2006 Dodge Charger 300 / 300C / SRT-8 Service & Repair Manual (P/N 3W4Z-19G399-AA)

• Coverage: Ford Motor Company source material for 2005 Mustang coupe and convertible, Base and GT, with the 4.0L SOHC V6 or 4.6L 3-valve V8; selected 2006 workshop sections and limited Mustang TSB coverage through 2008 are also included.
• Engine files cover 4.0L removal and disassembly, cylinder-head and piston subassembly work, camshaft timing, valve covers, and cooling service, plus 4.6L engine removal, LH/RH camshaft repair, valve covers, coolant crossover, pump, and support insulators.
• Driveline material addresses 4.0L/4.6L clutch service, clutch hydraulic bleeding, T5OD component identification, 5R55S fluid service and cooler cleaning, both engine-specific driveshafts, snap-ring U-joint overhaul, and Ford 7.5-inch/8.8-inch rear axles.
• Chassis repair coverage includes brake inspection and pinpoint diagnosis, front and rear pad replacement, parking-brake adjustment, wheel/tire fault isolation, front camber adjustment, lower arms, inner tie rods, and suspension and power-steering exploded views.
• Electrical, HVAC, body, and interior sections include WDS-based audio diagnostics, wiring and connector views, fuse/relay information, PCM and cluster service, HVAC actuators, SRS depowering, seat/OCS work, trim removal, and window adjustment and initialization.
• File set: 485 pages across 173 PDF files. After exact duplicate files are excluded, there are 136 distinct PDFs totaling 412 pages; this is a selected repair-document collection, not a continuous full workshop manual.

These files combine Ford workshop-manual extracts, wiring information, accessory instructions, and Technical Service Bulletins. With engine timing, SRS/occupant-classification work, scan-tool diagnostics, and hoist-based powertrain procedures, the set is best suited to trained technicians with the specified tools; Ford’s included TSBs expressly state that their procedures are not intended for do-it-yourself repair.

Model and Document Coverage

The identification section decodes 2005 VIN and certification-label data, including body codes T80/T82/T84/T85, engine codes N (4.0L) and H (4.6L), transmission codes for T5OD/TR3150, TR3650, and 5R55S applications, axle information, spring codes, and powertrain calibration labels. Most workshop pages carry the issue line “2005 Mustang, 12/2004,” while the later engine, driveline, suspension, fuel, and EVAP extracts are marked “2006 Mustang, 9/2005.”

Coverage is procedure-specific. The engine PDFs contain removal and selected in-vehicle or subassembly repair operations rather than complete start-to-finish engine overhaul chapters, and the T5OD file provides description, identification, and disassembled component views rather than a full transmission rebuild. Many procedures cross-reference Ford WSM sections that are not part of this set.

Diagnostic Depth and Factory References

The 36-page audio section includes DLC/WDS communication checks, DTC indexes, speaker walk-around and radio self-diagnostic modes, symptom charts, and pinpoint tests for communication, reception, distortion, speaker, subwoofer, and popping-noise faults. The 13-page brake diagnosis section covers inspection, road testing, disc and pad checks, symptom charts, warning-lamp and vibration pinpoint tests, and booster/master-cylinder component tests.

Named visual references include the Front Suspension—Exploded View, Disc Brake System—Exploded View, T5OD Transmission Internal Components—Disassembled View, Fuel Tank and Filler Pipe—Exploded View, audio Wiring Diagrams Cell 130, and the C253 message-center connector view. Listed service equipment includes WDS/VCM, the 73III meter 105-R0057, 4.0L timing tools 303-564/571/573/577, the 4.6L timing-chain wedge 303-1175, engine-support kit 303-F072, U-joint press 205-086, inner tie-rod socket 211-D029, and transmission fill adapter 307-437. Related pages supply component torque data, approved fluids, inspection limits, adjustment specifications, and electrical test values.

TSB and Accessory Material

Six Mustang-related bulletins cover long-cruise acceleration hesitation (06-9-9), 4.6L A/C clutch failure (06-10-1), 5R55S pump-cover leakage on 2006 vehicles built from August 1 through December 7, 2005 (06-10-5), early-2005 front strut popping (07-18-1), front-end noise on 2005–2007 4.0L/4.6L coupes excluding GT500 and convertibles (07-18-2), and transmission-crossmember/exhaust vibration on vehicles built before December 3, 2007 (08-3-4).

Accessory PDFs cover the 2005 Mustang coupe Mobile-Ease hands-free kit P/N 3W4Z-19G399-AA, generic inside-mirror kit P/N F6AZ-17700-AC, and Compass/HomeLink mirror kit P/N 4L3Z-17700-AA. The included TSB 08-1-9 applies to 5.4L 3-valve Ford/Lincoln trucks and SUVs, not the Mustang; the two mirror sheets are universal accessory instructions rather than Mustang workshop chapters.

Repair-Specific Cautions

The 4.6L camshaft pages warn that this is a non-freewheeling engine: losing timing-chain-wedge position or failing to preserve the chain-to-phaser index can damage valves and pistons. Passenger-seat OCS components are factory-calibrated as an assembly, and cushion or service-kit work requires diagnostic-tool rezeroing; separating the calibrated components or altering the glued service connector can compromise the restraint repair.

Fuel-pressure relief, SRS depowering, correct engine support, brake-fluid handling, and refrigerant recovery are safety-critical parts of the covered work. Follow the applicable Ford warnings and use properly rated hoisting, diagnostic, and service equipment.
