2000-01 Mercedes-Benz E320, E430 & E55 Automatic A/C-Heater Systems Manual
This manual covers the 2000-01 Mercedes-Benz E320, E430 & E55 automatic A/C-heater systems, detailing control panel functions, components, and troubleshooting procedures.
Manual Preview
Purchase & Download
Models Covered & Key Technical Specifications
2000-01 Mercedes-Benz E320, E430 & E55 Automatic A/C-Heater Systems Manual: Mercedes-Benz E320, E430, E55 Automatic A/C-Heater Service Manual
This manual provides comprehensive coverage of the automatic A/C-heater systems for Mercedes-Benz E320, E430, and E55 models from 2000-01.
- Automatic Climate Control (ACC) System: The ACC system utilizes various sensors to maintain selected temperatures.
- Control Panel Functions: Details the blower motor knob, mode control knob, and temperature control knob operations.
- Temperature Sensors: Explains the function and location of in-vehicle, outside, evaporator, and heater temperature sensors.
- A/C Compressor Cut-Out Control: Describes the two-stage system to prevent engine overheating.
- Self-Diagnostics: Outlines procedures for retrieving and erasing Diagnostic Trouble Codes (DTCs).
- Functional Test: Provides step-by-step instructions for testing system modes like Defrost, Normal Ventilation, and Economy.
Professional Workshop Service Manual & Technical Specifications
2000-01 Mercedes-Benz Automatic A/C-Heater Systems Manual: Mercedes-Benz E320, E430, E55 Service Manual
Application: Mercedes-Benz E320, E430, E55 // System: Automatic A/C-Heater Logic // Coverage: Comprehensive Repair Data.
| Identifier | Technical-Path | Calibration-Standards |
|---|---|---|
| Compressor Type | Nippondenso 7SB16 7-Cyl. | Not Specified |
| Compressor Oil Capacity | 5.6-6.3 ozs. | Use Densooil 8 (A 001 989 08 03) |
| Refrigerant (R-134a) Capacity | 26.4 ozs. | Not Available from manufacturer |
The manual presents information on:
- Component descriptions and functions within the A/C-heater system.
- Detailed removal and installation procedures for various components.
- Electrical tests and diagnostic troubleshooting steps for common issues.
- Functional tests to verify system operation under different conditions.
- Wiring diagrams for system analysis and repair.
The troubleshooting chapter addresses common A/C and heater system faults. Cooling system maintenance is addressed in the relevant sections, covering component replacement and fluid specifications. Testing requirements are specified for sensors and control modules to ensure proper system diagnostics and repair. Methodically requiring accurate diagnosis, this manual provides the necessary technical information for servicing the climate control system.
