWC repair manual

To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. Looking to repair your 4-stroke, 3-seat personal watercraft? Get your hands on the Honda Aquatrax service guide and workshop/repair manual in PDF format for comprehensive instructions. Product-Details and Specs: Production/model years: 2004, 2005, 2006, 2007 This manual applies to the following models: Aquatrax F-12, ARX 1200 Honda Aquatrax F-12 (ARX1200N3) - non-turbocharged model Honda Aquatrax F-12X (ARX1200T3) - turbocharged model Honda Aquatrax F-12X GPScape (ARX1200T3D) - turbocharged model w/ GPS and boarding step Honda Aquatrax F-12 Honda Aquatrax F-12X Honda Aquatrax F-12X GPScape Manual format: PDF / zip / .exe Manual Language: English Pages: 497 Printable: Yes, all printers Instant delivery: Download link will appear on the checkout page after your payment is complete. # ³ "Get the Comprehensive PDF Manual/Parts List for the 2004-2007 Honda Aquatrax F-12 and ARX 1200 PWCs - Download Now!" The 2004-2007 Honda Aquatrax F-12 and ARX 1200 PWCs are high-performance personal watercrafts that offer an exhilarating riding experience. If you own one of these models, it's essential to have a comprehensive manual and parts list to ensure proper maintenance and repairs. This PDF manual/parts list is the perfect resource for owners and mechanics alike. 30 Engine Specs/Technical Specifications for the Honda Aquatrax F-12 and ARX 1200 PWCs: • Engine: 1235cc four-stroke, liquid-cooled, DOHC, four-valve-per-cylinder inline four-cylinder • Horsepower: 123 hp • Bore x Stroke: 78.0 mm x 78.5 mm • Compression Ratio: 11.0:1 • Fuel System: Programmed Fuel Injection (PGM-FI) with automatic enrichment circuit • Ignition: Computer-controlled digital with three-dimensional mapping • Lubrication: Dry sump • Cooling System: Closed-loop cooling system • Exhaust System: Water-cooled exhaust manifold and muffler • Starter: Electric • Transmission: Direct-drive PTO • Impeller: Three-blade stainless steel • Hull: Fiberglass Reinforced Plastic (FRP) • Length: 132.8 inches • Width: 48.2 inches • Height: 46.8 inches • Dry Weight: 790-812 pounds • Fuel Capacity: 16.6 gallons • Oil Capacity: 4.0 quarts • Battery: 12V 19AH • Alternator: 25A • Pump Type: Axial-flow single-stage with large diameter impeller • Jet Pump: Aluminum, axial-flow • Intake Grate: Stainless steel • Ride Plate: Aluminum, delta-shaped • Trim System: Electric, variable angle • Steering System: Self-draining, open loop • Reverse System: Variable exhaust port • Top Speed: 57-60 mph • Color Options: Black, Red, and Blue The 2004-2007 Honda Aquatrax F-12 and ARX 1200 PWCs are highly sought-after watercrafts due to their powerful engines, sleek design, and exceptional performance capabilities. These models offer a smooth and comfortable ride, with excellent handling and maneuverability. Buy the OEM manual for your Honda Aquatrax F-12 and ARX 1200 PWCs with a secure PayPal purchase at www.repairloader.com to ensure you have access to comprehensive information for proper maintenance and repairs. After completing your payment, you will receive an email with all the necessary download information for your Honda F-12 manual. The download link will appear on the checkout page once your payment is complete. Please download and save the manual for future reference.

Price: 16.99 USD

↓ Instant Download: Paypal

Lifetime Guarantee
