Piper Cherokee PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, PA-28R-200 aircraft manual

Price: 29.99 USD
Lifetime Guarantee
File specifications File size: 23.49 MB File ending in: pdf
To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. The following models are covered by this manual: PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, PA-28R-200 / Piper Aircraft, Inc. Piper PA-28-140 Cherokee (Years: 1964-1967) Piper PA-28-150 Cherokee (Years: 1967-1974) Piper PA-28-160 Cherokee (Years: 1964-1970) Piper PA-28-180 Cherokee (Years: 1962-1983) Piper PA-28-235 Cherokee (Years: 1964-1982) Piper PA-28R-180 Cherokee Arrow (Years: 1967-1970) Piper PA-28R-200 Cherokee Arrow II (Years: 1969-1976) Pages: 916 Serial numbers: PART 753-586 Manual Language: English # ³ "Buy Original Piper Aircraft Parts List and Manual: Your Complete Guide to the Cherokee Series - PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, PA-28R-200!" Welcome to the comprehensive guide for the Piper Cherokee Series aircraft! The Piper Cherokee Series has been a staple in the general aviation community for decades, known for its reliability, versatility, and comfortable flying experience. In this ultimate guide, you will find the original parts list and detailed manual for the PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, and PA-28R-200 models. Whether you're a pilot, aircraft enthusiast, or owner, this guide will provide you with essential information on engine specifications, maintenance intervals, popular modifications, and more to ensure your Piper Cherokee aircraft remains in excellent condition and continues to serve you well on your aviation adventures. Let's take flight and explore the world of Piper Cherokee aircraft! Engine Specifications/Technical Data: • PA-28-140 Cherokee: Engine: Lycoming O-320-E2A Horsepower: 150 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,180 lbs (535 kg) Maximum Takeoff Weight: 2,300 lbs (1,043 kg) Cruise Speed: 108 knots (125 mph, 201 km/h) Range: 520 nautical miles (600 miles, 965 km) Rate of Climb: 660 feet per minute • PA-28-150 Cherokee: Engine: Lycoming O-320-E2A Horsepower: 150 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,180 lbs (535 kg) Maximum Takeoff Weight: 2,200 lbs (998 kg) Cruise Speed: 108 knots (125 mph, 201 km/h) Range: 520 nautical miles (600 miles, 965 km) Rate of Climb: 660 feet per minute • PA-28-160 Cherokee: Engine: Lycoming O-320-D3G Horsepower: 160 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,180 lbs (535 kg) Maximum Takeoff Weight: 2,400 lbs (1,089 kg) Cruise Speed: 111 knots (128 mph, 207 km/h) Range: 560 nautical miles (644 miles, 1,035 km) Rate of Climb: 700 feet per minute • PA-28-180 Cherokee: Engine: Lycoming O-360-A3A Horsepower: 180 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,315 lbs (596 kg) Maximum Takeoff Weight: 2,550 lbs (1,157 kg) Cruise Speed: 123 knots (142 mph, 229 km/h) Range: 540 nautical miles (622 miles, 1,001 km) Rate of Climb: 720 feet per minute • PA-28-235 Cherokee: Engine: Lycoming O-540-B4B5 Horsepower: 235 HP Fuel Capacity: 75 gallons (284 liters) Empty Weight: 1,480 lbs (671 kg) Maximum Takeoff Weight: 2,750 lbs (1,247 kg) Cruise Speed: 128 knots (147 mph, 237 km/h) Range: 725 nautical miles (835 miles, 1,344 km) Rate of Climb: 800 feet per minute • PA-28R-180 Cherokee Arrow: Engine: Lycoming O-360-C1A6D Horsepower: 180 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,475 lbs (669 kg) Maximum Takeoff Weight: 2,650 lbs (1,202 kg) Cruise Speed: 128 knots (147 mph, 237 km/h) Range: 710 nautical miles (818 miles, 1,317 km) Rate of Climb: 785 feet per minute • PA-28R-200 Cherokee Arrow II: Engine: Lycoming IO-360-B1E Horsepower: 200 HP Fuel Capacity: 50 gallons (189 liters) Empty Weight: 1,485 lbs (673 kg) Maximum Takeoff Weight: 2,650 lbs (1,202 kg) Cruise Speed: 133 knots (153 mph, 246 km/h) Range: 725 nautical miles (835 miles, 1,344 km) Rate of Climb: 835 feet per minute Facts and Details: - The Piper Cherokee Series aircraft, introduced in the late 1960s, became popular for flight training, personal flying, and short-haul travel. - The Cherokee Series features a low-wing design, providing excellent stability and control during flight. - The aircraft's spacious cabin accommodates up to four occupants, offering comfort for both pilots and passengers. - The Cherokee Series aircraft are equipped with a traditional control system, including a yoke and rudder pedals. - The PA-28-140, PA-28-150, PA-28-160, PA-28-180, and PA-28-235 models have fixed landing gear, while the PA-28R-180 and PA-28R-200 feature retractable landing gear. - The Cherokee Series boasts a wide range of certified avionics options, allowing for upgrades and modernization over time. - The aircraft's Lycoming engines are renowned for their reliability and efficient power delivery, making them ideal for training and personal flying missions. - The Cherokee Series aircraft offer excellent visibility from the cockpit, enhancing situational awareness during flight. - The Piper Cherokee Series is well-regarded for its forgiving flight characteristics, making it an ideal platform for flight training and building pilot confidence. - The PA-28-180 and PA-28-235 models are popular choices for cross-country flights due to their extended range and higher horsepower. Maintenance Intervals, Tips, and Common Issues: ► Regular Inspections: Adhere to the manufacturer's recommended inspection schedules to identify and address potential issues early on. ► Engine Overhaul: Lycoming engines require periodic overhauls based on operating hours or calendar time. Stay current with engine maintenance and overhaul requirements. ► Airframe Inspections: Perform thorough airframe inspections, including the wings, tail, and fuselage, to detect any signs of corrosion or structural issues. ► Landing Gear Maintenance: Check the landing gear regularly for wear, lubrication, and proper operation, especially in retractable models. ► Avionics Updates: Keep your avionics systems up to date for accurate navigation and communication during flight. ► Fuel System Checks: Regularly inspect the fuel system for leaks, contamination, and proper functioning to ensure a reliable fuel supply. Five Tips for Effective Maintenance: 1. Pre-flight Inspection: Perform a detailed pre-flight inspection before each flight to identify any visible issues or discrepancies. 2. Logbook Maintenance: Keep meticulous records of all maintenance, inspections, and repairs in the aircraft logbooks. 3. Quality Fuel: Use high-quality aviation fuel and ensure proper fueling procedures to prevent fuel-related issues. 4. Hangar Storage: Whenever possible, store your aircraft in a hangar to protect it from the elements and reduce wear and tear. 5. Engine Monitoring: Utilize engine monitoring systems to track engine performance, temperatures, and pressures during flight. Popular Tuning Tips and Modifications: ■ Avionics Upgrades: Install modern avionics systems, such as GPS navigation units, traffic and terrain awareness systems, and electronic flight displays, to enhance safety and situational awareness. ■ Interior Refurbishment: Refresh the aircraft's interior with updated materials, upholstery, and panels for a more comfortable and modern cabin environment. ■ Speed Modifications: Explore speed modifications, such as wingtip modifications or speed kits, to enhance cruise performance. ■ Improved Lighting: Upgrade exterior and interior lighting to improve visibility and enhance night flying capabilities. Accessories and Attachments: + Wheel Fairings: Install wheel fairings to reduce drag and improve aerodynamics. + Baggage Door Extension: Add a baggage door extension for easier access and increased storage capacity. Owner Reviews and Opinions: Strengths: ☺ The Piper Cherokee Series aircraft are known for their stable and forgiving flight characteristics, making them excellent trainers. ☺ The cabin design provides ample space and comfort for both pilots and passengers, even during extended flights. ☺ The Lycoming engines are renowned for their reliability and fuel efficiency, ensuring a dependable flying experience. ☺ The Cherokee Series offers a versatile range of models, accommodating various pilot skill levels and mission requirements. ☺ These aircraft are relatively easy to maintain and have a strong network of support from both the manufacturer and aviation communities. Weaknesses: ☻ Some owners have mentioned that the Cherokee Series can be susceptible to corrosion in certain areas, necessitating regular inspections and preventive maintenance. ☻ While the aircraft's low-wing design offers stability, it may require extra care during ground handling in windy conditions. ☻ The fixed landing gear in non-retractable models can limit ground maneuverability on certain airfields. The Piper Cherokee Series aircraft have earned their place as enduring icons in the aviation world. With their comfortable cabins, forgiving flight characteristics, and reliable performance, these aircraft are well-suited for a wide range of flying missions, from flight training to cross-country adventures. To maintain their excellence, regular maintenance is essential, ensuring proper engine and airframe care, adherence to inspection schedules, and updates to avionics systems. The Cherokee Series's versatility extends to the option for popular tuning tips and modifications, enabling pilots to personalize their aircraft for enhanced performance and comfort. By following these maintenance tips and embracing the aircraft's strengths, you can ensure your Piper Cherokee remains a reliable companion on every flight, ready to take you to new heights with confidence and safety. Most Frequently Repaired Parts: → Spark Plugs: Regular replacement of spark plugs is essential for optimal engine performance. → Tires: Wear and tear on landing and taxiing can lead to frequent tire replacements. → Brake Pads: Brake pads may require replacement due to regular use during landing and ground operations. → Batteries: Aircraft batteries may need replacement after several years of use. → Alternator: The alternator is a critical electrical component that may require replacement if it fails to charge the battery. → Fuel Pump: Fuel pumps may experience issues or failure over time, leading to starting and running problems. Unlock the wealth of information with just a click! Purchase the original Piper aircraft parts list and manual securely through PayPal. Once your payment is completed, you will instantly receive the download link for the OEM Piper parts list and shop handbook on the checkout page. Additionally, we will promptly send you the payment confirmation via email. §
Price: 29.99 USD
Lifetime Guarantee
